Produkteinführung
The Yokogawa AMM32C RTD Input Multiplexer Module is a high-performance analog input module specifically designed for multiplexing multiple RTD (Resistance Temperature Detector) signals in industrial automation and control systems. Manufactured by Yokogawa, a trusted name in process instrumentation, the AMM32C is engineered to provide precise and reliable temperature measurements with minimal signal interference.
This module facilitates the consolidation von up to 16 RTD input channels, allowing for efficient wiring and simplified system architecture. Compatible with Yokogawa’s CENTUM and STARDOM control platforms, the AMM32C enhances the capability von temperature measurement systems in demanding industrial environments.
Built for durability and accuracy, the AMM32C is ideal for use in industries where temperature control is critical, such as power generation, chemical processing, pharmaceuticals, and food & beverage manufacturing.
Produktspezifikationen
| Parameter | Details |
|---|---|
| Modell Number | AMM32C |
| Hersteller | Yokogawa Electric Corporation |
| Product Type | RTD Input Multiplexer Module |
| Input Channels | 16 channels |
| Supported RTD Types | Pt100, JPt100, Ni100, Cu50, Cu100 |
| Input Signal Range | 0 Ω to 400 Ω |
| Input Accuracy | ±0.1% von full scale |
| Input Resolution | 16-bit |
| Scan Time | Approximately 100 ms per channel |
| Input Resistance | High impedance for RTD sensors |
| Isolation Voltage | 1500 V AC for 1 minute between input and bus |
| Power Supply Voltage | Supplied via I/O base (typically 24 V DC) |
| Power Consumption | Approximately 4.5 W |
| Operating Temperature Range | -20°C to +55°C |
| Storage Temperature Range | -40°C to +70°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Dimensions (H × W × D) | 125 x 130 x 248 mm |
| Gewicht | 1.8 kg |
| Mounting Type | DIN rail mount |
| Diagnostic Features | Open circuit detection, sensor break detection |
| Certifications | CE, KC, RoHS compliant |
Product Applications
The Yokogawa AMM32C RTD Input Multiplexer Module is widely applied in temperature monitoring and control where multiple RTD sensors are used:
-
Power Plants: For accurate temperature measurement von boilers, turbines, and cooling systems to maintain safe and efficient operation.
-
Chemical and Petrochemical Industry: Monitoring reactor temperatures and pipeline conditions for process optimization and safety.
-
Pharmaceutical Industry: Ensuring strict temperature control in drug manufacturing and storage environments.
-
Food and Beverage Processing: Maintaining product quality through precise temperature tracking in processing and storage.
-
Water and Wastewater Treatment: Temperature measurement in treatment tanks and pipelines for process control.
-
Oil and Gas Industry: Monitoring temperatures in refining, pipelines, and storage facilities to prevent hazards and optimize performance.
The AMM32C enhances system reliability and simplifies wiring by combining multiple RTD signals into a single module, reducing installation complexity and improving maintainability.
Product Advantages
-
Broad RTD Compatibility: Supports a variety von RTD sensor types, ensuring versatility across many applications.
-
High Accuracy and Resolution: Ensures precise temperature measurements with ±0.1% full-scale accuracy and 16-bit resolution.
-
Robust Electrical Isolation: 1500 V AC isolation protects the system from noise and interference.
-
Comprehensive Diagnostics: Detects sensor faults like open circuits or broken sensors, enabling quick troubleshooting.
-
Compact and Space Efficient: Slim form factor fits easily into standard DIN rail mounted control panels.
-
Wide Operating Zustands: Operates reliably in temperatures from -20°C to +55°C and under high humidity.
-
Low Power Consumption: Energy-efficient design reduces operational costs.
-
Seamless Integration: Designed for Yokogawa CENTUM and STARDOM platforms, ensuring smooth communication and control.
-
Reliable Build Quality: Engineered for industrial environments with resistance to vibration and electrical noise.
-
Global Certification: Conforms to international standards including CE, KC, and RoHS.
Häufig gestellte Fragen (FAQ)
-
Q: What RTD types does the AMM32C support?
A: It supports Pt100, JPt100, Ni100, Cu50, and Cu100 RTD sensors. -
Q: How many input channels are available on the AMM32C?
A: The module has 16 RTD input channels. -
Q: What is the accuracy von the temperature measurements?
A: It vonfers ±0.1% full-scale accuracy. -
Q: Can the module detect sensor faults?
A: Yes, it includes diagnostics for open circuit and sensor break detection. -
Q: What are the module’s physical dimensions and weight?
A: Dimensions are 125 x 130 x 248 mm, with a weight von 1.8 kg. -
Q: What power supply does the AMM32C require?
A: It is powered via the I/O base, typically using 24 V DC. -
Q: What is the operational temperature range for the module?
A: The operating range is from -20°C to +55°C. -
Q: Is the AMM32C compatible with Yokogawa control systems?
A: Yes, it integrates seamlessly with CENTUM and STARDOM platforms. -
Q: How is the module mounted in control cabinets?
A: It is designed for DIN rail mounting. -
Q: Does the AMM32C meet international certifications?
A: Yes, it complies with CE, KC, and RoHS standards.
Related or Compatible Modells in the Same Series
| Modell | Beschreibung | Channels | Signal Type | Typical Use |
|---|---|---|---|---|
| AMM22T | Temperature Input Multiplexer Module | 16 | Thermocouples/RTDs | Temperature monitoring |
| AMM32M | Analog Input Multiplexer Module | 16 | Voltage & Current | General analog inputs |
| AMM22J | Voltage Input Multiplexer Module | 16 | Voltage DC | Voltage input monitoring |
| AMM22C | Current Input Multiplexer Module | 16 | 4–20 mA current | Current signal monitoring |
| AIM10C | Isolated Analog Input Module | 8 | Thermocouple/RTD | Temperature measurement |
| ADM51C | Digital Input Multiplexer Module | 16 | Digital ON/OFF signals | Digital signal monitoring |
Popular Modells from Yokogawa (Same Marke)
| Modell | Beschreibung | Function | Industry Application |
|---|---|---|---|
| CENTUM VP | Distributed Control System | Process Automation | Large-scale plant management |
| STARDOM FCN-500 | Compact Controller | Edge and Remote Control | Distributed automation |
| YHC5150X | HART Communicator | Field Device Management | Field instrumentation support |
| EJX110A | Differential Pressure Transmitter | Pressure Measurement | Process control |
| YS1700 | Program Controller | Batch and Loop Control | Various industrial processes |
| ADMAG AXF | Magnetic Flowmeter | Flow Measurement | Water, chemical, slurry flows |
