产品介绍
The Honeywell 8C-TAIM01 (51306999-175) is a high-density analog input module designed for use in Honeywell’s Experion Process Knowledge System (PKS) and C300 controller environment. As part / the Series C I/O family, the 8C-TAIM01 provides advanced analog signal acquisition with scalable architecture and high fault tolerance.
This module is engineered to handle multiple analog process signals, such as temperature, pressure, flow, and level, converting them with high accuracy for control and monitoring within critical automation systems. The module utilizes a 16-channel configuration, /fering optimal space utilization and reducing the need for additional hardware.
The 8C-TAIM01 is built to deliver precision, flexibility, and reliability, making it an essential component for modern industrial operations across sectors like oil & gas, chemicals, pharmaceuticals, and power generation.
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | 8C-TAIM01 |
| 零件号 | 51306999-175 |
| Function | Analog Input Module |
| Number / Channels | 16 channels |
| Input Signal Types | 4-20 mA, 0-20 mA (with shunt resistors) |
| Input Type | Single-ended |
| Resolution | 16-bit A/D |
| Accuracy | ±0.05% / full scale |
| Input Impedance | 250 Ω (with internal resistor) |
| Scan Rate | Configurable, typical 100 ms to 1 sec |
| Input Isolation | Channel-to-channel and system-to-channel isolation |
| Redundancy 支持 | Yes (I/O and communication redundancy) |
| Diagnostics | Built-in self-diagnosis, open wire, over-range detection |
| Operating Voltage | Supplied via Series C backplane |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5% to 95% RH, non-condensing |
| Mounting | Mounted on IOTA (Input/Output Terminal Assembly) |
| System Compatibility | Experion PKS, C300 Controller, Series C |
| Certifications | CE, UL, CSA, ATEX, IECEx |
| Dimensions (W x H x D) | 50 × 210 × 120 mm |
| 重量 | 0.55 kg |
Applications
-
Oil and Gas Refining: Ideal for monitoring flow transmitters, pressure sensors, and temperature loops in distributed field installations.
-
Chemical and Petrochemical Plants: Handles continuous process variables with precision to support advanced process control strategies.
-
Pharmaceutical Manufacturing: Provides accurate input monitoring in critical batch and cleanroom operations.
-
Power Generation: Used for real-time signal acquisition from turbines, boilers, and cooling systems.
-
Water Treatment Facilities: Efficiently collects data from level, turbidity, and pH sensors in treatment tanks and distribution lines.
-
Pulp & Paper: 支持s complex process lines by acquiring analog feedback from motors, valves, and chemical dosing 件s.
Product Advantages
-
High Channel Density: 支持s 16 input channels per module, reducing cabinet space and cost.
-
Precision Measurement: 16-bit resolution and ±0.05% accuracy for high signal fidelity in process control.
-
System Integration: Fully compatible with Honeywell’s Experion Series C platform and C300 controller.
-
Advanced Diagnostics: Built-in health checks, signal verification, and open-loop detection ensure operational reliability.
-
Hot-Swappable: Module replacement without shutting down the system minimizes operational disruption.
-
Redundancy Ready: 支持s I/O and communication redundancy for high availability in mission-critical applications.
-
Field Proven Reliability: Designed to perform in harsh industrial environments over extended operating cycles.
-
Compact and Modular Design: Easy installation and maintenance with plug-and-play compatibility.
常见问题 (FAQ)
-
What is the primary function / the 8C-TAIM01 module?
It is designed to collect and digitize analog process signals such as 4-20 mA current loops for use in a distributed control system. -
How many analog inputs does the module support?
The 8C-TAIM01 supports 16 individual analog input channels. -
Is the 8C-TAIM01 compatible with Honeywell’s C300 controller?
Yes, it is fully integrated into the Series C platform, including the C300 controller. -
Can this module detect sensor wiring faults?
Yes, it features diagnostic functions for open wires, short circuits, and input over-range. -
What is the resolution / the A/D converter used in the module?
It uses a 16-bit analog-to-digital converter for precise signal resolution. -
Does the module support hot-swapping?
Yes, it allows for module replacement while the system is operational. -
What kind / isolation does this module provide?
It /fers electrical isolation both between channels and from the system bus. -
What are the typical applications for this module?
It is used in industries such as oil and gas, power generation, chemical, and pharmaceuticals for process monitoring. -
Does the module support redundant configurations?
Yes, both communication and I/O redundancy are supported for critical operations. -
What is the physical size and weight / the module?
The module measures 50 × 210 × 120 mm and weighs around 0.55 kg.
Recommended 型号s – Same Series or Related
| 型号 | 描述 |
|---|---|
| 8C-PAIMA1 | Analog Input Multiplexer Module, 32-channel |
| 8C-PAOHA1 | Analog Output Module, 8-channel |
| 8C-TAIXA1 | Extended Analog Input Module, HART-enabled |
| 8C-TDODA1 | Digital Output Module, 32-channel |
| 8C-TOIDA1 | Digital Input Module, 32-channel |
| 8C-PDILA1 | Pulse Input Module for frequency and pulse counting |
Popular Honeywell 型号s
| 型号 | 描述 |
|---|---|
| C300 Controller | Central controller for Series C architecture |
| FTA-T001 | Field Terminal Assembly for analog modules |
| MU-TDID12 | Digital Input Module, Redundant, 12 channels |
| CC-PAIN01 | High-Performance Analog Input Module with HART |
| MC-TDID12 | Digital Input, Redundant, supports TDC3000 I/O |
| CC-PDIL01 | Pulse Input Module, part / Experion PKS |
