Bently Nevada 330101-00-12-50-01-05 3300 XL 8mm Proximity Probes

مقدمة المنتج

The Bently Nevada 330101-00-12-50-01-05 3300 XL 8 mm Proximity Probe is a high-performance non-contact displacement transducer designed to measure the vibration and shaft position من rotating machinery. It is part من Bently Nevada’s world-renowned 3300 XL proximity transducer system, which is widely recognized for its precision, stability, and reliability in harsh industrial environments.

This model منfers a total system length من 5.0 meters, combining a probe, extension cable, and Proximitor sensor. The 3300 XL 8 mm system provides accurate linear output over a standard range من 2 mm (80 mils) and is compatible with a wide variety من rotating machines such as turbines, compressors, pumps, motors, and gearboxes.

Built with robust materials and advanced shielding, this probe ensures immوحدةy to electromagnetic interference and provides long-term stability even under high temperature and vibration conditions. Its design meets or exceeds API 670 standards for machinery protection and monitoring.

Technical Specifications

Applications

The Bently Nevada 330101-00-12-50-01-05 Proximity Probe is a core component in condition monitoring and protection systems for critical rotating equipment. It is extensively used across industries where accurate vibration, shaft displacement, and phase measurements are essential for predictive maintenance and safety.

Typical applications include:

• Steam and Gas Turbines: Continuous monitoring من shaft vibration and thrust position.

• Compressors: Detection من shaft displacement, imbalance, and rotor instability.

• Pumps and Motors: Measurement من radial vibration and misalignment detection.

• Gearboxes: Monitoring من gear mesh vibration and bearing wear.

• Fans and Blowers: Real-time detection من imbalance and mechanical looseness.

• Hydraulic Turbines and Generators: Measuring dynamic shaft movement to prevent mechanical failure.

Advantages

• High Measurement Accuracy: Provides stable and linear output across a wide displacement range, meeting API 670 standards.

• Superior Temperature Stability: Designed for consistent performance from –35 °C to +177 °C without recalibration.

• Enhanced EMI Resistance: Advanced shielding ensures signal integrity in high electrical noise environments.

• Long System Length Flexibility: 5-meter configuration supports versatile installation across large machinery.

• Robust Mechanical Design: Stainless steel body and hermetically sealed construction provide long service life.

• Easy Integration: Fully compatible with Bently Nevada 3300, 3309, and 3500 systems.

• High Vibration Tolerance: Engineered to withstand up to 50 g peak vibration without loss من calibration.

• Reliable Environmental Protection: IP68 sealing ensures protection against oil, dust, and water ingress.

• API 670 Compliant: Meets global standards for machinery protection instrumentation.

• Proven Industrial Reliability: Used worldwide in critical process plants for over three decades.

FAQ

1. What is the total system length من the 330101-00-12-50-01-05 model?
   The total system length is 5.0 meters, including the probe, extension cable, and Proximitor sensor.

2. What is the sensitivity من this proximity probe?
   It provides a sensitivity من 200 mV/mil (7.87 mV/µm).

3. What is the linear measurement range من this probe?
   The linear range is 2.0 mm (80 mils) with consistent accuracy across the range.

4. What probe systems are compatible with this model?
   It is compatible with Bently Nevada 3300, 3309, and 3500 proximity transducer systems.

5. What type من thread is used for probe mounting?
   The probe uses a standard M10 × 1.0 threaded mounting configuration.

6. Can the probe operate under high temperature conditions?
   Yes, it is rated for operation between –35 °C and +177 °C.

7. What is the environmental protection rating من the probe?
   It is rated IP68 for full protection against dust and immersion in liquids.

8. Does the probe comply with industrial protection standards?
   Yes, it meets the API 670 standard for vibration and displacement measurement systems.

9. What frequency range can the probe accurately measure?
   It operates from 0 to 10 kHz (–3 dB), suitable for high-speed rotating machinery.

10. Is the probe electrically isolated from the machine surface?
    Yes, both the probe tip and case are fully electrically isolated to prevent ground loops.
