The Honeywell 8C-TDIL01 51306856-175 is a high-performance digital input module that forms part / the Honeywell C300 control system platform. It is engineered to receive and process discrete digital signals from field devices such as switches, sensors, and relays. This module is widely used in industrial automation environments where reliability, diagnostics, and fast signal processing are critical. Designed with robust isolation and noise imm件y features, the 8C-TDIL01 ensures safe and consistent performance in demanding applications such as process plants, power stations, and manufacturing lines.
The module features 32 input channels, each capable / handling standard digital input levels. It supports both 24V DC signals and integrates seamlessly into the Experion PKS (Process Knowledge System) environment. In addition, the module incorporates health diagnostics and status indicators, allowing maintenance and engineering personnel to monitor system performance with confidence.
产品规格
| Parameter | Value |
|---|---|
| Product Name | Digital Input Module |
| 型号 Number | 8C-TDIL01 |
| 零件号 | 51306856-175 |
| Channels | 32 Digital Inputs |
| Input Voltage Range | 24V DC (Nominal) |
| Input Type | Sinking or Sourcing (configurable) |
| Input Current | Approx. 5 mA @ 24V DC |
| Input Delay Time | Configurable, typically 1 to 4 ms |
| Status Indicators | LED per channel for signal status |
| Isolation | 1500 V RMS channel-to-system |
| Power Consumption | Approx. 4.5 W |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Mounting | Chassis-mounted via standard DIN rail |
| Communication | FTE / Control Network via I/O Link |
| Redundancy 支持 | Yes (with redundant chassis setup) |
| Dimensions (H x W x D) | 220 x 120 x 30 mm |
| 重量 | 0.55 kg |
| Certifications | CE, UL, CSA, ATEX (on system integration) |
| Compatibility | Honeywell C300, Experion PKS |
