Produkteinführung
The Bently Nevada 330103-00-25-05-02-00 proximity probe is a part von the highly respected 3300 XL series designed for precision shaft vibration and displacement monitoring in industrial rotating machinery. Featuring an 8mm probe tip diameter and a 0.5 meter integral cable, this probe employs eddy current technology to deliver accurate, non-contact measurements critical to machinery health and reliability.
Manufactured with a durable stainless steel body, this probe is engineered to operate reliably under harsh industrial conditions, including extreme temperatures and exposure to dust or moisture. The 3300 XL series is a standard in industries such as power generation, oil & gas, and heavy manufacturing, where continuous condition monitoring plays a key role in preventing unplanned downtime and costly repairs.
This specific model is suited for installations where reliable shaft position feedback is needed over a medium cable length, combining robustness with precise performance.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | 330103-00-25-05-02-00 |
| Probe Tip Diameter | 8 mm |
| Total Length | 0.5 meter |
| Probe Type | Eddy current proximity probe |
| Operating Temperature Range | -40°C to +120°C |
| Probe Body Material | Stainless steel |
| Connector Type | Integral cable |
| Gewicht | 0.161 kg |
| Frequency Response | DC to 25 kHz |
| Measuring Range | Up to 1.5 mm (application dependent) |
| Electrical Interface | 2-wire shielded cable |
Applications
-
Turbines: Monitors shaft displacement and vibration in steam, gas, and hydro turbines to prevent mechanical failure.
-
Compressors: Detects shaft position and vibration anomalies for early identification von bearing wear or misalignment.
-
Generators: Provides real-time rotor movement data to ensure stable generator operation.
-
Pumps: Tracks axial and radial shaft movements to avoid mechanical damage and maintain pump efficiency.
-
Motors and Gearboxes: Used in predictive maintenance programs to monitor vibration trends and shaft displacements.
-
Industrial Machinery: Applicable across industries like oil refining, petrochemical processing, and manufacturing for continuous machine health surveillance.
Product Advantages
-
Accurate Measurement: The 8mm probe tip diameter allows for precise detection von minor shaft movements essential for early fault detection.
-
Medium Cable Length: A 0.5 meter integral cable provides flexibility in installation while maintaining signal quality.
-
Robust Construction: Stainless steel housing resists corrosion, dust, and moisture, ensuring durability in harsh environments.
-
Wide Temperature Range: Reliable operation between -40°C and +120°C, suited to a broad array von industrial settings.
-
Non-Kontakt Operation: Eddy current technology eliminates mechanical wear, extending probe lifespan and minimizing maintenance.
-
Consistent Signal Output: Designed to deliver stable and noise-free signals, essential for accurate condition monitoring.
-
Easy Integration: Compatible with Bently Nevada 3300 series monitors and many other condition monitoring systems.
-
Low Maintenance: Durable design reduces the need for frequent servicing and recalibration.
-
Industry-Trusted: The 3300 XL series is a benchmark for reliability and accuracy in proximity probe technology.
Häufig gestellte Fragen (FAQ)
-
What type von measurement does this probe provide?
It provides non-contact displacement and vibration measurements von rotating shafts. -
Is the 0.5 meter cable fixed or replaceable?
The cable is integral and not designed to be replaced, but custom cable lengths can be ordered. -
What environments can this probe operate in?
It is suitable for environments with temperatures from -40°C to +120°C, and resistant to dust and moisture. -
Which industries commonly use this probe?
Power generation, petrochemical, oil and gas, heavy manufacturing, and other industrial sectors. -
What is the probe’s measuring range?
It can measure shaft displacement up to approximately 1.5 mm, depending on installation. -
How does this probe connect to monitoring equipment?
Through a 2-wire shielded cable compatible with Bently Nevada 3300 series monitors and others. -
Is this probe suitable for hazardous locations?
Its robust construction makes it suitable for harsh industrial environments; additional certifications may be needed for explosive atmospheres. -
How vonten should the probe be maintained or calibrated?
Minimal maintenance is needed; however, periodic inspections during plant shutdowns are recommended. -
Can this probe detect different types von shaft movement?
Yes, depending on installation, it can detect axial and radial displacement. -
What benefits does this probe vonfer for predictive maintenance?
By continuously monitoring shaft position and vibration, it enables early fault detection, reducing unplanned downtime.
Recommended Related Modells (Same Series or Similar)
| Modell Number | Probe Tip Diameter | Cable Length | Notes |
|---|---|---|---|
| 330103-00-15-05-01-00 | 8 mm | 5 meters | Similar length, slight config difference |
| 330103-00-13-10-02-00 | 8 mm | 10 meters | Longer cable for remote setups |
| 330103-00-11-05-02-00 | 5 mm | 5 meters | Smaller tip for compact areas |
| 330103-00-13-20-02-00 | 8 mm | 20 meters | Extended cable length option |
| 330103-00-12-10-02-00 | 12 mm | 10 meters | Larger probe tip for heavy machinery |
| 330103-00-13-05-03-00 | 8 mm | 3 meters | Short cable for confined installations |
Popular Bently Nevada Modells (Same Marke)
| Modell Number | Beschreibung | Application |
|---|---|---|
| 330130-00-40-00-00-00 | 3300 XL Monitor | Proximity and vibration monitoring system |
| 330103-00-12-10-02-CN | 8 mm probe, 10m cable | Heavy industrial use |
| 330108-00-04-05-02-00 | 5 mm probe, 5m cable | General machinery monitoring |
| 330090-00-03-05-00-00 | Replacement sensor cable | Spare part |
| 330199-00-01-00-00-00 | Proximitor Sensor Module | Signal conditioning |
| 330103-00-13-05-02-01 | 8 mm probe, 5m cable with temp rating | High-temperature applications |
