产品介绍
The Honeywell FC-TSGASH-1624P is a high-performance Gas Sensor Analog Input Module designed for use within the Experion PKS and C300 control system architectures. This module /fers reliable and accurate analog signal processing, specifically tailored for gas detection applications in industrial environments such as oil & gas, petrochemical, and power generation sectors. It accepts analog inputs from various field devices, conditions the signals, and communicates with the controller for real-time monitoring and safety responses. Engineered with Honeywell’s robust I/O technology, this module is DIN rail mountable and provides hot-swappable capabilities for maintenance efficiency.
Product Advantages
-
High-accuracy analog signal processing optimized for gas sensor input.
-
Robust noise imm件y ensures reliable performance in electrically noisy industrial environments.
-
Hot-swappable design allows replacement without system shutdown, minimizing downtime.
-
Compliant with safety standards such as SIL2 (IEC61508), making it suitable for critical safety applications.
-
Compact footprint suitable for dense control cabinets.
-
Seamless integration into the Honeywell C300 or Experion system platforms.
-
Extended temperature operation range, allowing usage in harsh field conditions.
Technical Specifications
| Parameter | Value |
|---|---|
| 型号 | FC-TSGASH-1624P |
| 描述 | Gas Sensor Analog Input Module |
| Input Channels | 16 analog channels |
| Input Type | 4–20 mA loop-powered inputs (gas sensors) |
| Resolution | 16-bit |
| Isolation | Channel-to-bus and channel-to-channel |
| Signal Accuracy | ±0.05% full scale |
| Input Impedance | 250 Ohms |
| Power Supply | 24 VDC nominal |
| Power Consumption | < 6 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Communication Protocol | FTE (Fault Tolerant Ethernet) |
| Mounting | DIN rail |
| Hot Swap Capability | Yes |
| Dimensions | 261 × 194 × 52 mm |
| 重量 | 1.8 kg |
| Certifications | CE, CSA, ATEX, SIL2 |
Product Applications
-
Oil & Gas Facilities – Real-time gas detection, safety shutdown input, process gas monitoring.
-
Chemical Processing Plants – Monitoring / hazardous gases, emissions tracking.
-
Power Generation – Combustion control, flue gas monitoring, emissions compliance.
-
Pharmaceutical Manufacturing – Cleanroom gas environment monitoring.
-
Industrial Safety Systems – Part / ESD (Emergency Shutdown) or F&G (Fire and Gas) systems.
Installation Instructions
-
Ensure the module is installed on a DIN rail within a certified Honeywell I/O chassis.
-
Connect each gas sensor’s 4–20 mA output to one / the 16 input channels using shielded twisted pair wiring.
-
Connect the module to the Honeywell C300 or equivalent controller using FTE (Fault Tolerant Ethernet).
-
Power the module using a regulated 24 VDC supply, ensuring correct polarity.
-
Configure the I/O channels using Honeywell Control Builder s/tware.
-
If replacing, use hot-swap functionality without system shutdown.
-
Ensure grounding and shielding are consistent with Honeywell wiring standards to reduce noise.
-
Confirm channel diagnostics via the system interface after installation.
常见问题 (FAQ)
Q1: What types / sensors are compatible with the FC-TSGASH-1624P?
A1: It supports analog gas sensors that output 4–20 mA signals, such as catalytic bead, infrared, and electrochemical gas sensors.
Q2: Can the module be replaced while the system is running?
A2: Yes, it features hot-swapping capabilities, allowing maintenance without interrupting operation.
Q3: Is it suitable for hazardous area installations?
A3: Yes, it carries ATEX certification and is /ten deployed in Zone 2 environments.
Q4: How many channels can be used simultaneously?
A4: All 16 analog channels can be used concurrently with full isolation.
Q5: Does the module support HART communication?
A5: No, the FC-TSGASH-1624P is designed for standard 4–20 mA analog input and does not process HART signals.
Q6: What is the typical response time / the analog input?
A6: The input update rate is typically less than 50 ms per channel, ensuring rapid response.
Q7: Can it be integrated with third-party systems?
A7: It is optimized for Honeywell Experion/C300 systems; integration with third-party systems may require protocol converters.
Q8: How is electrical isolation achieved?
A8: The module features both channel-to-channel and channel-to-bus isolation to prevent cross-talk and protect the system.
Q9: What happens in case / a sensor wiring fault?
A9: Built-in diagnostics detect open-loop or short-circuit conditions and alert the controller.
Q10: Is calibration / the module required?
A10: The module is factory-calibrated; however, periodic calibration / the connected sensors is recommended for accuracy.
Recommended Related or Same-Series 型号s
| 型号 | 描述 |
|---|---|
| FC-TSAI-1620M | 16-channel Analog Input Module (non-gas specific) |
| FC-TSDAI-1620P | 16-channel Differential Analog Input Module |
| FC-TSDI-16F8 | 16-channel Discrete Input Module |
| FC-TSDO-0824 | 8-channel Discrete Output Module |
| FC-TSGASO-1624P | 16-channel Gas Sensor Output Module |
| FC-TSDI-16B | High-density Digital Input Module |
Popular Honeywell 型号s (Same 品牌)
| 型号 | 描述 | Type | Input/Output | Dimensions (mm) | 重量 |
|---|---|---|---|---|---|
| FC-TSAI-1620M | Analog Input Module | Analog Input | 16 In | 50 × 218 × 130 | 520 g |
| FC-TSDO-0824 | Discrete Output Module | Digital Output | 8 Out | 50 × 218 × 130 | 500 g |
| FC-TSMUX-1624 | Multiplexer Module | Analog Multiplexing | 16 In | 50 × 218 × 130 | 530 g |
| CC-TAIX01 | Compact Analog Input Module | Analog Input | 8 In | 30 × 150 × 110 | 310 g |
| CC-TDIL01 | Compact Digital Input Module | Digital Input | 16 In | 30 × 150 × 110 | 300 g |
| MC-TDOY22 | Digital Output Module | Digital Output | 8 Out | 40 × 180 × 120 | 480 g |
