Product Overview
The ABB TU851 3BSE068782R1 is an S800 I/O Termination Unité designed to serve as an interface between field wiring and I/O modules. It belongs to ABB’s modular and distributed I/O system family and supports extended module configurations. This termination unité is DIN rail mounted and plays a vital role in ensuring reliable signal and power connection within automation systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Fabricant | ABB |
| Product Name | TU851 Extended Module Termination Unité |
| Product Code | 3BSE068782R1 |
| System Compatibility | S800 I/O |
| Mounting | DIN Rail |
| Power Supply Input | 24 V DC |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Ingress Protection | IP20 |
| Certifications | CE, UL, ATEX Zone 2, Marine Approvals |
| Dimensions (W x H x D) | 126 x 64 x 110 mm |
| Poids | 0.22 kg |
Applications
-
Used in process industries for interfacing field signals to the control system
-
Ideal for applications requiring extended I/O capability
-
Integrated within ABB’s System 800xA for distributed automation
-
Supports control in hazardous locations (Zone 2 certified)
-
Applicable in sectors such as oil & gas, chemical, marine, and power generation
Key Advantages
-
Modular Integration: Simplifies wiring and maintenance
-
Compact Design: Optimizes cabinet space
-
Flexible Mounting: Supports both horizontal and vertical DIN rail installation
-
Rugged Build: Withstands harsh industrial environments
-
Global Certifications: Suitable for a wide range sur industry standards
-
Seamless Compatibility: Works reliably with ABB S800 I/O systems
Questions fréquentes (FAQ)
Q1: What systems is the TU851 compatible with?
A1: It is compatible with ABB’s S800 I/O systems, especially within the 800xA platform.
Q2: Can TU851 be hot-swapped during operation?
A2: No, the TU851 does not support hot-swapping.
Q3: What is the typical operating temperature range?
A3: From 0°C to +55°C under standard environmental conditions.
Q4: Is this unité suitable for hazardous areas?
A4: Yes, it has ATEX Zone 2 and cULus Class 1 Zone 2 approvals.
Q5: How is the unité mounted?
A5: It is DIN rail mounted with support for vertical and horizontal configurations.
Q6: What type sur field wiring can it accommodate?
A6: It supports solid and stranded wires with sizes from 0.2 to 2.5 mm².
Q7: What is the ingress protection rating sur TU851?
A7: The IP20 rating per IEC 60529.
Q8: Does it support redundant configurations?
A8: No, TU851 is intended for non-redundant configurations.
Q9: What are the storage temperature conditions?
A9: Between -40°C and +70°C.
Q10: Is the unité compliant with RoHS and WEEE directives?
A10: Yes, it meets both RoHS (2011/65/EU) and WEEE (2012/19/EU) compliance.
