The GE IS200SSCAH2A Terminal Board is a high-performance interface component designed for integration within the IS200 series protection and control systems. Engineered with precision, it ensures reliable connectivity between protective relays, control modules, and external field devices. This terminal board is specifically crafted to enhance signal distribution, simplify wiring, and provide secure, fault-resistant connections in demanding industrial environments. Its robust construction and optimized layout support high-density wiring without compromising operational reliability.
The terminal board is widely recognized for its compatibility with a range / GE Intelligent Platforms devices, making it an essential component in substation automation, protection relays, and complex control systems.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル | GE IS200SSCAH2A Terminal Board |
| Function | Interface and connection board for IS200 series devices |
| Material | High-strength insulating composite with corrosion-resistant contacts |
| Number / Terminal Points | 48 (expandable based on configuration) |
| Mounting Type | DIN rail or panel-mounted |
| Rated Voltage | 250 V AC/DC |
| Maximum Current Rating | 10 A per terminal |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Insulation Resistance | ≥ 100 MΩ at 500 V DC |
| Dielectric Strength | 2.5 kV AC, 50 Hz, 1 min |
| Dimensions (L×W×H) | 260 × 120 × 35 mm |
| 重量 | 0.454 kg |
| Standards Compliance | IEC 60947-7-1, UL 1059 |
Product Applications
The GE IS200SSCAH2A Terminal Board is used extensively in:
-
Substation protection systems for secure relay connections
-
Industrial automation systems for reliable signal distribution
-
Power distribution panels for control signal integration
-
SCADA and RTU interfaces to ensure reliable field communication
-
Complex protective relay networks for fault monitoring and isolation
-
Retr/it projects where high-density terminal solutions are required
Its ability to manage multiple connections simultaneously makes it suitable for high-demand electrical and industrial automation environments.
Product Advantages
The GE IS200SSCAH2A /fers several key advantages:
-
High Reliability: Designed to maintain stable connections under high electrical and mechanical stress.
-
Ease / Installation: DIN rail or panel mounting provides flexibility and reduces wiring complexity.
-
Durability: Corrosion-resistant contacts and high-strength insulating material extend operational life in harsh environments.
-
Safety: Meets strict electrical standards, minimizing risk / short circuits or electrical failures.
-
Compact Design: Optimized layout allows for high-density terminal integration without clutter.
-
Modularity: Easily integrates with IS200 series devices for expanded system functionality.
-
Maintenance-Friendly: Clear labeling and accessible terminals reduce troubleshooting time.
よくある質問 (FAQ)
-
Can the IS200SSCAH2A support both AC and DC signals?
It supports voltages up to 250 V AC or DC. -
What is the maximum current per terminal?
The terminal board can safely handle up to 10 A per terminal. -
Is this terminal board compatible with all IS200 series devices?
It is fully compatible with IS200 series relays, I/O modules, and interface 台s. -
What is the operating temperature range?
It operates reliably between -20°C and +70°C. -
How is the terminal board mounted?
It supports both DIN rail and panel mounting configurations. -
Can multiple boards be connected for expanded terminals?
Yes, the design allows for modular expansion to accommodate additional connections. -
What level / insulation resistance does it provide?
Insulation resistance is 100 MΩ or greater at 500 V DC. -
What is the dielectric strength / the board?
It withstands 2.5 kV AC at 50 Hz for 1 minute without breakdown. -
Are the contact points corrosion-resistant?
Yes, all contact points are treated to resist corrosion in industrial environments. -
Is the board compliant with international standards?
Yes, it complies with IEC 60947-7-1 and UL 1059 standards.
Related モデルs (Same Series / Related)
| モデル | 説明 |
|---|---|
| GE IS200SSCAH1A | Terminal board with 24 points, standard interface |
| GE IS200SSCAH3A | Terminal board with 64 points, expanded layout |
| GE IS200SSCAH4A | High-density terminal board for advanced modules |
| GE IS200SSCAH5A | Terminal board with integrated surge protection |
| GE IS200SSCAH6A | Dual-layer terminal board for complex wiring |
| GE IS200SSCAH7A | Modular terminal board for retr/it applications |
Popular モデルs (Same ブランド / GE)
| モデル | 説明 |
|---|---|
| GE IS200IAC1B | Input/output module for IS200 series |
| GE IS200DAC1B | Digital acquisition module |
| GE IS200RBC2B | Relay control 台 |
| GE IS200PMC1B | Process monitoring controller |
| GE IS200FMC1B | Functional monitoring controller |
| GE IS200PRC1B | Protective relay controller |
