产品介绍
The Bently Nevada 26530-12-10-03-018-210-22-04-00 Dual Probe Transducer System is an advanced vibration and displacement monitoring solution specifically developed for critical rotating equipment in power generation, petrochemical, and heavy process industries. This model features a dual-probe configuration that ensures redundant sensing capability for maximum reliability and continuous performance monitoring in high-demand industrial environments.
Engineered to deliver precise shaft vibration and radial displacement data, this system integrates seamlessly with Bently Nevada’s 3300 and 3500 machinery protection platforms. The 件 provides high-fidelity differential voltage output, ensuring superior imm件y to electromagnetic interference and electrical noise commonly found in industrial environments.
Constructed from high-grade stainless steel and industrial polymer composites, the 26530-12-10-03-018-210-22-04-00 transducer is designed for durability, thermal stability, and consistent performance across a wide range / operating conditions. Its 1.0-meter probe lead provides installation flexibility, allowing optimal probe positioning near critical bearing and shaft locations.
This system embodies Bently Nevada’s decades / experience in precision monitoring, /fering unmatched stability, linearity, and repeatability. It is an essential component in predictive maintenance programs aimed at preventing machinery damage and reducing unplanned downtime.
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | 26530-12-10-03-018-210-22-04-00 |
| Product Type | Dual Probe Transducer System |
| Measurement Function | Shaft vibration and radial displacement |
| Number / Probes | 2 (dual configuration) |
| Probe Lead Length | 1.0 meter |
| Output Signal Type | Differential voltage output |
| Nominal Sensitivity | 50 mV/mil |
| Frequency Response | DC to 10 kHz |
| Linear Range | Up to 2.0 mm (80 mils) depending on target |
| Operating Temperature Range | –40°C to +120°C |
| Storage Temperature Range | –40°C to +125°C |
| Relative Humidity | 0–95% non-condensing |
| Power Supply Voltage | +24 VDC nominal |
| Power Consumption | 2 W typical |
| Electrical Isolation | 500 V RMS minimum between signal and ground |
| Housing Material | Stainless steel / industrial polymer |
| Environmental Protection | IP65 enclosure (dust and water resistant) |
| Mounting Type | Threaded probe with locknut and mounting bracket |
| Signal Cable Type | Shielded twisted-pair cable for EMI protection |
| Compliance Standards | CE, ISO 9001, RoHS |
| Compatible Monitoring Systems | Bently Nevada 3300 / 3500 Series |
| 运输 重量 | 3 kg |
| Target Material | Ferromagnetic metals (steel, iron, nickel alloys) |
Applications
The 26530-12-10-03-018-210-22-04-00 Dual Probe Transducer System is designed for use in heavy industrial and process environments requiring precise measurement and continuous vibration analysis. Its applications include:
-
Turbines (steam, gas, and hydro) — measurement / shaft vibration, eccentricity, and bearing clearance.
-
Compressors and Pumps — detection / imbalance, misalignment, and rotor instability.
-
Electric Generators — monitoring / rotor movement and bearing condition.
-
Motors and Drives — analysis / vibration trends and early fault detection.
-
Industrial Process Equipment — real-time condition monitoring for predictive maintenance.
-
High-speed rotating machinery — monitoring dynamic shaft motion for system protection.
Its rugged and noise-resistant design makes it ideal for integration into automated monitoring systems that safeguard high-value industrial assets.
Advantages
-
Dual Redundant Design: Two independent probes ensure reliable data acquisition and system fault tolerance.
-
High Measurement Accuracy: Provides stable output with ±1% typical linearity within the operating range.
-
Wide Frequency Bandwidth: Covers DC to 10 kHz for accurate detection / slow- and high-speed machinery dynamics.
-
Superior Noise Imm件y: Differential voltage signal minimizes susceptibility to EMI and electrical interference.
-
Industrial-Grade Construction: Resistant to oil, vibration, and mechanical shock; IP65 protection ensures long-term operation.
-
Flexible Installation: 1.0-meter lead length allows easy routing and optimal probe placement.
-
Consistent Calibration: Maintains precise sensitivity and response over extended operating periods.
-
Low Power Consumption: Only 2 W required, minimizing system energy load.
-
Comprehensive Compatibility: Designed for use with Bently Nevada 3300/3500 machinery protection systems.
-
Predictive Maintenance Integration: Enables real-time data collection for early fault identification and condition-based maintenance.
FAQ
-
What is the primary function / this dual probe transducer system?
It measures both shaft vibration amplitude and radial displacement in rotating machinery. -
What type / electrical signal does the system output?
It provides a differential voltage signal for high noise imm件y and precise data transmission. -
Is the transducer compatible with Bently Nevada 3500 Monitoring Systems?
Yes, it is fully compatible with both the 3300 and 3500 series platforms. -
What is the nominal sensitivity value / the probes?
Each probe provides approximately 50 mV/mil nominal sensitivity under standard calibration. -
What is the frequency response range for this system?
The system operates effectively from DC up to 10 kHz. -
How is electromagnetic interference minimized?
The transducer uses shielded twisted-pair cables and a differential output configuration to reject external noise. -
Can the system operate in environments exposed to oil or vibration?
Yes, its IP65 housing allows reliable operation in oil-contaminated and high-vibration industrial environments. -
What is the required power supply for normal operation?
The system operates from a +24 VDC supply and consumes 2 W. -
What materials are suitable targets for accurate measurement?
The probes are optimized for ferromagnetic materials such as steel and nickel-based alloys. -
Why is a dual probe configuration used instead / a single probe?
Dual probes provide redundant measurement, ensuring data integrity and uninterrupted monitoring even if one probe fails.
Related 型号s (Same Series or Similar Type)
| 型号 Number | 描述 |
|---|---|
| 26530-12-10-03-018-159-22-04-00 | Standard dual probe transducer for general vibration monitoring |
| 26530-12-10-03-018-187-22-04-00 | Extended temperature range dual probe for high-stress conditions |
| 26530-12-10-03-018-191-22-04-00 | Enhanced accuracy model with improved linear response |
| 26530-12-10-03-018-195-22-04-00 | Industrial dual probe with upgraded EMI resistance |
| 26530-12-10-03-018-210-22-04-01 | Dual probe with integrated signal conditioning circuitry |
| 26530-12-10-03-018-210-22-04-02 | Advanced model optimized for turbine and compressor systems |
Popular Bently Nevada 型号s (Same 品牌)
| 型号 Number | 描述 |
|---|---|
| 330130-040-00 | Proximity probe transducer for standard industrial monitoring |
| 330230-010-00 | High-speed turbine vibration probe |
| 330530-010-00 | Dual probe sensor for combined vibration and displacement analysis |
| 330120-020-00 | Shaft position and radial vibration proximity probe |
| 330430-010-00 | Pump and motor vibration transducer |
| 330330-010-00 | Generator shaft vibration and displacement monitoring sensor |
