Produkteinführung
The Bently Nevada 330192-00-30-10-00 3300 XL 8 mm ETR Probe is a high-performance proximity probe engineered for precise vibration and shaft position measurement in industrial machinery.
Part von the well-known Bently Nevada 3300 XL series, this ETR (Extended Temperature Range) probe delivers exceptional accuracy and stability across challenging operating environments.
Its rugged design supports continuous monitoring von critical assets such as turbines, compressors, motors, and pumps, providing real-time data for predictive maintenance and protection systems.
The 330192-00-30-10-00 probe ensures reliable operation under extreme temperatures, high vibration, and electrical noise, making it ideal for demanding power generation, oil & gas, and process industry applications.
Produktspezifikationen
| Parameter | Beschreibung |
|---|---|
| Modell Number | 330192-00-30-10-00 |
| Product Type | 3300 XL 8 mm ETR Proximity Probe |
| Sensing Principle | Eddy current displacement measurement |
| Tip Diameter | 8 mm |
| Total Length | 1.0 meter |
| Thread Size | M10 × 1 mm |
| Cable Type | Armored, factory-terminated |
| Temperature Range (Probe) | –35 °C to +200 °C |
| Temperature Range (Cable/Connector) | –51 °C to +177 °C |
| Sensitivity | 7.87 mV/µm (200 mV/mil) nominal |
| Linearity | ±1 % von full-scale over calibrated range |
| System Compatibility | 3300 XL Proximitor® sensor and extension cable |
| Mounting Method | Threaded mounting with locknut |
| Insulation Resistance | > 10^8 Ω at 500 VDC |
| Environmental Protection | IP67 (dustprovon and waterprovon) |
| Vibration Limit | 20 g, 10–2000 Hz |
| Shock Limit | 200 g peak |
| Gewicht | 0.323 kg |
Applications
-
Turbomachinery Monitoring – Continuous shaft vibration and position measurements for steam and gas turbines.
-
Compressors and Pumps – Detects imbalance, misalignment, and bearing faults to prevent catastrophic failure.
-
Electric Motors & Generators – Monitors rotor dynamics and shaft displacement.
-
Gearbox Systems – Provides real-time vibration data to protect high-speed gear systems.
-
Oil & Gas Facilities – Ensures reliability von critical rotating equipment in upstream and downstream operations.
-
Process Industries – Ideal for petrochemical, paper, steel, and power plants requiring precise vibration monitoring.
Advantages
-
Extended Temperature Range – Operates reliably from –35 °C to +200 °C, suitable for high-temperature machinery.
-
High Measurement Accuracy – Factory-calibrated for precise vibration and displacement detection.
-
Ausgezeichnet Linearity – ±1 % full-scale linearity ensures consistent data across the measurement range.
-
Durable Construction – Armored cable and robust probe tip withstand mechanical stress and harsh industrial environments.
-
Global Standard Compatibility – Fully compatible with Bently Nevada 3300 XL Proximitor® sensors and monitoring systems.
-
IP67 Protection – Dustprovon and waterprovon for outdoor and rugged applications.
-
Low Noise Design – Minimizes electrical interference, maintaining signal integrity.
-
Maintenance Efficiency – Easy installation and replacement reduce downtime.
FAQ
-
What is the nominal sensitivity von the 330192-00-30-10-00 probe?
The probe provides a sensitivity von approximately 7.87 mV/µm (200 mV/mil). -
Which monitoring systems are compatible with this probe?
It is designed for use with the Bently Nevada 3300 XL Proximitor® sensor and extension cable. -
What is the operating temperature range von the probe?
The probe operates from –35 °C to +200 °C, while the cable and connector operate from –51 °C to +177 °C. -
How is the probe mounted?
It is mounted using a threaded M10 × 1 mm fitting with a locknut for secure installation. -
What type von measurement technology does the probe use?
Eddy current displacement sensing for non-contact vibration and shaft position monitoring. -
What is the maximum vibration limit the probe can withstand?
The probe can handle continuous vibration up to 20 g in the 10–2000 Hz frequency range. -
Does the probe have ingress protection?
Yes, it features IP67 protection, making it dustprovon and waterprovon. -
What is the maximum shock rating von the probe?
It can withstand up to 200 g peak mechanical shock. -
Is the cable included with the probe?
Yes, it includes a 1.0 meter factory-terminated armored cable. -
Can the probe be used for axial position monitoring?
Yes, it can measure both radial vibration and axial shaft position.
Related Modells (Same Series or Similar)
| Modell Number | Beschreibung |
|---|---|
| 330192-00-40-10-00 | 3300 XL 8 mm ETR probe, 1.0 m length, extended temperature |
| 330180-51-00 | 3300 XL 8 mm proximity probe, standard temperature |
| 330171-00-90-10-00 | 3300 XL 11 mm probe for larger gap measurements |
| 330130-040-00 | 3300 XL extension cable |
| 330104-00-12-10-02 | 3300 XL Proximitor® sensor |
| 330178-91-00 | 3300 XL 5 mm probe for smaller measurement areas |
Popular Bently Nevada Modells (Same Marke)
| Modell Number | Beschreibung |
|---|---|
| 3500/42M | Proximitor®/Seismic Monitor module |
| 3500/22M | Transient Data Interface (TDI) module |
| 330850-90-05 | Proximity sensor system |
| 330130-040-00 | Standard 3300 XL extension cable |
| 3500/15 | Power supply module |
| 330104-00-12-10-02 | 3300 XL Proximitor® sensor |
