Product Overview
The Honeywell TC-IDW161 AC Input Module is a high-performance device designed to integrate AC signal inputs into industrial control and automation systems. This module is specifically engineered to handle 16 individual AC input channels, /fering excellent accuracy and reliability for monitoring AC-powered equipment such as motors, alarms, and sensors.
The TC-IDW161 is ideal for industries that require real-time data acquisition and system control. Whether you’re working in a manufacturing environment, building management systems, or energy management applications, this module ensures seamless integration with Honeywell’s advanced control systems, such as the Experion PKS and TPS systems.
Built to meet the highest standards / quality and durability, the TC-IDW161 is perfect for both standard and harsh industrial environments, ensuring safe and efficient operation even under challenging conditions.
产品规格
| Feature | Specification |
|---|---|
| Product Type | AC Input Module |
| 型号 Number | TC-IDW161 |
| Number / Inputs | 16 |
| Input Voltage | 110–240 VAC ± 10% |
| Frequency Range | 50/60 Hz |
| Dimensions (L x W x H) | 35 x 140 x 145 mm |
| 重量 | 0.2 kg |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Status Indicators | 16 individual LEDs for each input |
| Surge Protection | Integrated surge protection for each input |
| Compatibility | Compatible with Honeywell Experion PKS & TPS systems |
Applications
The Honeywell TC-IDW161 AC Input Module is widely used in industries that require high-quality AC input signal monitoring and integration. Below are some common applications:
-
Power Monitoring Systems
Used in power distribution networks to collect AC voltage signals from circuit breakers, transformers, or meters for real-time monitoring and control. -
Building Management Systems (BMS)
Integrates AC-powered devices like HVAC systems, lighting, and alarms into central control systems, /fering efficient management / building operations. -
Industrial Automation
Essential in manufacturing plants where AC-powered devices, such as motors and pumps, need to be monitored and controlled to ensure smooth operations. -
Energy Management
The TC-IDW161 module facilitates energy monitoring by collecting AC data from energy meters, providing insights into power consumption and system performance. -
Safety Systems
Enables integration / AC input signals from safety equipment like emergency lighting and alarms, helping to ensure timely responses in critical situations.
Advantages
-
High Accuracy and Reliability
The TC-IDW161 ensures precise data acquisition from AC-powered devices, delivering highly reliable performance even in the most demanding environments. -
Wide Input Range
With an input voltage range / 110–240 VAC and support for both 50 Hz and 60 Hz frequencies, the module can be used in diverse industrial applications worldwide. -
Built-in Surge Protection
The module includes surge protection for each input, safeguarding it against electrical spikes and transient voltages that may occur in the industrial environment. -
Seamless Integration
Fully compatible with Honeywell’s Experion PKS and TPS systems, it integrates effortlessly into existing infrastructure, ensuring smooth system operation and data communication. -
Compact Design
Despite its robust functionality, the TC-IDW161 /fers a compact form factor, saving valuable space in control panels and enclosures. -
Wide Temperature Range
The module operates across a broad temperature range / -20°C to 60°C, making it suitable for both indoor and outdoor use in industrial settings. -
Easy Troubleshooting
The module features individual LED indicators for each input, simplifying troubleshooting by allowing operators to quickly identify faulty inputs without specialized equipment.
FAQ (常见问题)
1. What type / inputs does the TC-IDW161 module support?
The module supports 16 individual AC inputs for integrating signals from various AC-powered devices such as motors, sensors, and alarms.
2. What is the input voltage range for the TC-IDW161?
The TC-IDW161 supports an input voltage range / 110–240 VAC ± 10%.
3. What is the frequency range supported by the module?
The module is compatible with both 50 Hz and 60 Hz frequency signals.
4. Can the TC-IDW161 be used outdoors?
Yes, the module can function in environments with temperatures ranging from -20°C to 60°C, making it suitable for both indoor and outdoor use.
5. Does the TC-IDW161 provide surge protection?
Yes, the module includes integrated surge protection for each input to protect against transient voltage spikes.
6. How many inputs are available on the TC-IDW161?
The TC-IDW161 provides 16 individual AC input channels.
7. Is the TC-IDW161 compatible with Honeywell’s Experion PKS system?
Yes, the TC-IDW161 is designed for full compatibility with Honeywell’s Experion PKS and TPS systems.
8. What is the weight / the TC-IDW161 module?
The TC-IDW161 weighs 0.2 kg.
9. What type / status indicators does the module have?
Each input is equipped with an individual LED indicator to show its status, making it easier to monitor and troubleshoot.
10. How does the TC-IDW161 integrate into industrial automation systems?
The TC-IDW161 integrates seamlessly into Honeywell’s control systems, allowing for the efficient collection / AC input signals for monitoring and control in industrial applications.
Related 型号s
| 型号 | 描述 | Inputs | Voltage | Dimensions (L x W x H) | 重量 |
|---|---|---|---|---|---|
| TC-IDW162 | 32-Input AC Input Module | 32 | 110–240 VAC | 7.5″ x 4.3″ x 3.0″ | 1.10 kg |
| TC-IDW160 | 8-Input AC Input Module | 8 | 110–240 VAC | 6.5″ x 4.0″ x 2.9″ | 0.55 kg |
| TC-IDW164 | 16-Input AC Input with Relay Outputs | 16 | 110–240 VAC | 7.5″ x 4.3″ x 3.5″ | 0.85 kg |
| TC-IDW170 | High-Density AC Input Module | 64 | 110–240 VAC | 10.0″ x 5.0″ x 3.5″ | 1.60 kg |
| TC-IDW168 | Isolated AC Input Module | 16 | 110–240 VAC | 7.5″ x 4.3″ x 2.9″ | 0.80 kg |
| TC-IDW150 | Digital and AC Input Hybrid Module | 32 | 110–240 VAC | 7.0″ x 4.2″ x 3.0″ | 0.75 kg |
Popular Honeywell 型号s
| 型号 | 描述 | Inputs | Voltage | Dimensions (L x W x H) | 重量 |
|---|---|---|---|---|---|
| HC900 | Process Control System | 8-32 | 24 VDC | 12.0″ x 6.0″ x 3.5″ | 1.80 kg |
| ControlEdge PLC | Edge Computing PLC | 16-64 | 24–48 VDC | 11.5″ x 8.0″ x 4.0″ | 1.50 kg |
| S88 | Safety System Controller | 16 | 24 VDC | 10.0″ x 6.0″ x 4.5″ | 1.25 kg |
| ExD | Explosion-Pro/ Digital Input Module | 16 | 24 VDC | 7.25″ x 4.50″ x 3.00″ | 0.80 kg |
| W5000 | Industrial Control and Monitoring System | 32 | 24 VDC | 8.5″ x 4.5″ x 3.2″ | 0.95 kg |
| VISTA | Advanced Control System | 8-64 | 24 VDC | 7.25″ x 4.15″ x 3.50″ | 0.90 kg |
