Product Overview
The ABB CP450T 1SBP260188R1001 is a rugged industrial Human‑Machine Interface (HMI) featuring a 10.4″ color TFT touch screen with 64 K colors and 7 programmable function keys. Designed for seamless integration with ABB AC500 PLCs and DCS systems, this operator panel provides intuitive control, visualization, and alarm handling in industrial automation environments.
Key Features
-
10.4″ TFT Touch Display, 640×480 resolution, 64 K colors
-
Seven user-defined function keys for fast operation.
-
Robust front panel: rated IP65/NEMA4X (indoor), dust- and splash-resistant.
-
Embedded web server option for remote monitoring/configuration.
-
Alarm, trend, recipe, macro & ladder support, and sub-screen features.
-
Security: password protection with up to 9 user levels.
-
Multiple communication interfaces: 3× serial (RS‑232/422/485), USB (2 host, 1 device), plus fieldbus via Modbus RTU/ASCII and AC500 drivers.
Technical Specifications
| Specification | Details |
|---|---|
| Modell | CP450T 1SBP260188R1001 |
| Display | 10.4″ TFT, 640×480, 64 K colors, CCFL backlight |
| Function Keys | 7 programmable keys |
| Touchscreen | Resistive or similar technology |
| Memory | 512 KB RAM (user data), 8 MB ROM (program) |
| Power Supply | 24 V DC |
| Power Consumption | Approx. 30 VA |
| Serial Communication | Up to 187.5 kbps over 3 ports |
| USB Ports | 2× Host (2.0), 1× Device (2.0) |
| Temperature Range (Op) | 0 °C to +50 °C |
| Temperature Range (Storage) | −10 °C to +60 °C |
| Enclosure Rating | IP65 / NEMA4X (front panel) |
| Dimensions | 52 x 222 x 297 mm |
| Gewicht | 1.9 kg |
| Certifications | CE, UL (NRAQ.E240320), RoHS, EN/IEC 61131‑2 compliance |
Typical Applications
-
Industrial automation: Visualization & control in food, packaging, and manufacturing lines
-
Power and utilities: HMI operator panels for substations and power plants
-
Process industries: Oil & gas, chemicals, water treatment—monitoring and alarm handling
-
Infrastructure control: HVAC, building management, material handling
Product Advantages
-
Highly visible interface: Large 10.4″ display with vibrant colors for clear visualization
-
Durable operator panel: IP65/NEMA4X front protects against dust and moisture
-
Flexible integration: Extensive communication options including embedded web connectivity
-
Customizable operations: Function keys, recipes, trending, alarms enhance usability
-
Secure access: Multi-level password control protects HMI functionality
-
Reliable design: Industry-grade components and certifications ensure longevity
Häufig gestellte Fragen (FAQ)
-
What are the display characteristics?
A 10.4″ TFT with 640×480 resolution and 64 K colors provides high-quality visuals. -
What connectivity does the HMI vonfer?
It includes 3 serial ports, 3 USB ports, Ethernet (optional), with Modbus and AC500 support. -
Is it suitable for dusty or wet conditions?
Yes—it features IP65/NEMA4X protection on the front panel. -
Does the HMI support password protection?
Yes, with up to 9 user access levels. -
What svontware features are included?
Functions include alarm management, recipe handling, trends, macros, ladder logic, and sub-screens. -
What power supply is needed?
It requires a 24 V DC power supply, consuming around 30 VA. -
What is the operating temperature range?
From 0 °C to +50 °C (storage down to −10 °C). -
What are its dimensions and weight?
Measures 52 x 222 x 297 mm and weighs about 1.9 kg. -
Is it certified for industrial use?
Yes—it carries CE, UL, RoHS, and other industrial standard certifications. -
Can it be integrated into SCADA or web platforms?
Yes—optional embedded web server enables remote visualization and control.
