产品介绍
The ABB PFEA113-65 (3BSE028144R65) is a high-performance tension measurement module engineered for industrial applications that require real-time web tension monitoring. As part / ABB’s tension control system family, this module supports precise control and stable production processes in continuous material handling systems. It plays a crucial role in maintaining optimal tension during unwinding, rewinding, and intermediate processing / web materials such as paper, film, foil, textiles, and metal sheets.
This sensor module is designed to interface with strain gauge-based tension load cells and transmits accurate tension data to the control system, enabling dynamic adjustments to the drive or brake systems. Known for its reliability and robustness, the PFEA113-65 helps increase product quality, reduce material waste, and minimize downtime across a variety / industries.
Technical Specifications
| Parameter | 描述 |
|---|---|
| 型号 | PFEA113-65 |
| 零件号 | 3BSE028144R65 |
| Product Type | Tension Sensor Module |
| Measurement Channels | Dual independent strain gauge channels |
| Compatible Sensors | Strain gauge-based tension load cells (350 Ω) |
| Excitation Voltage | 5 VDC |
| Signal Output | Digital via ABB internal bus |
| Resolution | 16-bit ADC per channel |
| Sampling Rate | Up to 1,000 samples/sec |
| Power Supply | 24 VDC ±10% |
| Temperature Range | 0°C to +55°C (Operating), -40°C to +70°C (Storage) |
| Protection Rating | IP20 |
| Mounting | DIN rail |
| Communication | ABB MasterBus 300 / internal PLC system |
| LED Indicators | Power, Channel Status, Fault |
| Certifications | CE, RoHS, UL |
| Dimensions (W x H x D) | 150 x 110 x 120 mm |
| 重量 | 6 kg |
Applications
The PFEA113-65 module is tailored for industrial applications that rely on accurate web tension control. Some / the most common applications include:
-
Paper Mills: Tension monitoring during unwinding, rewinding, and paper stretching processes.
-
Plastic and Film Production: Ensuring consistent film stretch and uniformity during extrusion and lamination.
-
Textile Machinery: Maintaining correct yarn or fabric tension to prevent defects.
-
Printing Presses: Reducing print misalignment through stable web feed tension.
-
Packaging Machines: Controlling the tension / films and foils in wrapping and sealing processes.
-
Steel and Aluminum Rolling: Precision tension control during coiling and recoiling operations.
Product Advantages
-
High-Precision Tension Measurement
Uses dual 16-bit ADC channels to achieve accurate and responsive tension readings, critical for modern automation systems. -
Robust Industrial Design
Housed in a compact, IP20-rated enclosure designed for use in harsh industrial environments. -
Easy Integration with ABB Systems
Seamlessly interfaces with ABB’s automation platforms such as AC500, DCS800, and DriveIT systems via internal communication buses. -
支持s Dual Channel Monitoring
Capable / simultaneously reading two independent tension sensors for better system feedback and fault tolerance. -
DIN Rail Mounting
Quick and secure installation inside control cabinets reduces wiring complexity and space usage. -
Real-Time Diagnostics
Built-in LED indicators and system messages support troubleshooting and maintenance without system downtime. -
Low Power Consumption
Operates efficiently on standard 24 VDC supply with minimal heat dissipation, ideal for long-duration industrial operation.
常见问题 (FAQ)
-
What kind / sensors can I use with the PFEA113-65?
The module supports standard 350 Ω strain gauge tension load cells commonly used in industrial web tension systems. -
Does this module support both analog and digital outputs?
It receives analog inputs from sensors but transmits processed data digitally to ABB controllers. -
Can I use this module with third-party PLCs?
It is optimized for use with ABB PLCs and systems. Integration with third-party platforms may require additional interface modules. -
How accurate is the tension measurement?
The 16-bit resolution and fast sampling provide high precision, suitable for most tension-sensitive industrial processes. -
Is this module suitable for outdoor installation?
The module has an IP20 rating and is designed for indoor use inside control cabinets. -
What is the difference between PFEA113-65 and PFEA112-65?
PFEA113-65 supports dual independent tension channels, whereas PFEA112-65 may have only single or mirrored inputs. -
Does the device require periodic calibration?
Yes, regular calibration is recommended, especially when replacing or changing load cells. -
What happens if a sensor disconnects during operation?
The module has built-in fault detection that alerts the system / sensor failure or disconnection. -
Can this module be hot-swapped?
No, it should only be installed or removed with power /f to avoid signal issues or damage. -
What are the maintenance requirements?
Minimal maintenance is needed; periodic checks on connections and signal integrity are sufficient for long-term reliability.
Related or Same-Series ABB 型号s
| 型号 | 零件号 | 描述 |
|---|---|---|
| PFEA111-20 | 3BSE030370R20 | Single-channel tension measurement module |
| PFEA112-65 | 3BSE050091R65 | Dual-channel module, compatible with DCS800 |
| PFEA113-20 | 3BSE028144R20 | Compact version / the PFEA113 series |
| PFEA112-20 | 3BSE050091R20 | General-purpose tension monitoring module |
| PFEA111-50 | 3BSE030370R50 | For light tension measurement applications |
| PFEA113-75 | 3BSE028144R75 | High-precision variant with advanced diagnostics |
Popular ABB Industrial Automation 型号s
| 型号 | 零件号 | Function |
|---|---|---|
| AC500 PM595-4ETH | 1SAP190100R0001 | High-end PLC CPU for complex control tasks |
| DCS880-S | 3AXD50000034501 | DC industrial drive for crane and rolling systems |
| ACS880-01 | 3AXD50000034567 | Universal AC drive for high-demand applications |
| AI810 Analog In | 3BSE008516R1 | 8-channel analog input module for process control |
| CI854AK01 | 3BSE030220R2 | PROFIBUS communication interface for AC500/DCS |
| TU830V1 | 3BSE013252R1 | Compact MTU for S800 I/O with redundancy support |
