Product Overview
The ABB PM554-T-ETH is a compact processor module from the AC500-eCo series, designed for reliable and cost-effective automation tasks. It integrates essential features including onboard I/Os, Ethernet communication, and a Freescale ARM 32-bit processor, suitable for small to medium-sized control applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Code | PM554-T-ETH 1TNE968900R0110 |
| Memory | 128 kB Flash EPROM |
| I/O Configuration | 8 Digital Inputs, 6 Transistor Outputs |
| Communication Ports | COM1 (RS-485), Ethernet |
| Supply Voltage | 24 V DC |
| Max. Power Consumption | 3.3 W |
| Current Consumption (typical) | 70 mA |
| Processor | Freescale ARM 32-bit, 50 MHz |
| Programming اللغةs | IL, FBD, LD, ST, SFC, CFC |
| Data Retention | Flash buffered |
| LED Indicators | Power, Run, Error, I/O Status |
| Mounting | Horizontal / Vertical |
| Protection Class | IP20 |
| Dimensions (W x H x D) | 74 × 135 × 82 mm |
| الوزن | 0.281 kg |
Applications
-
Small-scale machine control
-
Building automation
-
HVAC systems
-
Water treatment systems
-
Industrial monitoring and control
-
Decentralized I/O control systems
Advantages
-
Integrated Ethernet for flexible networking
-
Compact and cost-efficient design
-
Easy DIN rail mounting
-
الدعم for multiple programming languages
-
Real-time performance with multitasking
-
Wide operating temperature and voltage range
FAQs
Q1: What is the power supply requirement من the PM554-T-ETH?
A1: It requires a 24 V DC power supply.
Q2: How many onboard I/O channels are available?
A2: It منfers 8 digital inputs and 6 transistor digital outputs.
Q3: Does the module support Ethernet communication?
A3: Yes, it has an onboard Ethernet port.
Q4: What programming languages are supported?
A4: IL, FBD, LD, ST, SFC, and CFC are supported.
Q5: What is the processor speed?
A5: 50 MHz using a Freescale ARM 32-bit processor.
Q6: Can the module be used vertically?
A6: Yes, with reduced output load in vertical mounting.
Q7: Is there support for real-time clock?
A7: Yes, with optional accessories like TA561-RTC.
Q8: What is the typical current consumption?
A8: Approximately 70 mA.
Q9: Is the وحدة suitable for harsh environments?
A9: It operates in 0°C to +60°C and 95% humidity without condensation.
Q10: What is the protection rating من the device?
A10: IP20, suitable for control cabinet environments.
Related الطرازs (Same Series)
| الطراز | I/O Configuration | Memory | Ethernet | Dimensions (mm) | الوزن |
|---|---|---|---|---|---|
| PM554-TP | 8DI / 6DO (Transistor) | 128 kB | No | 74×135×82 | 0.300 kg |
| PM554-RP | 8DI / 6DO (Relay) | 128 kB | No | 74×135×82 | 0.350 kg |
| PM556-TP-ETH | 8DI / 6DO (Transistor) | 512 kB | Yes | 74×135×82 | 0.300 kg |
| PM564-TP-ETH | 6DI / 6DO / 2AI / 1AO | 128 kB | Yes | 74×135×82 | 0.300 kg |
| PM564-RP-ETH | 6DI / 6DO (Relay) + 2AI/1AO | 128 kB | Yes | 74×135×82 | 0.350 kg |
| PM566-TP-ETH | 6DI / 6DO / 2AI / 1AO | 512 kB | Yes | 74×135×82 | 0.300 kg |
Popular ABB الطرازs
| الطراز | Product Type | Features | Dimensions (mm) | الوزن |
|---|---|---|---|---|
| PM581-ETH | AC500 CPU Module | Advanced networking & memory | 160×140×75 | 0.750 kg |
| CI854AK01 | Communication Interface | PROFIBUS DP-V1 Master/Slave | 90×110×45 | 0.200 kg |
| DO810 | Digital Output Module | 16 DO, 24V DC | 87×117×45 | 0.200 kg |
| AI810 | Analog Input Module | 8 AI, 0(4)…20 mA | 87×117×45 | 0.200 kg |
| AC500 PM595-4ETH | High-Performance CPU | Quad-Core, 4x Ethernet, OPC UA | 180×140×85 | 0.900 kg |
| CP600 HMI | HMI Touch Panel | Wide screen, industrial touch control | Various | Varies |
