The Bently Nevada 330192-00-30-10-00 3300 XL 8 mm ETR Probe is a high-performance proximity probe engineered for precise vibration and shaft position measurement in industrial machinery.
Part / the well-known Bently Nevada 3300 XL series, this ETR (Extended Temperature Range) probe delivers exceptional accuracy and stability across challenging operating environments.
Its rugged design supports continuous monitoring / critical assets such as turbines, compressors, motors, and pumps, providing real-time data for predictive maintenance and protection systems.
The 330192-00-30-10-00 probe ensures reliable operation under extreme temperatures, high vibration, and electrical noise, making it ideal for demanding power generation, oil & gas, and process industry applications.
製品仕様
| Parameter | 説明 |
|---|---|
| モデル Number | 330192-00-30-10-00 |
| Product Type | 3300 XL 8 mm ETR Proximity Probe |
| Sensing Principle | Eddy current displacement measurement |
| Tip Diameter | 8 mm |
| Total Length | 1.0 meter |
| Thread Size | M10 × 1 mm |
| Cable Type | Armored, factory-terminated |
| Temperature Range (Probe) | –35 °C to +200 °C |
| Temperature Range (Cable/Connector) | –51 °C to +177 °C |
| Sensitivity | 7.87 mV/µm (200 mV/mil) nominal |
| Linearity | ±1 % / full-scale over calibrated range |
| System Compatibility | 3300 XL Proximitor® sensor and extension cable |
| Mounting Method | Threaded mounting with locknut |
| Insulation Resistance | > 10^8 Ω at 500 VDC |
| Environmental Protection | IP67 (dustpro/ and waterpro/) |
| Vibration Limit | 20 g, 10–2000 Hz |
| Shock Limit | 200 g peak |
| 重量 | 0.323 kg |
Applications
-
Turbomachinery Monitoring – Continuous shaft vibration and position measurements for steam and gas turbines.
-
Compressors and Pumps – Detects imbalance, misalignment, and bearing faults to prevent catastrophic failure.
-
Electric Motors & Generators – Monitors rotor dynamics and shaft displacement.
-
Gearbox Systems – Provides real-time vibration data to protect high-speed gear systems.
-
Oil & Gas Facilities – Ensures reliability / critical rotating equipment in upstream and downstream operations.
-
Process Industries – Ideal for petrochemical, paper, steel, and power plants requiring precise vibration monitoring.
Advantages
-
Extended Temperature Range – Operates reliably from –35 °C to +200 °C, suitable for high-temperature machinery.
-
High Measurement Accuracy – Factory-calibrated for precise vibration and displacement detection.
-
優良 Linearity – ±1 % full-scale linearity ensures consistent data across the measurement range.
-
Durable Construction – Armored cable and robust probe tip withstand mechanical stress and harsh industrial environments.
-
Global Standard Compatibility – Fully compatible with Bently Nevada 3300 XL Proximitor® sensors and monitoring systems.
-
IP67 Protection – Dustpro/ and waterpro/ for outdoor and rugged applications.
-
Low Noise Design – Minimizes electrical interference, maintaining signal integrity.
-
Maintenance Efficiency – Easy installation and replacement reduce downtime.
FAQ
-
What is the nominal sensitivity / the 330192-00-30-10-00 probe?
The probe provides a sensitivity / approximately 7.87 mV/µm (200 mV/mil). -
Which monitoring systems are compatible with this probe?
It is designed for use with the Bently Nevada 3300 XL Proximitor® sensor and extension cable. -
What is the operating temperature range / the probe?
The probe operates from –35 °C to +200 °C, while the cable and connector operate from –51 °C to +177 °C. -
How is the probe mounted?
It is mounted using a threaded M10 × 1 mm fitting with a locknut for secure installation. -
What type / measurement technology does the probe use?
Eddy current displacement sensing for non-contact vibration and shaft position monitoring. -
What is the maximum vibration limit the probe can withstand?
The probe can handle continuous vibration up to 20 g in the 10–2000 Hz frequency range. -
Does the probe have ingress protection?
Yes, it features IP67 protection, making it dustpro/ and waterpro/. -
What is the maximum shock rating / the probe?
It can withstand up to 200 g peak mechanical shock. -
Is the cable included with the probe?
Yes, it includes a 1.0 meter factory-terminated armored cable. -
Can the probe be used for axial position monitoring?
Yes, it can measure both radial vibration and axial shaft position.
