产品介绍
The GE IC695CHS007 RX3i 7-Slot Universal Backplane is a compact, high-performance component / the GE PACSystems RX3i family, designed to serve as the foundation for modular industrial control systems. It provides the necessary infrastructure for integrating various RX3i modules, including CPUs, power supplies, I/O modules, and communication modules, into a single, unified system.
The IC695CHS007 is the smallest member / the RX3i Universal Backplane family, making it the preferred choice for applications that demand high control performance within limited space. Its dual-purpose architecture allows it to support both PCI-based (IC695) and serial backplane (IC693 and IC694) modules, providing exceptional compatibility and flexibility. This unique feature enables engineers to integrate both modern RX3i components and legacy Series 90-30 I/O modules within the same rack, ensuring long-term investment protection.
Compact, reliable, and versatile, the IC695CHS007 /fers industrial users a flexible platform that can be adapted to various automation, process control, and data acquisition environments.
Technical Specifications
| Parameter | 描述 |
|---|---|
| 制造商 | GE Automation & Controls |
| Product 型号 | IC695CHS007 |
| Product Type | RX3i Universal Backplane |
| Series | PACSystems RX3i |
| Number / Slots | 7 universal slots |
| Compatible Modules | IC695 (PCI-based), IC693/IC694 (serial-based), Series 90-30 I/O |
| Backplane Type | Dual-purpose (PCI and serial) |
| Bus Type | High-speed 32-bit PCI and serial bus |
| Bus Speed | Up to 33 MHz PCI bus |
| Power Supply Slots | 1 slot (leftmost) |
| CPU/Controller Slots | 1 slot (adjacent to power supply) |
| I/O Module Slots | 5 slots (for various input/output or communication modules) |
| Mounting Type | Panel or rack mounting |
| Power Distribution | Integrated power rails for backplane power delivery |
| Module Retention | Locking clips and guide rails for secure module fit |
| Operating Voltage | 5 VDC and 3.3 VDC distributed via backplane |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Shock Resistance | 30 g, 11 ms half-sine pulse |
| Vibration Resistance | 5–10 Hz, 0.2 inches displacement; 10–500 Hz, 2 g acceleration |
| Cooling Method | Natural convection (air-cooled) |
| Compliance Standards | CE, UL, cUL, RoHS compliant |
| Dimensions (W x H x D) | 265 x 141.5 x 148 mm |
| 重量 | 1.03 kg |
| Color | Industrial black/gray |
| Construction Material | Powder-coated aluminum and high-strength polymer |
| System Expansion | 支持s additional RX3i racks via expansion cables |
| Typical Bus Length | Up to 10 meters with expansion connections |
| Isolation | Electrical isolation between backplane segments |
| Certifications | UL508, CSA C22.2, IEC 61131-2 compliant |
Product Applications
The GE IC695CHS007 RX3i 7-Slot Universal Backplane is a core component for industrial automation and control systems. Its compact form and dual-bus design make it particularly suitable for mixed architecture systems, where both new and legacy modules need to be integrated.
Common applications include:
-
Process Automation Systems – 支持s control modules for process monitoring and control in refineries, chemical plants, and food manufacturing.
-
Factory Automation – Provides a robust platform for programmable control systems in assembly lines, robotics, and motion control.
-
Power Generation and Distribution – Used in turbine control, substation automation, and energy monitoring systems.
-
Oil and Gas Control Systems – Offers stable platform integration for wellhead monitoring and pipeline management.
-
Water and Wastewater Treatment – Manages distributed I/O systems for pump stations, filtration control, and SCADA integration.
-
Pharmaceutical and Biotech Automation – Enables precise control and data acquisition in cleanroom or production facilities.
-
Transportation and Logistics – 支持s control infrastructure in rail automation, material handling, and automated storage systems.
Product Advantages
-
Dual-Bus Compatibility
支持s both PCI-based (IC695) and serial-based (IC693/IC694) backplane modules, /fering seamless integration / new and legacy hardware. -
Compact Design
The 7-slot configuration is ideal for installations where panel space is limited but control requirements remain high. -
High Reliability
Robust mechanical design with industrial-grade materials ensures long-term stability in harsh environments. -
Flexible System Configuration
Compatible with Series 90-30 I/O modules, providing backward compatibility and migration flexibility. -
Efficient Power Distribution
Integrated power rails deliver consistent voltage and current across all module slots. -
Secure Module Mounting
Locking clips and precision guide rails prevent vibration-induced disconnection in industrial settings. -
Ease / Maintenance
Modular architecture allows hot-swapping / components and simplified field replacement. -
Future-Pro/ Architecture
Designed for scalability and long-term use, ensuring compatibility with future RX3i system modules. -
Enhanced Noise Imm件y
Grounding and shielding features ensure reliable communication and low EMI in demanding environments. -
Wide Operating Range
支持s extended temperature and humidity conditions for diverse industrial deployments.
FAQ
-
What types / modules can be installed in the IC695CHS007 backplane?
It supports IC695 (PCI-based), IC693, and IC694 (serial-based) modules, as well as Series 90-30 I/O modules. -
How many total slots are available for modules?
The backplane has 7 slots, including one for power supply, one for CPU/controller, and five for I/O or communication modules. -
Can the IC695CHS007 support both old and new generation modules?
Yes, it is specifically designed to support both legacy Series 90-30 and modern RX3i modules. -
What type / communication bus does the backplane use?
It uses a high-speed 32-bit PCI bus and a serial communication bus for dual compatibility. -
Does the backplane require active cooling?
No, it is naturally air-cooled and suitable for environments with proper ventilation. -
Is hot-swapping / modules supported?
Certain modules support hot-swapping, depending on system configuration and firmware compatibility. -
What are the recommended mounting options?
The backplane can be panel-mounted or rack-mounted using standard industrial enclosures. -
Can the backplane be expanded to include more slots?
Yes, additional RX3i racks can be connected using GE expansion cables. -
How does the backplane ensure electrical isolation?
It provides isolation between PCI and serial buses and employs grounding tracks to reduce electrical noise. -
Is the IC695CHS007 compatible with RX3i CPUs like IC695CPU310 or IC695CPU315?
Yes, it is fully compatible with both models, supporting stable communication and data exchange.
Related 型号s (Same Series or Function)
| 型号 | 描述 |
|---|---|
| IC695CHS012 | 12-slot RX3i Universal Backplane for large system configurations |
| IC695CHS016 | 16-slot RX3i backplane with extended I/O capability |
| IC695CHS032 | 32-slot backplane for large distributed control systems |
| IC695CHS100 | Modular expansion rack for RX3i backplane systems |
| IC695CHS002 | Compact 5-slot RX3i backplane for small control applications |
| IC695CBL002 | 3-foot backplane interconnect cable for RX3i expansion |
Popular GE 型号s (Same 品牌)
| 型号 | 描述 |
|---|---|
| IC695CPU310 | RX3i CPU module with high-speed Ethernet and logic processing |
| IC695PSA040 | 40W power supply module for RX3i systems |
| IC695ALG808 | 8-channel analog output module for precision control |
| IC695ALG728 | 8-channel analog output module supporting multiple signal types |
| IC695ETM001 | RX3i Ethernet communication module |
| IC695PWR330 | 330W power supply for expanded RX3i control systems |
