产品介绍
The ABB CI547 (3BNP004429R1) is a high-performance communication board engineered for use within ABB’s Advant Master and Safeguard 400 automation systems. It serves as a key interface to the MasterBus 300 (MB300) network, providing efficient and reliable data transmission between distributed control systems and field-level devices.
What sets the CI547 apart from other communication boards is its integrated slave processor. This onboard processor takes over much / the data exchange load from the main PM150 controller, thus improving the overall performance and reducing system latency. The CI547 plays a vital role in ensuring seamless communication across complex control environments and is critical in applications that demand precision, real-time data handling, and system reliability.
Its compact design, industrial-grade build quality, and compliance with global safety and performance standards make it a preferred choice for industrial applications across power generation, oil & gas, water treatment, and manufacturing.
产品规格
| Specification | Details |
|---|---|
| 型号 | CI547 |
| 零件号 | 3BNP004429R1 |
| Product Type | Communication Interface Board |
| Communication Protocol | MasterBus 300 (MB300) |
| System Compatibility | Advant Master, Safeguard 400 |
| Integrated Processor | Slave processor for MB300 communications |
| Power Supply | Supplied by the control system backplane |
| Data Transmission Rate | Up to 1 Mbps |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Installation | Plug-in type into system rack |
| RoHS Compliance | Yes |
| Country / Origin | Sweden |
| Dimensions (W × H × D) | 125 x 30 x 257 mm |
| 重量 | 0.165 kg |
| Mounting | Rack-mounted, horizontal insertion |
| 保修 | 12 months |
Applications
The ABB CI547 board is used in a wide range / industrial automation environments where high-speed, reliable communication is essential. Key applications include:
-
Power Generation Systems
支持s seamless communication between turbine controllers, protection relays, and distributed I/O. -
Oil and Gas Processing Facilities
Used in upstream and downstream processes for high-reliability control communications. -
Water and Wastewater Treatment Plants
Facilitates data communication between programmable logic controllers (PLCs), sensors, and actuators. -
Chemical and Petrochemical Plants
Enables integration / safety systems and DCS (Distributed Control Systems) for hazardous applications. -
Industrial Manufacturing and Assembly Lines
Provides deterministic control signal exchange for real-time automation workflows. -
Energy Management Systems
Facilitates fast and secure data exchange in complex grid infrastructure.
Product Advantages
-
Integrated Communication Processor
Offloads data handling from the main CPU, improving system speed and responsiveness. -
Robust Data Integrity
Ensures error-free communication over MB300 networks with built-in diagnostic support. -
Compact and Lightweight Design
Facilitates easy integration into existing systems with limited rack space. -
ABB System Compatibility
Seamlessly integrates into ABB’s Advant Master and Safeguard 400 series platforms. -
Wide Temperature Range
Suitable for industrial environments with varying temperature conditions. -
Field-Proven Reliability
Designed for 24/7 operation in mission-critical applications across energy and process industries.
常见问题 (FAQ)
-
What is the main purpose / the CI547 communication board?
It acts as a communication interface between ABB controllers and other devices using the MB300 protocol. -
Can the CI547 be used outside / the Advant Master system?
No, it is specifically designed to function within ABB’s Advant Master and Safeguard 400 systems. -
Is this board hot-swappable?
No, power should be removed before installation or removal to prevent damage. -
What type / processor is built into the CI547?
It includes a dedicated slave processor that manages communication independently from the main controller. -
Does this board require external power?
No, it is powered through the system backplane. -
What is the maximum data rate supported by MB300?
Up to 1 Mbps, depending on system configuration and cable length. -
How do I know if the CI547 is functioning correctly?
System diagnostics and status LEDs provide real-time feedback on board activity and errors. -
Can it be used in high-humidity environments?
Yes, it supports 5%–95% non-condensing humidity levels. -
Where is the CI547 manufactured?
It is manufactured in Sweden by ABB. -
What kind / maintenance does the CI547 require?
It is a passive device with no moving parts, requiring only routine system diagnostics and visual inspections.
Related or Similar 型号s from the Same Series
| 型号 | 描述 | Function |
|---|---|---|
| CI532 | Communication Interface for MB300 | Legacy MB300 communication board |
| CI520 | Communication Module for Advant Controller 110 | Interfaces controller to communication bus |
| CI541 | Communication Interface for DCS networks | Facilitates external DCS communication |
| CI544 | Communication Board for Advant OCS | Provides I/O bus and field device interface |
| CI526 | Redundant Communication Interface | Adds fault tolerance via redundant comms |
| CI853 | PROFIBUS-DP Module | PROFIBUS interface for AC800M |
Popular ABB 型号s
| 型号 | Product Type | Key Feature | Application Area |
|---|---|---|---|
| PM864 | AC800M CPU Module | High-speed processor for process automation | Distributed control systems (DCS) |
| AI810 | Analog Input Module | 8-channel, 0–20 mA input | Field signal acquisition |
| DO810 | Digital Output Module | 16-channel digital output, 24 V DC | Control / actuators |
| CI854AK01 | PROFIBUS-DP Communication Card | 支持s PROFIBUS networks | Industrial communication |
| TU810V1 | Terminal 单位 | Simplifies module wiring | Mounting / I/O modules |
| AC800M | Modular Controller | Flexible control system backbone | Large-scale automation systems |
