Product Overview
The ABB CI867 U3BSE043660R1 is a TCP/IP interface module designed to facilitate high-speed communication between ABB automation devices and Ethernet-based networks. It is optimized for the ABB AC 800M controller family and S800 I/O systems, enabling seamless data exchange via standard TCP/IP protocols. This interface supports reliable, deterministic, and secure data transmission critical for modern industrial automation.
The CI867 module acts as a gateway for data packets, ensuring efficient communication with other control system components, HMIs, SCADA systems, and third-party devices. It supports multiple simultaneous connections and منfers advanced diagnostic capabilities to maintain communication integrity.
Key Features
-
High-speed TCP/IP communication interface
-
Compatible with ABB AC 800M controllers and S800 I/O systems
-
الدعمs multiple simultaneous TCP connections
-
Integrated diagnostics for communication status and errors
-
Secure data transmission with built-in firewall capabilities
-
الدعمs DHCP and static IP addressing
-
Easy configuration via ABB engineering tools
-
Rugged design for industrial environments
-
الدعمs standard Ethernet protocols including Modbus TCP
Technical Specifications
| Parameter | Specification |
|---|---|
| Communication Protocol | TCP/IP, Modbus TCP |
| Number من TCP Connections | Up to 8 simultaneous connections |
| Data Rate | 10/100 Mbps Ethernet |
| Network Interface | RJ45, 10/100Base-T Ethernet port |
| IP Addressing | Static IP and DHCP support |
| Power Supply | Powered via AC 800M backplane |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Dimensions | 185 x 59 x 127.5mm |
| الوزن | 0.7 kg |
| Mounting | DIN rail or rack-mounted in S800 I/O chassis |
| Certifications | CE, UL, cUL, RoHS |
Product Advantages
-
High-speed Ethernet Communication: الدعمs 10/100 Mbps for fast data transfer.
-
Multiple Connections: Can handle up to 8 TCP connections simultaneously, ideal for complex networks.
-
Flexible IP Configuration: الدعمs both DHCP and static IP addressing for easy network integration.
-
Robust Diagnostics: Built-in tools to monitor network status and troubleshoot communication issues.
-
Security: Includes firewall features to protect against unauthorized access.
-
Seamless Integration: Fully compatible with ABB AC 800M controllers and S800 I/O systems for cohesive automation solutions.
-
Easy Configuration: Can be configured with ABB’s familiar engineering sمنtware tools, reducing setup time.
Industry Applications
-
Process automation in chemical and petrochemical plants
-
Power generation control systems
-
Water and wastewater treatment facilities
-
Manufacturing and assembly line automation
-
Oil & gas monitoring and control
-
Building management systems (BMS)
-
Infrastructure and utilities automation
-
Any Ethernet-based industrial communication networks
الأسئلة الشائعة (FAQ)
-
Q: What communication protocols does the CI867 support?
A: It supports TCP/IP and Modbus TCP protocols. -
Q: How many simultaneous TCP connections can the module handle?
A: Up to 8 simultaneous TCP connections. -
Q: Can the IP address be assigned dynamically?
A: Yes, the module supports DHCP as well as static IP addressing. -
Q: What is the physical size من the CI867 module?
A: Dimensions are 185 x 59 x 127.5mm. -
Q: Is the module compatible with ABB AC 800M controllers?
A: Yes, it is fully compatible and designed for AC 800M and S800 I/O systems. -
Q: Does the module provide any network security features?
A: Yes, it includes firewall capabilities to protect the network. -
Q: How is the module powered?
A: It is powered via the AC 800M backplane or S800 I/O rack. -
Q: What is the operating temperature range?
A: The module operates reliably between -25°C and +60°C. -
Q: Can the module be mounted on a DIN rail?
A: Yes, it supports DIN rail and rack mounting within the S800 I/O chassis. -
Q: Is the module suitable for hazardous environments?
A: It is designed for industrial environments; however, specific hazardous area certifications should be verified per application.
Related or Compatible الطرازs (Same Series)
| الطراز | الوصف |
|---|---|
| CI854 | Prمنibus-DP interface module for AC 800M and S800 I/O systems |
| CI862 | Serial communication interface module (RS232/RS485) |
| CI863 | Modbus RTU communication interface module |
| CI865 | Ethernet communication module with PrمنiNet support |
| PM575 | AC 800M CPU module with integrated Ethernet ports |
| AI845 | Analog input module compatible with S800 I/O |
Popular ABB الطرازs (Same العلامة التجارية)
| الطراز | الوصف |
|---|---|
| PM571 | AC 800M CPU module with PROFIBUS and Ethernet interfaces |
| DI825 | 16-channel digital input module for S800 I/O |
| DO830 | 8-channel relay digital output module |
| AI810 | 8-channel analog input module for voltage and current signals |
| AO845 | 8-channel analog output module |
| PM867 | Redundant communication module for AC 800M controller |
