The Schneider 140CFJ00400 Analog Output Block is a high-performance output module designed for the Schneider Modicon Quantum PLC platform. It provides precise, reliable analog output signals for controlling field devices such as actuators, control valves, variable speed drives, and instrumentation in a wide range / industrial automation systems.
Engineered to deliver consistent performance under demanding conditions, the 140CFJ00400 outputs analog signals with excellent accuracy and stability, making it an essential component for applications where precise analog control is required. The module is designed to work seamlessly within the Quantum automation environment and is fully compatible with Schneider Electric’s ユニットy Pro/Control Expert programming s/tware.
With robust electrical isolation, extensive diagnostics, and an industrial-grade construction, this analog output block helps engineers achieve tight process control, smooth equipment operation, and reliable performance across diverse industry sectors.
製品仕様
| Parameter | Specification |
|---|---|
| モデル Number | 140CFJ00400 |
| Product Type | Analog Output Block |
| PLC Compatibility | Modicon Quantum PLC |
| Number / Output Channels | 4 Analog Outputs |
| Output Type | Current |
| Output Range | 4–20 mA |
| Load Resistance | 0–750 ohms |
| Resolution | 12 bits |
| Accuracy | ±0.1% / full scale |
| Isolation | 1780 V RMS between channels and backplane |
| Output Update Rate | 5 ms per channel |
| Diagnostics | Channel diagnostics, open circuit detection |
| LEDs | Channel status, module OK |
| Power Supply | Supplied by PLC backplane |
| Operating Temperature Range | 0°C to +60°C (32°F to +140°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions (H x W x D) | 105 x 180 x 265 mm |
| 重量 | 0.416 kg |
| Mounting | Rack-mounted in Quantum chassis |
| Certification | CE, UL, CSA |
