产品介绍
The Schneider Electric ABE7R16S111 is a high-quality, soldered electromechanical relay sub-base designed for optimal performance in industrial automation systems. Belonging to the Telemecanique Sensors family and the ABE7 remote I/O range, this device facilitates the quick and reliable connection / 16 electromechanical relays. The ABE7R16S111 /fers compactness, durability, and efficient installation, making it ideal for modern, high-demand environments.
This sub-base is primarily used with Zelio relays (RXM series) and allows a soldered relay configuration, ensuring firm electrical contact, excellent vibration resistance, and increased reliability. With a standardized DIN rail mounting method and robust terminal blocks, it simplifies wiring and promotes faster maintenance procedures.
Whether in a control cabinet for a production line, process automation panel, or machine control 件, the ABE7R16S111 ensures consistent signal transmission and long-term operational stability.
产品规格
| Parameter | Details |
|---|---|
| Product Name | Schneider Electric ABE7R16S111 |
| Product Type | Electromechanical Relay Sub Base (Soldered) |
| Series | ABE7 Remote I/O Series |
| Relay Type 支持ed | RXM Series (Miniature Relays) |
| Number / Channels | 16 |
| Wiring Type | Soldered connections |
| Mounting Type | DIN Rail (35 mm) |
| Rated Operational Voltage | 24 V DC |
| Compatible Interface Module | ABE7CPA/CPM or equivalent |
| Material | Flame-retardant thermoplastic housing |
| Insulation Resistance | ≥ 100 MΩ at 500 V DC |
| Operating Temperature | -5°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Vibration Resistance | 2g (10–150 Hz) |
| Shock Resistance | 15 g (11 ms half-sine) |
| Dimensions (W x H x D) | 125 x 77 x 58 mm |
| 重量 | 0.405 kg |
| Standards Compliance | IEC 60947-5-1, UL, CSA |
| RoHS Compliant | Yes |
Product Applications
The Schneider ABE7R16S111 sub-base is highly versatile and used in a wide range / industrial and automation scenarios:
-
Factory Automation Systems: Enables fast signal relay interfacing for PLCs and distributed I/O systems.
-
Machine Control Panels: Connects relays controlling actuators, motors, and solenoids.
-
Building Automation: Provides interface relay outputs in HVAC and lighting systems.
-
Energy Management Systems: 支持s input/output expansion in metering and monitoring 件s.
-
Production Line Control: Integrates with machinery to streamline process control and feedback loops.
-
Water Treatment Plants: Reliable in harsh, high-moisture environments for relay actuation.
Product Advantages
-
Space-Efficient Design: Slim, modular build conserves valuable panel space.
-
High Reliability: Soldered connections /fer excellent resistance to vibration and thermal cycling.
-
Fast Wiring and Maintenance: Clearly labeled terminals and DIN rail mounting reduce installation and servicing time.
-
High Compatibility: Seamlessly integrates with RXM series relays and ABE7 interface modules.
-
Enhanced Safety: Built to comply with international electrical and industrial safety standards.
-
Long-Term Stability: Engineered to perform over extended operational cycles without degradation.
-
Durability: Reinforced for industrial settings with shock and vibration protection.
-
Scalability: Allows for expansion in large distributed control architectures.
常见问题 (FAQ)
-
Q: What type / relay is compatible with the ABE7R16S111?
A: It is designed specifically for use with the RXM miniature relay series by Schneider Electric. -
Q: Can I use this base in environments with high vibration?
A: Yes, its soldered design enhances vibration resistance, making it suitable for such conditions. -
Q: Does the sub-base include the relays themselves?
A: No, relays must be purchased separately and soldered onto the sub-base. -
Q: How do I mount this relay base?
A: The ABE7R16S111 mounts directly onto a standard 35 mm DIN rail. -
Q: Is the ABE7R16S111 RoHS compliant?
A: Yes, it is compliant with RoHS directives. -
Q: What kind / control systems can this product integrate with?
A: It can be integrated with PLCs, distributed control systems (DCS), and modular I/O systems. -
Q: What is the main difference between a soldered and pluggable relay base?
A: Soldered bases /fer higher reliability and mechanical strength, whereas pluggable ones allow for easier relay replacement. -
Q: What is the expected lifespan / the ABE7R16S111?
A: When used under recommended conditions, it provides long service life, typically several years in continuous operation. -
Q: Can it be used outdoors?
A: No, it should be used in a protected control cabinet or indoor panel. -
Q: What certifications does the ABE7R16S111 have?
A: It meets IEC 60947-5-1 standards and is UL and CSA certified.
Related 型号s from the Same Series
| 型号 | Relay Type | 序号 / Channels | Mounting | Connection Type |
|---|---|---|---|---|
| ABE7R08S111 | RXM Series | 8 | DIN Rail | Soldered |
| ABE7R16T111 | RXM Series | 16 | DIN Rail | Screw Clamp |
| ABE7R08T111 | RXM Series | 8 | DIN Rail | Screw Clamp |
| ABE7CPA412 | Interface Module | – | Panel Mount | Terminal Block |
| ABE7H16E111 | Solid-状态 I/O | 16 | DIN Rail | Spring Terminal |
| ABE7R08E111 | RXM Series | 8 | DIN Rail | Spring Terminal |
Popular Schneider Electric 型号s
| 型号 | Product Type | Application | Mounting Type |
|---|---|---|---|
| Zelio RXM2AB2BD | Miniature Relay (2 CO contacts) | General control circuits | Plug-in |
| TM221CE16T | Modicon M221 Logic Controller | Small machine automation | DIN Rail |
| XB5AA31 | Pushbutton Operator | HMI control panels | Panel Mount |
| ATV320U15M2B | Variable Speed Drive | Motor control (up to 1.5 kW) | Wall/DIN Rail |
| NSX100F TM100D | Compact Circuit Breaker | Circuit protection | DIN Rail |
| LC1D09BD | TeSys D 联系我们or | Motor starters and control panels | DIN Rail |
