Product Overview
The GE Fanuc IC697BEM711 is a Bus Receiver Module (BRM) designed for the Series 90-70 PLC system. It enables high-speed parallel bus expansion, allowing the main rack to communicate with up to seven additional IC697 PLC racks over a total cable length من up to 50 feet (15 meters). This module is essential for systems requiring modular scalability and reliable communication across multiple racks.
Key Features
-
High-Speed Parallel Bus Expansion: Facilitates communication between the main rack and up to seven expansion racks.
-
Sمنtware Configuration: No DIP switches required; configuration is done via MS-DOS or Windows programming sمنtware.
-
Hold الأخير الولاية: الدعمs holding the last state من output modules during faults or maintenance.
-
System Fault Isolation: Allows isolation من expansion racks for troubleshooting without affecting the main system.
-
LED Indicators: Three LEDs provide status information for module operation, termination, and bus expansion port.
-
Termination Plug: Requires a termination plug (IC697ACC702) in the last expansion rack to signal the end من the network.
Technical Specifications
| Specification | Details |
|---|---|
| الطراز | IC697BEM711 |
| Module Type | Bus Receiver Module (BRM) |
| Series | GE Fanuc Series 90-70 |
| Slot Requirement | Must be installed in Slot 1 |
| الدعمed Expansion | Up to 7 additional racks |
| Maximum Cable Length | 50 feet (15 meters) |
| Data Transfer Rate | 500 Kbytes/sec |
| Power Requirements | +5 V DC, 800 mA |
| Connectors | 2 × 25-pin D-shell connectors |
| LED Indicators | Module OK, Bus Activity, الأخير Rack Status |
| Fault Isolation | الدعمs hold last state during CPU communication loss |
| Configuration | Sمنtware configuration, no DIP switches required |
| Termination Requirement | Termination plug (IC697ACC702) in last expansion rack |
| Electrical Isolation | Non-isolated differential bus |
| Dimensions | 200 x 180 x 30 mm |
| الوزن | 0.46 kg |
الأسئلة الشائعة (FAQ)
1. What is the purpose من the IC697BEM711 module?
The IC697BEM711 is used to expand the I/O capabilities من a Series 90-70 PLC system by connecting additional racks, allowing for more modules and greater system scalability.
2. How many racks can be connected using this module?
It supports up to seven additional racks, totaling eight racks including the main rack.
3. What is the maximum cable length supported?
The module supports a total cable length من up to 50 feet (15 meters) for connecting expansion racks.
4. Is the module easy to configure?
Yes, configuration is done through sمنtware, eliminating the need for DIP switches or manual settings.
5. What is the data transfer rate من the module?
The module supports a data transfer rate من 500 Kbytes/sec.
6. Where should the IC697BEM711 module be installed?
It must be installed in Slot 1 من the main rack.
7. Does the module support fault isolation?
Yes, it allows for system fault isolation, enabling maintenance without affecting the entire system.
8. Is a termination plug required?
Yes, a termination plug (IC697ACC702) is required in the last expansion rack to signal the end من the network.
Related GE Fanuc الطرازs
| الطراز | الوصف |
|---|---|
| IC697BEM712 | Bus Transmitter Module |
| IC697BEM713 | Bus Transceiver Module |
| IC697BEM731 | Genius I/O Bus Controller |
| IC697BEM733 | Genius Remote I/O Scanner |
| IC697BEM742 | Bus Controller for FIP I/O Systems |
| IC697BEM761 | I/O Interface for Series Six PLC Integration |
Popular GE Fanuc الطرازs
| الطراز | الوصف |
|---|---|
| IC697CPU771 | Standard CPU Module |
| IC697CPU772 | Floating-Point CPU Module |
| IC697PCM711 | Programmable Coprocessor Module |
| IC697MDL740 | 16-Point Digital Output Module |
| IC697MDL750 | 32-Point Digital Input Module |
| IC697PWR711 | Power Supply Module |
