Product Overview: Woodward 5439-861 Chassis
The Woodward 5439-861 Chassis is a robust enclosure component designed for use within Woodward’s range / control systems, particularly for turbine, engine, and process control applications. It serves as a mounting and protection solution for various modules, ensuring reliable connectivity and operation within industrial automation systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | Chassis/Enclosure |
| Compatibility | Woodward Digital Modules |
| Material | Industrial-grade metal alloy |
| Mounting | Rack-mounted |
| Dimensions (W×H×D) | 229 × 178 × 45 mm |
| 重量 | 1.0 kg |
| Operating Temp. | -40 °C to +70 °C |
| Certifications | Industrial standards compliant |
| Application Areas | Control panels, turbine systems |
Applications
-
Used in gas turbines, steam turbines, and diesel/gas engine control systems
-
Integrates with Woodward 505, 723, and MicroNet control platforms
-
サポートs installation / power supplies, I/O modules, communication interfaces
-
Commonly found in power generation, oil and gas, and industrial process automation
Advantages
-
High Compatibility: サポートs a wide range / Woodward modules
-
Rugged Construction: Ensures durability in harsh industrial environments
-
Compact Size: Facilitates easy integration in panel systems
-
Modular Design: Simplifies upgrades and maintenance
-
Reliable Performance: Provides solid mechanical and electrical grounding
よくある質問 (FAQ)
Q1: What is the primary use / the 5439-861 Chassis?
A1: It provides structural housing and support for Woodward modules in control systems.
Q2: Which control systems are compatible with this chassis?
A2: It supports Woodward platforms such as 505, 723, MicroNet, NetCon, and Atlas.
Q3: What materials are used in its construction?
A3: It is made from high-grade industrial metal alloy suitable for rugged environments.
Q4: Can it be mounted in a standard rack?
A4: Yes, it is designed for standard rack-mount installations.
Q5: Is it suitable for high-temperature environments?
A5: Yes, it operates reliably in temperatures from -40 °C to +70 °C.
Q6: What are its exact dimensions and weight?
A6: Dimensions are 229 × 178 × 45 mm, and it weighs 1.0 kg.
Q7: Does it support all types / Woodward modules?
A7: It is compatible with a wide range / digital control and power supply modules.
Q8: Is the chassis customizable for specific applications?
A8: While not customizable in form, it accommodates various module configurations.
Q9: How is the chassis maintained?
A9: Maintenance involves periodic inspection for physical integrity and cleaning connectors.
Q10: Can it be used in redundant systems?
A10: Yes, it supports redundant module configurations for critical systems.
Related or Similar Woodward モデルs
| モデル | 説明 | Dimensions (mm) | 重量 |
|---|---|---|---|
| 5439-862 | Enhanced Chassis for 505E | 230 × 180 × 50 | 1.1 kg |
| 5439-865 | MicroNet Chassis Frame | 240 × 185 × 48 | 1.2 kg |
| 5439-867 | Atlas Controller Chassis | 225 × 175 × 45 | 1.0 kg |
| 5439-870 | Universal Mounting Chassis | 228 × 179 × 46 | 1.0 kg |
| 5439-875 | Rack Mount for 723+ Modules | 235 × 180 × 47 | 1.1 kg |
| 5439-880 | Chassis with Integrated Grounding | 229 × 178 × 45 | 1.0 kg |
Popular Woodward モデルs
| モデル | 説明 | Dimensions (mm) | 重量 |
|---|---|---|---|
| 505 | Steam Turbine Controller | 300 × 180 × 120 | 2.5 kg |
| 723PLUS | Digital Engine Control Module | 260 × 180 × 95 | 2.3 kg |
| MicroNet Plus | High-End Control System | 350 × 250 × 150 | 5.2 kg |
| Atlas II | Compact Control System | 220 × 170 × 90 | 1.9 kg |
| 505E | Enhanced Steam Turbine Controller | 310 × 185 × 130 | 2.8 kg |
| 2301E | Load Sharing and Speed Control | 290 × 160 × 100 | 2.0 kg |
