The Honeywell FC-TSJASH-1624CC is a high-performance I/O module designed for use within the Experion PKS (Process Knowledge System) environment. It serves as a critical component for integrating analog and digital signals in industrial process control applications. Engineered with a robust, compact build, the module provides enhanced reliability and communication performance, enabling accurate data acquisition and control over complex automation processes.
This model is part / the Honeywell Field Control (FC) series and is optimized for seamless interoperability within distributed control systems (DCS). Its compact size, plug-in design, and extended operating parameters make it ideal for demanding industrial environments, including power plants, chemical processing, and oil and gas installations.
Product Advantages
-
High Signal Integrity: Delivers precise signal transmission and processing with minimized noise interference.
-
Robust Build Quality: Built to withstand harsh industrial environments including temperature fluctuations and electrical noise.
-
Plug-and-Play Integration: Easily integrates with Honeywell’s C300 controller and other system modules in the Experion PKS platform.
-
Compact Form Factor: Allows for dense installation in control cabinets, saving space without compromising performance.
-
Enhanced Diagnostics: 支持s advanced fault detection and diagnostic feedback for faster maintenance and reduced downtime.
-
Long Product Lifecycle: Designed for long-term system support and backward compatibility.
Technical Specifications
| Parameter | 描述 |
|---|---|
| 型号 Number | FC-TSJASH-1624CC |
| Product Type | Analog Input Module |
| 支持ed Signals | 16-channel 4–20 mA analog input |
| Input Range | 4–20 mA |
| Resolution | 16-bit |
| Communication Protocol | FTE / I/O Link |
| Power Supply | 24 VDC |
| Mounting Type | DIN-rail or panel-mounted |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | 213 x 112 x 70mm |
| 重量 | 0.5 kg |
| Certifications | CE, UL, CSA, RoHS compliant |
Product Applications
-
Power Generation Facilities – Used for analog signal acquisition in turbine and auxiliary system control.
-
Oil & Gas Plants – Ideal for upstream and downstream automation processes, including wellhead monitoring.
-
Chemical and Petrochemical Plants – Interfaces field sensors and transmitters with process control systems.
-
Water Treatment Plants – Manages flow, pressure, and level sensors to ensure optimized process flow.
-
Pharmaceutical Manufacturing – Ensures precise environmental and process monitoring.
-
Metallurgy and Mining – 支持s harsh-condition analog monitoring in steel mills and mining facilities.
Compatible 型号s
The Honeywell FC-TSJASH-1624CC works seamlessly with the following modules within the Experion and C300 controller ecosystem:
-
C300 Controller
-
FC-TSROCH-1624P
-
FC-TSGASH-1624P
-
FC-TSDI-1624
-
FC-TSAI-1620
-
FC-TSDO-0824
Installation Instructions
-
Ensure the control cabinet is powered down and ESD precautions are observed.
-
Mount the module on a DIN rail or fixed panel in a vertical orientation for optimal airflow.
-
Connect I/O signals via shielded twisted-pair cables.
-
Use the appropriate I/O termination assembly specified for this module.
-
Secure communication to the I/O Link interface and configure addressing using Control Builder.
-
Power up the cabinet and verify module recognition via the Experion Station.
常见问题 (FAQ)
Q1: What is the primary function / the FC-TSJASH-1624CC module?
A1: It serves as a 16-channel analog input module for reading 4–20 mA signals from field devices.
Q2: Is the module hot-swappable?
A2: 序号 Power must be turned /f before removing or installing the module to prevent damage.
Q3: Can this module be used in hazardous environments?
A3: Yes, it is certified to meet industrial safety and EMC standards for harsh settings.
Q4: How is the module configured after installation?
A4: Configuration is done via Honeywell’s Control Builder within the Experion PKS system.
Q5: What types / field devices can be connected?
A5: Any 4–20 mA analog transmitters, such as pressure, level, temperature, or flow sensors.
Q6: What is the accuracy / the analog input readings?
A6: The module features a 16-bit resolution, /fering high accuracy for industrial applications.
Q7: What is the recommended cable type for signal connection?
A7: Shielded twisted pair cables are recommended to minimize electrical interference.
Q8: Does the module provide channel-level diagnostics?
A8: Yes, it includes channel diagnostics for open loop, short circuit, and range errors.
Q9: Is the module compatible with legacy Honeywell systems?
A9: It is primarily intended for Experion systems but may support legacy integration via I/O link interfaces.
Q10: What maintenance is required for this module?
A10: Periodic inspection for physical integrity, cable condition, and diagnostic logs via Experion HMI is recommended.
Recommended 型号s from Same Series or Related
| 型号 Number | 描述 |
|---|---|
| FC-TSAI-1620 | 16-Channel Analog Input Module (4–20 mA) |
| FC-TSDI-1624 | 16-Channel Digital Input Module |
| FC-TSDO-0824 | 8-Channel Digital Output Module |
| FC-TSGASH-1624P | Analog Input Module with Galvanic Isolation |
| FC-TSROCH-1624P | Redundant Output Module |
| FC-TSPX01 | Power Supply Module for Field Controllers |
Popular Honeywell 型号s
| 型号 Number | Product Type | Input/Output Type | Size (W×H×D) | 重量 |
|---|---|---|---|---|
| FC-TSAI-1620 | Analog Input Module | 16 AI (4–20 mA) | 114×137×40 mm | 0.42 kg |
| FC-TSDI-1624 | Digital Input Module | 16 DI | 114×137×40 mm | 0.41 kg |
| FC-TSDO-0824 | Digital Output Module | 8 DO | 114×137×40 mm | 0.43 kg |
| FC-TSRCH-1624P | Redundant Channel Output Module | 16 DO | 114×137×40 mm | 0.47 kg |
| 2MLQ-SS2A-CC | Communication Module | Serial Bus Communication | 120×135×38 mm | 0.40 kg |
| FC-TSGASH-1624P | Analog Input Galvanic Isolation | 16 AI | 114×137×40 mm | 0.46 kg |
