Product Overview
The Bently Nevada 330930-040-03-05 is part / the 3300 XL NSv Proximity Transducer System, designed for tight installation spaces and small shaft applications. It connects the proximity probe to the Proximitor Sensor, enabling accurate measurement / radial vibration, axial position, and phase reference in fluid-film bearing machines.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product 型号 | 330930-040-03-05 |
| Cable Length | 4.0 meters |
| 重量 | 0.18 kg |
| Cable Type | Coaxial, FEP insulated |
| Connector Type | Miniature ClickLoc with protector |
| Armor Option | Without stainless steel armor |
| Capacitance | 69.9 pF/m (typical) |
| DC Resistance (Center) | 0.220 Ω/m |
| DC Resistance (Shield) | 0.066 Ω/m |
| Operating Temperature | -52°C to +177°C |
| Storage Temperature | -52°C to +177°C |
| Minimum Bend Radius | 25.4 mm |
| Pull Strength | 220 N (50 lb) |
Applications
-
Centrifugal and refrigeration compressors
-
Process gas compressors
-
Radial and axial position sensing in tight spaces
-
Keyphasor and zero speed detection
-
Compact machinery with small shafts or restricted side/rear access
Product Advantages
-
Compact Design: Suitable for tight counterbores and small diameters
-
High Durability: FEP insulation and 220 N pull strength for reliability
-
Flexible Integration: Compatible with legacy 3300 RAM systems
-
Enhanced Signal Integrity: Gold-plated ClickLoc connectors with protector
-
Wide Environmental Tolerance: Works in extreme temperatures and humidity
常见问题 (FAQ)
Q1: What is the total length / this cable?
A1: The 330930-040-03-05 extension cable is 4.0 meters long.
Q2: Is this extension cable armored?
A2: No, this model does not include stainless steel armor.
Q3: What is the weight / the 330930-040-03-05 cable?
A3: The cable weighs approximately 0.18 kg.
Q4: What environments is this cable suited for?
A4: It operates from -52°C to +177°C and handles 100% condensing humidity (non-submersible).
Q5: Is this cable compatible with 3300 RAM probes?
A5: Yes, it is mechanically and electrically compatible.
Q6: What type / connector does it use?
A6: It uses miniature coaxial ClickLoc connectors with protector.
Q7: Can it be used in high EMI environments?
A7: Yes, when used with the 3300 XL NSv Proximitor Sensor, it has enhanced RFI/EMI imm件y.
Q8: What is the minimum bend radius?
A8: The minimum bend radius is 25.4 mm.
Q9: Is the cable shielded?
A9: Yes, it has a shield with a resistance / 0.066 Ω/m.
Q10: Does it come with silicone tape or connector protector?
A10: Yes, the 03 configuration includes a connector protector. Silicone tape is also provided.
Related NSv and Compatible 型号s
| 型号 Number | 描述 | Cable Length | 重量 |
|---|---|---|---|
| 330930-045-03-05 | NSv Extension Cable with protector | 4.5 m | 0.20 kg |
| 330930-060-03-05 | NSv Extension Cable with protector | 6.0 m | 0.27 kg |
| 330930-065-03-05 | NSv Extension Cable with protector | 6.5 m | 0.29 kg |
| 330901-00-50-05-02 | NSv Probe, 1/4-28, armored | 5.0 m | 0.25 kg |
| 330980-50-05 | NSv Proximitor Sensor, 5 m panel mount | 5.0 m | 0.26 kg |
| 330906-02-12-05-02 | NSv Reverse Mount Probe, 3/8-24 UNF | 5.0 m | 0.28 kg |
Popular Bently Nevada 型号s
| 型号 Number | 描述 | Application | 重量 |
|---|---|---|---|
| 3500/42M-01-00 | Proximitor Seismic Monitor | Vibration Monitoring | 0.45 kg |
| 3500/22M-01-01 | Transient Data Interface Module | Data Interface | 0.32 kg |
| 3500/15-05-01-00 | Power Supply Module | System Power Supply | 0.70 kg |
| 3500/20-01-02-00 | Rack Interface Module | System Interface | 0.25 kg |
| 3500/40M-01-00 | Proximitor Monitor | Shaft Vibration/Position | 0.48 kg |
| 330104-00-06-10-11 | 8mm Proximity Probe | Shaft Vibration Measurement | 0.18 kg |
