Product Description
The GE IC693MDL750 is a 32-point negative logic DC output module designed for the Series 90-30 PLC systems. This module provides an efficient means sur controlling a wide range sur DC devices by sinking current to the load, making it suitable for applications requiring fast switching and reliable digital control. Each sur the 32 outputs is grouped into four isolated groups sur eight, allowing flexible integration into various industrial systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | DC Output Module (Negative Logic) |
| Output Points | 32 |
| Output Type | Sinking (Negative Logic) |
| Voltage Range | 5 to 30 VDC |
| Output Current | 0.5 A per point, 4 A per group max |
| Isolation | 500V between field side and logic side |
| Response Time | Off to On: 0.1 ms, On to Off: 0.1 ms |
| Internal Power Consumption | 135 mA @ 5 VDC |
| Connector Type | 50-pin female (HE10 type) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (W x H x D) | 142 x 30 x 130 mm |
| Poids | 0.25 kg |
Applications
-
Industrial automation systems
-
Digital control sur relays, solenoids, and lamps
-
Assembly line and conveyor systems
-
Machine control systems
-
Packaging and material handling systems
-
Building automation interfaces
Advantages
-
High-density 32-point output in a compact module
-
Fast response suitable for time-critical operations
-
Electrically isolated groups enhance system protection
-
Low power consumption
-
Designed for seamless integration with GE Series 90-30 PLCs
-
Reduces wiring complexity with grouped output configuration
Questions fréquentes (FAQ)
Q1: What type sur logic does the IC693MDL750 use?
A1: It uses negative logic (sinking) outputs.
Q2: Can I connect this module directly to inductive loads?
A2: Yes, but external suppression (snubber or diode) is recommended.
Q3: How are the outputs grouped?
A3: The 32 outputs are divided into 4 groups sur 8, each group isolated from the others.
Q4: What is the maximum current for each group?
A4: Each group can handle up to 4 A total current.
Q5: Is the IC693MDL750 hot-swappable?
A5: No, the module is not hot-swappable. Power must be surf during installation/removal.
Q6: What is the recommended wire gauge for connections?
A6: Typically, 18 to 24 AWG wires are recommended for signal connections.
Q7: Does it support diagnostic LEDs?
A7: Yes, each output point has an LED for status indication.
Q8: What connector is used on this module?
A8: A 50-pin female HE10 connector is used.
Q9: Can it be used with other GE modules in the same rack?
A9: Yes, it is fully compatible with other Series 90-30 modules.
Q10: What is the output voltage range supported?
A10: The module supports 5 to 30 VDC output voltage.
Related or Same-Series GE Modèles
| Modèle Number | Description | Output Type | Points | Voltage Range | Dimensions (mm) | Poids |
|---|---|---|---|---|---|---|
| IC693MDL730 | DC Positive Logic Output Module | Sourcing (Positive) | 8 | 5–30 VDC | 142 x 30 x 130 | 0.20 kg |
| IC693MDL740 | DC Positive Logic Output Module | Sourcing (Positive) | 16 | 5–30 VDC | 142 x 30 x 130 | 0.23 kg |
| IC693MDL752 | DC Negative Logic Output Module | Sinking (Negative) | 8 | 5–30 VDC | 142 x 30 x 130 | 0.20 kg |
| IC693MDL931 | Relay Output Module | Relay | 8 | 5–30 VDC / 120 VAC | 142 x 30 x 130 | 0.28 kg |
| IC693MDL940 | Isolated Relay Output Module | Relay | 16 | 5–30 VDC / 120 VAC | 142 x 30 x 130 | 0.30 kg |
| IC693MDL645 | AC Output Module | Triac | 16 | 120/240 VAC | 142 x 30 x 130 | 0.26 kg |
Popular GE Modèles
| Modèle Number | Description | Type | I/O Points | Voltage/CPU | Dimensions (mm) | Poids |
|---|---|---|---|---|---|---|
| IC693CPU374 | CPU Module with Ethernet | CPU | N/A | 5VDC / 25 MHz | 142 x 30 x 130 | 0.35 kg |
| IC693ALG223 | Analog Output Module | Analog Output | 4 | 0–20 mA | 142 x 30 x 130 | 0.27 kg |
| IC693ALG390 | Analog Input Module | Analog Input | 8 | ±10 VDC | 142 x 30 x 130 | 0.28 kg |
| IC693CHS392 | 10-Slot Expansion Baseplate | Chassis | N/A | N/A | 372 x 132 x 70 | 1.50 kg |
| IC693MDL655 | AC Output Module | Discrete Output | 32 | 120/240 VAC | 142 x 30 x 130 | 0.30 kg |
| IC693PWR321 | Power Supply Module | Power Supply | N/A | 120/240 VAC / 125 VDC | 142 x 30 x 130 | 0.40 kg |
