产品介绍
The ABB PP D115 A102 3BHE017628R0102 AC800 Control Module is a high-performance central processing 件 (CPU) used in ABB’s AC800 distributed control system (DCS) platform. This module serves as the main processing and communication hub within automation networks, enabling precise control, reliable data processing, and robust connectivity across multiple industrial systems.
The PP D115 A102 module is designed for complex automation environments that require high reliability, rapid data exchange, and scalable control architectures. Built with ABB’s industrial-grade hardware standards, it combines powerful computation capability with flexible network interfaces, ensuring consistent real-time performance even under demanding operating conditions.
It is equipped with redundant communication ports, advanced I/O handling, and secure firmware architecture, allowing it to serve as both a primary and backup controller within critical automation systems. The module integrates seamlessly with ABB’s Control Builder s/tware suite and supports the IEC 61131-3 standard programming languages, allowing easy customization for process, motion, and discrete control applications.
Technical Specifications
| Parameter | 描述 |
|---|---|
| Product 型号 | PP D115 A102 |
| 零件号 | 3BHE017628R0102 |
| System Series | ABB AC800 Control System |
| Processor Type | 32-bit industrial-grade processor |
| Clock Frequency | 400 MHz |
| System Memory (RAM) | 64 MB SDRAM |
| Flash Memory | 32 MB |
| Non-Volatile Memory | 1 MB EEPROM for configuration and diagnostics |
| Communication Ports | 2 × Ethernet, 1 × PROFIBUS-DP, 1 × RS-485/RS-232 |
| 支持ed Communication Protocols | TCP/IP, Modbus RTU/TCP, SNMP, ABB proprietary protocol |
| 支持ed I/O Channels | Up to 1024 (depending on I/O module configuration) |
| Power Supply Voltage | 24 VDC nominal (18–30 VDC range) |
| Power Consumption | 10 W (typical) |
| Diagnostics | Built-in self-test, LED indicators, error log memory |
| System Redundancy | Fully supported with hot-swappable operation |
| Protection Features | Short-circuit, reverse polarity, and overvoltage protection |
| Mounting Type | DIN-rail or backplane mounting |
| Cooling Method | Passive (natural convection) |
| Enclosure Material | Aluminum alloy with anti-corrosion coating |
| Operating Temperature Range | -25°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 10–150 Hz, amplitude 0.5 mm |
| Certifications | CE, UL, and RoHS compliant |
| S/tware Compatibility | ABB Control Builder M, AC800M system engineering tools |
| Firmware Upgrade Method | Via Ethernet interface |
| Dimensions | 450 x 100 x 150 mm |
| 重量 | 2.8 kg |
Product Applications
The ABB PP D115 A102 3BHE017628R0102 is specifically engineered for distributed and modular control architectures across multiple industries. It is commonly used as a central control processor or as part / a redundant control pair in advanced automation systems.
-
Power Generation Plants – For turbine, generator, and auxiliary equipment control, as well as energy management systems.
-
Oil & Gas Industry – Used in upstream and downstream automation, compressor control, and /fshore platform systems.
-
Chemical & Petrochemical Processing – Controls reaction sequences, batch operations, and process interlocks.
-
Steel and Metal Manufacturing – Manages rolling mills, furnaces, and automated cooling systems.
-
Pulp & Paper Production – Handles continuous process control for pulp bleaching, paper drying, and cutting operations.
-
Marine & Offshore Automation – Integrated into propulsion, ballast control, and engine room monitoring systems.
Its flexibility, multi-protocol communication support, and real-time processing capabilities make it a preferred choice in mission-critical industrial environments requiring continuous uptime and process integrity.
Product Advantages
-
High-Speed Processing Power
The module’s 400 MHz industrial processor ensures deterministic and precise control cycles for high-speed automation tasks. -
Wide Communication Compatibility
Equipped with multiple interfaces including Ethernet, PROFIBUS, and Modbus, it enables smooth integration with ABB and third-party systems. -
Industrial-Grade Durability
The reinforced housing, conformal coating, and wide temperature tolerance ensure reliable operation in harsh field conditions. -
Redundancy 支持
Offers dual configuration for hot standby redundancy, ensuring system availability even during hardware faults. -
Scalable Architecture
支持s seamless expansion / I/O modules and communication 件s, allowing easy system upgrades. -
Comprehensive Diagnostics
Built-in monitoring tools with LED status indication and detailed error logs simplify maintenance and troubleshooting. -
Low Maintenance Requirement
Passive cooling and energy-efficient design reduce failure risk and minimize operational costs. -
S/tware Integration
Fully compatible with ABB Control Builder M for programming, system design, and online diagnostics.
FAQ
-
What role does the PP D115 A102 play in the AC800 control system?
It functions as the main CPU, managing logic execution, data exchange, and communication between field devices and supervisory systems. -
Does this module support redundancy operation?
Yes, the PP D115 A102 supports full redundancy, including processor synchronization and hot-swappable operation. -
Which communication protocols are compatible with this module?
It supports TCP/IP, Modbus RTU/TCP, PROFIBUS-DP, and ABB proprietary protocols for flexible system integration. -
How is configuration performed for the module?
Configuration and logic programming are completed through ABB’s Control Builder M s/tware suite using IEC 61131-3 languages. -
Can the module communicate with third-party devices?
Yes, it can communicate with other manufacturers’ PLCs and devices via Modbus or Ethernet protocols. -
What diagnostic functions are available?
It includes self-diagnostic routines, system status LEDs, event logging, and communication error tracking. -
How does the module handle I/O expansion?
The PP D115 A102 supports modular I/O extension through the ABB system bus, providing scalable system capacity. -
Is the module suitable for installation in high-vibration environments?
Yes, it complies with industrial vibration standards, making it ideal for power, marine, and heavy industry applications. -
How can firmware be updated?
Firmware updates are done securely through the Ethernet service port using ABB’s maintenance tools. -
What is the input voltage range supported by the module?
It operates within a range / 18–30 VDC, /fering flexibility for industrial power systems.
Recommended Related 型号s (Same Series)
| 型号 | 描述 | Series | 重量 |
|---|---|---|---|
| PP D113 B03-26-100100 3BHE023584R2625 | Standard AC800 CPU 单位 | AC800 | 0.88 kg |
| PP D113 B03-23-111615 3BHE023584R2365 | Enhanced Performance Control Module | AC800 | 0.85 kg |
| PP D114 B1022 3BHE020570R1022 | High-Reliability CPU Module | AC800 | 0.90 kg |
| PP D200 A101 3BHE019633R0101 | System Controller Board | AC800 | 0.89 kg |
| PP D234 A101 3BHE024820R0101 | Interface and Communication Module | AC800 | 0.90 kg |
| PP D115 A101 3BHE017628R0001 | Standard Control Processor | AC800 | 0.89 kg |
Popular ABB 型号s (Same 品牌)
| 型号 | 描述 | Product Type | 重量 |
|---|---|---|---|
| PM864AK01 3BSE018161R1 | Main Processor Module | DCS Controller | 1.05 kg |
| PM866AK02 3BSE050198R1 | High-Speed Control Processor | Controller Module | 1.10 kg |
| CI854AK01 3BSE025961R1 | Communication Adapter (PROFIBUS) | Interface Module | 0.75 kg |
| AI810 3BSE008516R1 | Analog Input Module | I/O Module | 0.65 kg |
| DI810 3BSE008508R1 | Digital Input Module | I/O Module | 0.60 kg |
| DO810 3BSE008510R1 | Digital Output Module | I/O Module | 0.62 kg |
