Produkteinführung
The ABB PFEA113-65 (3BSE028144R65) is a high-performance tension measurement module engineered for industrial applications that require real-time web tension monitoring. As part von ABB’s tension control system family, this module supports precise control and stable production processes in continuous material handling systems. It plays a crucial role in maintaining optimal tension during unwinding, rewinding, and intermediate processing von web materials such as paper, film, foil, textiles, and metal sheets.
This sensor module is designed to interface with strain gauge-based tension load cells and transmits accurate tension data to the control system, enabling dynamic adjustments to the drive or brake systems. Known for its reliability and robustness, the PFEA113-65 helps increase product quality, reduce material waste, and minimize downtime across a variety von industries.
Technical Specifications
| Parameter | Beschreibung |
|---|---|
| Modell | PFEA113-65 |
| Artikelnummer | 3BSE028144R65 |
| Product Type | Tension Sensor Module |
| Measurement Channels | Dual independent strain gauge channels |
| Compatible Sensors | Strain gauge-based tension load cells (350 Ω) |
| Excitation Voltage | 5 VDC |
| Signal Output | Digital via ABB internal bus |
| Resolution | 16-bit ADC per channel |
| Sampling Rate | Up to 1,000 samples/sec |
| Power Supply | 24 VDC ±10% |
| Temperature Range | 0°C to +55°C (Operating), -40°C to +70°C (Storage) |
| Protection Rating | IP20 |
| Mounting | DIN rail |
| Communication | ABB MasterBus 300 / internal PLC system |
| LED Indicators | Power, Channel Status, Fault |
| Certifications | CE, RoHS, UL |
| Dimensions (W x H x D) | 150 x 110 x 120 mm |
| Gewicht | 6 kg |
Applications
The PFEA113-65 module is tailored for industrial applications that rely on accurate web tension control. Some von the most common applications include:
-
Paper Mills: Tension monitoring during unwinding, rewinding, and paper stretching processes.
-
Plastic and Film Production: Ensuring consistent film stretch and uniformity during extrusion and lamination.
-
Textile Machinery: Maintaining correct yarn or fabric tension to prevent defects.
-
Printing Presses: Reducing print misalignment through stable web feed tension.
-
Packaging Machines: Controlling the tension von films and foils in wrapping and sealing processes.
-
Steel and Aluminum Rolling: Precision tension control during coiling and recoiling operations.
Product Advantages
-
High-Precision Tension Measurement
Uses dual 16-bit ADC channels to achieve accurate and responsive tension readings, critical for modern automation systems. -
Robust Industrial Design
Housed in a compact, IP20-rated enclosure designed for use in harsh industrial environments. -
Easy Integration with ABB Systems
Seamlessly interfaces with ABB’s automation platforms such as AC500, DCS800, and DriveIT systems via internal communication buses. -
Supports Dual Channel Monitoring
Capable von simultaneously reading two independent tension sensors for better system feedback and fault tolerance. -
DIN Rail Mounting
Quick and secure installation inside control cabinets reduces wiring complexity and space usage. -
Real-Time Diagnostics
Built-in LED indicators and system messages support troubleshooting and maintenance without system downtime. -
Low Power Consumption
Operates efficiently on standard 24 VDC supply with minimal heat dissipation, ideal for long-duration industrial operation.
Häufig gestellte Fragen (FAQ)
-
What kind von sensors can I use with the PFEA113-65?
The module supports standard 350 Ω strain gauge tension load cells commonly used in industrial web tension systems. -
Does this module support both analog and digital outputs?
It receives analog inputs from sensors but transmits processed data digitally to ABB controllers. -
Can I use this module with third-party PLCs?
It is optimized for use with ABB SPSs and systems. Integration with third-party platforms may require additional interface modules. -
How accurate is the tension measurement?
The 16-bit resolution and fast sampling provide high precision, suitable for most tension-sensitive industrial processes. -
Is this module suitable for outdoor installation?
The module has an IP20 rating and is designed for indoor use inside control cabinets. -
What is the difference between PFEA113-65 and PFEA112-65?
PFEA113-65 supports dual independent tension channels, whereas PFEA112-65 may have only single or mirrored inputs. -
Does the device require periodic calibration?
Yes, regular calibration is recommended, especially when replacing or changing load cells. -
What happens if a sensor disconnects during operation?
The module has built-in fault detection that alerts the system von sensor failure or disconnection. -
Can this module be hot-swapped?
No, it should only be installed or removed with power vonf to avoid signal issues or damage. -
What are the maintenance requirements?
Minimal maintenance is needed; periodic checks on connections and signal integrity are sufficient for long-term reliability.
Related or Same-Series ABB Modells
| Modell | Artikelnummer | Beschreibung |
|---|---|---|
| PFEA111-20 | 3BSE030370R20 | Single-channel tension measurement module |
| PFEA112-65 | 3BSE050091R65 | Dual-channel module, compatible with DCS800 |
| PFEA113-20 | 3BSE028144R20 | Compact version von the PFEA113 series |
| PFEA112-20 | 3BSE050091R20 | General-purpose tension monitoring module |
| PFEA111-50 | 3BSE030370R50 | For light tension measurement applications |
| PFEA113-75 | 3BSE028144R75 | High-precision variant with advanced diagnostics |
Popular ABB Industrial Automation Modells
| Modell | Artikelnummer | Function |
|---|---|---|
| AC500 PM595-4ETH | 1SAP190100R0001 | High-end PLC CPU for complex control tasks |
| DCS880-S | 3AXD50000034501 | DC industrial drive for crane and rolling systems |
| ACS880-01 | 3AXD50000034567 | Universal AC drive for high-demand applications |
| AI810 Analog In | 3BSE008516R1 | 8-channel analog input module for process control |
| CI854AK01 | 3BSE030220R2 | PROFIBUS communication interface for AC500/DCS |
| TU830V1 | 3BSE013252R1 | Compact MTU for S800 I/O with redundancy support |
