مقدمة المنتج
The Allen-Bradley 1746-OBP8 is a high-current DC digital output module designed for the SLC 500 programmable controller platform. It is specifically built for applications that require higher output current capability compared to standard transistor output modules, making it suitable for driving demanding DC loads.
This module provides 8 output channels arranged in groups, with 4 points per common, allowing flexible wiring and load distribution. It operates within a 20.4–26.4V DC range, making it ideal for typical 24V DC industrial systems. The module is capable من delivering higher current outputs, enabling direct control من devices such as solenoids, contactors, and other high-load DC equipment.
Unlike standard protected modules, the 1746-OBP8 is designed without electronic protection, which allows for higher current handling but requires proper external protection design. Its screw terminal configuration ensures secure wiring connections, making it suitable for applications where reliability and robust electrical connections are critical.
مواصفات المنتج
| Parameter | الوصف |
|---|---|
| الشركة المصنعة | Allen-Bradley |
| Series | SLC 500 |
| Module Type | DC Digital Output Module |
| Catalog Number | 1746-OBP8 |
| Module Classification | High-Current Output Module |
| Number من Channels | 8 Outputs |
| Output Type | DC Transistor Output (Sourcing) |
| Output Voltage Range | 20.4–26.4V DC |
| Nominal Voltage | 24V DC |
| Current per Channel | 0.135 A |
| Output Power Range | 0.675–3.08 W |
| Grouping | 4 Points per Common |
| Protection | No Electronic Protection |
| Connection Type | Screw Terminal |
| Backplane Current Consumption | Approx. 0.095 A |
| Isolation | Group isolation (backplane to field) |
| Operating Temperature | 0 to 60°C |
| Storage Temperature | -40 to 85°C |
| Installation | SLC 500 Chassis |
| Wiring الفئة | الفئة 1 |
| Dimensions | 144.5 × 34.6 × 130.18 mm |
| الوزن | 0.45 kg |
Applications
● High-Current DC Load Control
Designed to drive loads that require higher current than standard output modules, such as solenoids and heavy-duty relays.
● Industrial Control Systems
Used in automation panels where robust DC output capability is required for reliable equipment operation.
● Material Handling Equipment
Controls high-load devices in conveyors, lifting systems, and positioning mechanisms.
● Machine Control Applications
Suitable for machinery requiring stable and higher-power DC switching.
● Custom Control Architectures
Provides flexibility in systems where external protection and custom load management are implemented.
Advantages
● High Current Output Capability
الدعمs higher load demands compared to standard DC output modules.
● Flexible Grouping Configuration
4 points per common allows efficient wiring and load distribution.
● Direct Control من Heavy Loads
Reduces the need for intermediate relays in some applications.
● Robust Screw Terminal Connections
Ensures secure and stable wiring in industrial environments.
● Simplified Power Design
Optimized for 24V DC systems commonly used in automation.
● Adaptable System Integration
Suitable for customized systems where external protection is applied.
