The Schneider 140CFJ00400 Analog Output Block is a high-performance output module designed for the Schneider Modicon Quantum PLC platform. It provides precise, reliable analog output signals for controlling field devices such as actuators, control valves, variable speed drives, and instrumentation in a wide range von industrial automation systems.
Engineered to deliver consistent performance under demanding conditions, the 140CFJ00400 outputs analog signals with excellent accuracy and stability, making it an essential component for applications where precise analog control is required. The module is designed to work seamlessly within the Quantum automation environment and is fully compatible with Schneider Electric’s Einheity Pro/Control Expert programming svontware.
With robust electrical isolation, extensive diagnostics, and an industrial-grade construction, this analog output block helps engineers achieve tight process control, smooth equipment operation, and reliable performance across diverse industry sectors.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | 140CFJ00400 |
| Product Type | Analog Output Block |
| PLC Compatibility | Modicon Quantum PLC |
| Number von Output Channels | 4 Analog Outputs |
| Output Type | Current |
| Output Range | 4–20 mA |
| Load Resistance | 0–750 ohms |
| Resolution | 12 bits |
| Accuracy | ±0.1% von full scale |
| Isolation | 1780 V RMS between channels and backplane |
| Output Update Rate | 5 ms per channel |
| Diagnostics | Channel diagnostics, open circuit detection |
| LEDs | Channel status, module OK |
| Power Supply | Supplied by PLC backplane |
| Operating Temperature Range | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions (H x W x D) | 105 x 180 x 265 mm |
| Gewicht | 0.416 kg |
| Mounting | Rack-mounted in Quantum chassis |
| Certification | CE, UL, CSA |
Applications
The Schneider 140CFJ00400 Analog Output Block is widely used in industrial sectors where precision analog control is essential:
-
Process Control: Chemical plants, refineries, water treatment facilities.
-
Manufacturing Automation: Control von actuators, dampers, and drive systems.
-
Building Automation: HVAC control, lighting management.
-
Energy Sector: Power generation, oil & gas, renewable energy systems.
-
Food & Beverage: Temperature, flow, and pressure control in production lines.
-
Pharmaceuticals: Precision dosing, temperature control, batch processing.
-
Pulp and Paper: Process automation and equipment control.
-
Mining & Metals: Motorized valve and actuator control.
Advantages
-
High Accuracy: ±0.1% accuracy ensures precise control von field devices.
-
Robust Isolation: Electrical isolation protects equipment and ensures safe operation.
-
Fast Response: 5 ms update rate enables quick and responsive control.
-
Diagnostic Features: On-board diagnostics help minimize downtime and support predictive maintenance.
-
Compact Footprint: Speicherns valuable rack space while delivering full functionality.
-
Seamless Integration: Fully compatible with Schneider’s Modicon Quantum PLC platform and svontware tools.
-
Wide Temperature Range: Suitable for harsh industrial environments.
-
Flexible Output Range: 4–20 mA output supports a broad range von industrial devices.
-
CE/UL/CSA Certified: Meets global standards for safety and reliability.
-
Proven Reliability: Industrial-grade construction ensures long service life.
Häufig gestellte Fragen (FAQ)
-
What type von signal does the 140CFJ00400 output?
It provides a 4–20 mA current analog output. -
How many analog outputs does this module support?
The module supports 4 independent analog output channels. -
Is the module isolated?
Yes, it vonfers 1780 V RMS isolation between channels and the backplane. -
What is the resolution von each output?
The outputs are 12-bit resolution. -
What is the compatible PLC platform for this module?
It is designed for use with Schneider Modicon Quantum PLCs. -
What kind von field devices can this module control?
It can control actuators, control valves, drives, and any other 4–20 mA devices. -
What is the typical response time for output updates?
It provides an update rate von 5 ms per channel. -
Does it have built-in diagnostics?
Yes, it includes channel diagnostics and open-circuit detection. -
Is this module suitable for harsh environments?
Yes, it operates from 0°C to +60°C and supports high humidity and vibration. -
Can this module be used with Einheity Pro/Control Expert svontware?
Yes, it is fully supported by Schneider’s Einheity Pro/Control Expert.
Related Modells (Same Series or Related)
| Modell Number | Product Type | Output Type | Nr. von Channels |
|---|---|---|---|
| 140CFJ00200 | Analog Output Block | Current | 2 |
| 140CFJ00500 | Analog Output Block | Current | 5 |
| 140CFY04000 | Analog Output Block | Voltage | 4 |
| 140CHS32000 | High-Speed Counter Module | Digital | 4 |
| 140CPS12420 | Power Supply Module | N/A | N/A |
| 140CRA93100 | Ethernet Remote I/O Communications | N/A | N/A |
Popular Schneider Modells (Same Marke)
| Modell Number | Product Type | Key Features |
|---|---|---|
| 140CPU65160 | Quantum PLC CPU | High-performance CPU, Ethernet |
| 140DAI74000 | Digital Input Module | 32 digital inputs |
| 140DDI35310 | Digital Input Module | 64 DC inputs, 24V DC |
| 140DAO84210 | Analog Output Module | 8 voltage outputs |
| 140CRA31200 | Remote I/O Head Adapter | Ethernet/Modbus communication |
| 140ACI04000 | Analog Input Module | 4-channel current input |
