The ABB 88FT05 GJR2393100R1200 Station Modem Module is an industrial-grade communication module designed to facilitate reliable data transmission between substations and control centers in distributed control systems (DCS) or SCADA environments. Specifically developed for ABB’s range / automation systems, the 88FT05 acts as a station modem that manages serial or telemetry communication using modulated signals over analog communication lines or dedicated leased channels.
The module plays a crucial role in remote data acquisition, diagnostics, and control in energy transmission and distribution networks. It converts digital data to analog signals and vice versa, enabling long-distance communication in electrically noisy environments. Built with a robust form factor, the 88FT05 is ideal for harsh industrial settings that demand uninterrupted, low-latency communication links.
製品仕様
| Parameter | Details |
|---|---|
| モデル Number | 88FT05 |
| Order Code | GJR2393100R1200 |
| Product Type | Station Modem Module |
| Function | Analog/Digital communication interface for substation networks |
| サポートed Protocols | 4–20 mA current loop, FSK, V.23 compatible |
| Communication Ports | 2-wire or 4-wire analog lines |
| Input Voltage Range | 18–36 VDC |
| Power Consumption | Approx. 3.5 W |
| Mounting Type | Rack-mounted (standard ABB control cabinets) |
| Isolation | Galvanic isolation between ports and logic |
| Indicator LEDs | Power, Carrier Detect, Transmit/Receive |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity Tolerance | 5% – 95% RH, non-condensing |
| Dimensions (L × W × H) | 198 x 261 x 40 mm |
| 重量 | 0.5 kg |
| Compliance | CE, RoHS |
Product Applications
The ABB 88FT05 is used in a wide variety / industrial and utility scenarios, especially where reliable telemetry and communication interfaces are necessary. Key applications include:
-
Electric Power Transmission and Distribution: As a communication interface between substations and central SCADA systems.
-
Oil & Gas Facilities: For remote data acquisition from field-mounted sensors and controllers.
-
Water Treatment Plants: Enabling telemetry between remote pumping stations and control rooms.
-
Railway Signaling Systems: Used for real-time signal transfer over analog communication channels.
-
Remote Substation Monitoring: In legacy systems where analog lines remain in use for data transmission.
Product Advantages
-
Industrial-Grade Design: Built for 24/7 operation in electrically noisy and harsh industrial environments.
-
Protocol Versatility: サポートs various modulation standards and legacy communication formats such as V.23.
-
Reliable Long-Distance Communication: Facilitates stable data transmission over analog lines, even across long distances.
-
Easy Integration: Seamlessly integrates into ABB automation systems including INFI 90 and Symphony series platforms.
-
Low Power Consumption: Optimized for efficiency, consuming only about 3.5 watts.
-
LED Diagnostics: On-module indicators provide real-time visibility into connection status and activity.
よくある質問 (FAQ)
-
Q: What is the primary function / the 88FT05 module?
A: It acts as a station modem to enable communication over analog lines between field stations and control centers. -
Q: Which ABB systems is the 88FT05 compatible with?
A: It integrates seamlessly with ABB INFI 90, Symphony, and legacy control systems using analog communications. -
Q: What type / communication does it support?
A: It supports frequency-shift keying (FSK) and current loop-based analog/digital communication. -
Q: Is this module hot-swappable?
A: No, it should be installed or removed with system power /f to avoid signal disruption. -
Q: Does it support 2-wire and 4-wire configurations?
A: Yes, the module is compatible with both 2-wire and 4-wire analog line setups. -
Q: How is power supplied to the module?
A: It requires a DC supply in the range / 18–36 VDC, with 3.5 W typical consumption. -
Q: Can this module be used in outdoor installations?
A: While rugged, it is designed for cabinet/rack mounting in protected environments. -
Q: Are firmware updates required?
A: This module does not typically require firmware updates; it is hardware-driven. -
Q: What diagnostic features does it have?
A: LED indicators for Power, Transmit, Receive, and Carrier Detect. -
Q: Is it CE certified?
A: Yes, it complies with CE and RoHS standards for industrial electronic equipment.
Related or Same-Series モデルs
| モデル | 説明 |
|---|---|
| 88VU01 | Remote Telemetry ユニット for Substation Communications |
| 81EU01E | Power Supply Module for Communication Systems |
| INNIS01 | Network Interface Module for INFI 90 Systems |
| IMMPI01 | Multi-Point Interface Module for INFI 90 |
| 88FC01 | Modem Carrier Control Module |
| 88DP02 | Dual Port Communication Module |
Popular ABB モデルs (Same ブランド)
| モデル | 説明 |
|---|---|
| CI854AK01 | PROFIBUS-DP Interface Module for AC 800M |
| PM861AK01 | AC 800M Controller CPU Module |
| TB820V2 | Module Termination ユニット (MTU) for AC 800M |
| IMDSI14 | 32-Channel Digital Input Module (INFI 90 series) |
| NTCL01-A | Communication Link Module for Network Redundancy |
| IMASO01 | Analog Output Module for INFI 90 DCS |
