The Epro PR9268/206-100 is a high-performance electrodynamic velocity sensor tailored for industrial applications requiring precise and reliable vibration monitoring. As part / the Epro PR9268 series, this model is specifically designed to measure vibration velocity in machinery, helping to detect early signs / wear, misalignment, imbalance, or bearing failure.
The sensor operates on the electrodynamic principle, delivering an analog voltage signal proportional to the vibration velocity / the equipment to which it is mounted. Unlike piezoelectric sensors, the PR9268/206-100 requires no external power source, simplifying installation and long-term maintenance.
This model /fers optimized frequency response and mechanical ruggedness, making it suitable for harsh environments including power generation, steel production, oil & gas refining, and heavy machinery industries. Its stainless-steel housing, excellent shock resistance, and high ingress protection rating ensure long-lasting, dependable performance even in aggressive operating conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | PR9268/206-100 |
| Sensor Type | Electrodynamic Velocity Sensor |
| Output Signal | Analog Voltage |
| Sensitivity | 28 mV/mm/s (±5%) |
| Frequency Response | 10 Hz to 1000 Hz (±3 dB) |
| Measuring Range | ±50 mm/s (Peak) |
| Mounting Type | Stud Mounting – M8 x 1.25 |
| Housing Material | Stainless Steel |
| Connector Type | 2-pin MIL-C-5015 connector (axial or radial exit) |
| Cable Compatibility | Compatible with shielded twisted pair, optional armoring |
| Operating Temperature | -25°C to +120°C |
| Shock Limit | 5000 g |
| Vibration Limit | 200 g |
| Protection Class | IP67 |
| Dimensions (L x Ø) | 78 × 58 mm |
| 重量 | 0.93 kg |
| Installation Torque | 8 Nm recommended |
| Internal Damping | Less than 10% |
| Certification Options | CE, RoHS, ATEX (on request for specific versions) |
Product Applications
-
Steam and Gas Turbines
Monitors axial and radial vibration in rotating components to prevent catastrophic failure. -
Industrial Fans and Blowers
Identifies vibration due to blade imbalance, looseness, or mechanical resonance. -
Pumps and Compressors
Detects early-stage cavitation, impeller misalignment, or mechanical degradation. -
Steel Rolling Mills
Ensures proper machine performance under high-load environments. -
Cement and Mining Equipment
Measures equipment health in crushers, ball mills, and conveyor systems. -
HVAC and Power Distribution 单位s
Monitors motor health to avoid unplanned downtime in critical systems.
Product Advantages
-
High Output Sensitivity
The 28 mV/mm/s sensitivity provides excellent resolution for low-level vibration signals. -
Passive Sensor Design
No external power supply required, reducing complexity and points / failure. -
Rugged Construction
Stainless steel enclosure with high shock and vibration resistance ensures long-term performance. -
Ingress Protection IP67
Sealed against dust and water ingress for outdoor or washdown area usage. -
Standardized Connector & Mounting Interface
Facilitates quick and reliable installation and replacement with minimal training. -
Broad Compatibility
Easily integrates with condition monitoring and protection systems from multiple vendors. -
Wide Temperature and Shock Range
Performs reliably in extreme industrial conditions.
常见问题 (FAQ)
-
What is the sensing principle / the PR9268/206-100?
It operates on the electrodynamic principle, converting mechanical vibration into an electrical voltage signal. -
Does the sensor require external power?
No, it is a passive device and functions without external excitation. -
Is the PR9268/206-100 suitable for outdoor use?
Yes, with an IP67 protection rating, it is fully sealed for outdoor and industrial environments. -
Can this sensor be used in high-shock environments?
Absolutely, it is rated for shock levels up to 5000 g. -
What is the connector type?
The standard model uses a 2-pin MIL-C-5015 connector, either axial or radial. -
What cable types are compatible with this sensor?
Shielded twisted pair cables are recommended; armored versions are available for rugged use. -
Can this sensor be mounted in any orientation?
While it supports various orientations, optimal sensitivity is along the longitudinal axis / the housing. -
What is the typical application for this sensor in power plants?
It is commonly mounted on turbine casings to monitor vibration velocity. -
Is this sensor compatible with Epro’s CON021 or MMS systems?
No, the PR9268 series is typically connected directly to analog monitoring systems, not via eddy current sensor interfaces like CON021. -
How frequently does the sensor require maintenance?
Under normal industrial usage, the sensor requires virtually no maintenance thanks to its sealed design.
Related 型号s from the Same Series or 分类
| 型号 | 描述 | Sensitivity | Frequency Response |
|---|---|---|---|
| PR9268/201-000 | Standard axial velocity sensor | 20 mV/mm/s | 10 – 1000 Hz |
| PR9268/203-000 | Compact size, side-exit connector | 20 mV/mm/s | 10 – 1000 Hz |
| PR9268/204-000 | Extended temperature range version | 20 mV/mm/s | 10 – 1000 Hz |
| PR9268/205-000 | Dual sensitivity version | 10/20 mV/mm/s | 10 – 1000 Hz |
| PR9268/211-000 | ATEX-certified intrinsically safe variant | 20 mV/mm/s | 10 – 1000 Hz |
| PR9268/300-000 | Heavy-duty variant with shock reinforcement | 28 mV/mm/s | 10 – 1200 Hz |
Popular 型号s from the Same 品牌 (Epro)
| 型号 | Product Type | Key Feature | Application |
|---|---|---|---|
| PR6423/002-030 | Eddy Current Probe | High-resolution displacement measurement | Turbine Monitoring Systems |
| PR6424/010-010 | Eddy Current Probe | Rugged, high-temperature probe | Gas Compressors |
| CON021 | Connection Module | Used with PR6423/PR6424 series | Vibration Monitoring Systems |
| MMS3120/022-100 | Monitoring Module | 2-channel vibration + gap monitoring | Plant Automation Systems |
| MMS6110 | Multi-channel Monitoring System | Rack-based configuration with local display | Plant-wide Vibration Analysis |
| TQ402 | Speed Sensor | Pulse output speed monitoring | Rotating Machinery |
