Product Overview
The Bently Nevada 330930-040-03-05 is part von the 3300 XL NSv Proximity Transducer System, designed for tight installation spaces and small shaft applications. It connects the proximity probe to the Proximitor Sensor, enabling accurate measurement von radial vibration, axial position, and phase reference in fluid-film bearing machines.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Modell | 330930-040-03-05 |
| Cable Length | 4.0 meters |
| Gewicht | 0.18 kg |
| Cable Type | Coaxial, FEP insulated |
| Connector Type | Miniature ClickLoc with protector |
| Armor Option | Without stainless steel armor |
| Capacitance | 69.9 pF/m (typical) |
| DC Resistance (Center) | 0.220 Ω/m |
| DC Resistance (Shield) | 0.066 Ω/m |
| Operating Temperature | -52°C to +177°C |
| Storage Temperature | -52°C to +177°C |
| Minimum Bend Radius | 25.4 mm |
| Pull Strength | 220 N (50 lb) |
Applications
-
Centrifugal and refrigeration compressors
-
Process gas compressors
-
Radial and axial position sensing in tight spaces
-
Keyphasor and zero speed detection
-
Compact machinery with small shafts or restricted side/rear access
Product Advantages
-
Compact Design: Suitable for tight counterbores and small diameters
-
High Durability: FEP insulation and 220 N pull strength for reliability
-
Flexible Integration: Compatible with legacy 3300 RAM systems
-
Enhanced Signal Integrity: Gold-plated ClickLoc connectors with protector
-
Wide Environmental Tolerance: Works in extreme temperatures and humidity
Häufig gestellte Fragen (FAQ)
Q1: What is the total length von this cable?
A1: The 330930-040-03-05 extension cable is 4.0 meters long.
Q2: Is this extension cable armored?
A2: No, this model does not include stainless steel armor.
Q3: What is the weight von the 330930-040-03-05 cable?
A3: The cable weighs approximately 0.18 kg.
Q4: What environments is this cable suited for?
A4: It operates from -52°C to +177°C and handles 100% condensing humidity (non-submersible).
Q5: Is this cable compatible with 3300 RAM probes?
A5: Yes, it is mechanically and electrically compatible.
Q6: What type von connector does it use?
A6: It uses miniature coaxial ClickLoc connectors with protector.
Q7: Can it be used in high EMI environments?
A7: Yes, when used with the 3300 XL NSv Proximitor Sensor, it has enhanced RFI/EMI immStücky.
Q8: What is the minimum bend radius?
A8: The minimum bend radius is 25.4 mm.
Q9: Is the cable shielded?
A9: Yes, it has a shield with a resistance von 0.066 Ω/m.
Q10: Does it come with silicone tape or connector protector?
A10: Yes, the 03 configuration includes a connector protector. Silicone tape is also provided.
Related NSv and Compatible Modells
| Modell Number | Beschreibung | Cable Length | Gewicht |
|---|---|---|---|
| 330930-045-03-05 | NSv Extension Cable with protector | 4.5 m | 0.20 kg |
| 330930-060-03-05 | NSv Extension Cable with protector | 6.0 m | 0.27 kg |
| 330930-065-03-05 | NSv Extension Cable with protector | 6.5 m | 0.29 kg |
| 330901-00-50-05-02 | NSv Probe, 1/4-28, armored | 5.0 m | 0.25 kg |
| 330980-50-05 | NSv Proximitor Sensor, 5 m panel mount | 5.0 m | 0.26 kg |
| 330906-02-12-05-02 | NSv Reverse Mount Probe, 3/8-24 UNF | 5.0 m | 0.28 kg |
Popular Bently Nevada Modells
| Modell Number | Beschreibung | Application | Gewicht |
|---|---|---|---|
| 3500/42M-01-00 | Proximitor Seismic Monitor | Vibration Monitoring | 0.45 kg |
| 3500/22M-01-01 | Transient Data Interface Module | Data Interface | 0.32 kg |
| 3500/15-05-01-00 | Power Supply Module | System Power Supply | 0.70 kg |
| 3500/20-01-02-00 | Rack Interface Module | System Interface | 0.25 kg |
| 3500/40M-01-00 | Proximitor Monitor | Shaft Vibration/Position | 0.48 kg |
| 330104-00-06-10-11 | 8mm Proximity Probe | Shaft Vibration Measurement | 0.18 kg |
