The Bently Nevada 330910-01-19-10-02-00 3300 NSv Proximity Probe is a precision-engineered proximity sensor developed for industrial machinery vibration and displacement monitoring applications. Part / the Bently Nevada 3300 NSv Proximity Probe System, this model /fers highly accurate, stable, and repeatable measurements in harsh industrial conditions where space limitations and high reliability are essential.
The 330910 series is specifically designed for small shaft applications such as small turbines, compressors, pumps, and gearboxes, where accurate measurement / shaft vibration and position is critical for machine protection and predictive maintenance. The probe operates based on the Eddy Current principle, detecting the distance between the probe tip and the target metallic surface with exceptional linearity and temperature stability.
The 330910-01-19-10-02-00 model delivers high-frequency response, superior signal integrity, and full compatibility with the Bently Nevada 3300 NSv Proximity Transducer System. It is commonly paired with 3300 NSv Extension Cables and Proximitor Sensors to form a complete transducer assembly.
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | 330910-01-19-10-02-00 |
| Product Type | Proximity Probe (NSv Type) |
| System Type | Bently Nevada 3300 NSv Proximity Transducer System |
| Measurement Principle | Eddy Current (Non-contact) |
| Typical Applications | Small shaft vibration and displacement monitoring |
| Linear Range | 0.25 mm to 2.0 mm (10 to 80 mils) |
| Nominal Gap | 1.0 mm (40 mils) |
| Sensitivity | 7.87 mV/µm (200 mV/mil) |
| Frequency Response | DC to 10 kHz (–3 dB) |
| Probe Tip Diameter | 5 mm |
| Thread Type | M8 × 1 |
| Material | Stainless Steel housing with PTFE insulation |
| Operating Temperature | –35°C to +180°C |
| Storage Temperature | –40°C to +200°C |
| Maximum Cable Length | Compatible with up to 5 m total system length (probe + extension + proximitor) |
| Power Requirement (System) | –24 VDC (nominal, supplied via Proximitor) |
| Output Voltage Range | –2 VDC to –18 VDC proportional to gap distance |
| Insulation Resistance | > 100 MΩ at 500 VDC |
| Shock Resistance | 100 g, 11 ms |
| Vibration Tolerance | 20 g peak-to-peak, 10–2000 Hz |
| Moisture Protection | IP67 rated (sealed and oil-resistant) |
| 重量 | 0.15 kg |
| Total Length | 1.0 meter |
Product Applications
The Bently Nevada 330910-01-19-10-02-00 is widely used in rotating machinery applications that demand compact, high-precision proximity measurement. Its small form factor and robust design make it ideal for confined environments or smaller machines where standard probes cannot fit.
Typical Applications Include:
-
Turbomachinery Monitoring: Detects shaft vibration and relative displacement in gas or steam turbines.
-
Compressors and Pumps: Monitors bearing health, misalignment, and rotor dynamic behavior.
-
Gearboxes and Generators: Provides shaft position data for balancing and predictive diagnostics.
-
Fans and Blowers: Detects unbalance, looseness, or bearing degradation in small rotating elements.
-
Research and Testing Systems: Used in high-speed rotating machinery laboratories for real-time vibration data collection.
-
OEM and Skid-Mounted Equipment: Common in integrated machinery packages with compact mechanical layouts.
Product Advantages
-
Compact Design: Slim body allows installation in tight spaces or smaller machines.
-
High Precision: Delivers excellent linearity and repeatability over its full measurement range.
-
Stable Performance: Maintains accuracy under wide temperature and vibration conditions.
-
High Frequency Response: Enables reliable detection / rapid shaft movements and transient vibrations.
-
Rugged Construction: Stainless steel and PTFE components provide resistance to oil, dust, and corrosion.
-
Easy Integration: Fully compatible with 3300 NSv Proximitor Sensors and extension cables.
-
Reliable Isolation: Electrical isolation ensures signal purity and imm件y from ground loops.
-
Flexible Installation: 可用 with various mounting options and thread types for different configurations.
-
Proven Technology: Based on Bently Nevada’s trusted Eddy Current sensing platform.
-
Industrial Grade Durability: Engineered for long-term performance in demanding industrial environments.
FAQ
-
What type / measurement does the 330910-01-19-10-02-00 probe perform?
It performs non-contact measurement / shaft displacement and vibration using Eddy Current technology. -
Is this probe compatible with standard Bently Nevada proximitor sensors?
Yes, it is specifically designed to operate with 3300 NSv Proximitor Sensors and matching extension cables. -
What is the output signal characteristic / this probe system?
The system provides a voltage output proportional to the gap distance between the probe tip and the target surface. -
Can the probe be used in high-temperature environments?
Yes, it can operate continuously from –35°C to +180°C, suitable for most industrial applications. -
What is the sensitivity / the 330910-01-19-10-02-00 probe?
Its sensitivity is approximately 7.87 mV/µm (200 mV/mil), which ensures precise displacement measurement. -
Does the probe require calibration after installation?
Factory calibration is standard, but system calibration may be performed during setup to match target material and gap. -
What is the linear range / this proximity probe?
The linear range extends from 0.25 mm to 2.0 mm, providing accurate output within this distance. -
Is the probe resistant to oil or moisture contamination?
Yes, the probe is IP67-rated, resistant to oil ingress, and suitable for harsh industrial conditions. -
Can this probe be used for axial position monitoring?
Yes, it can be configured for both radial vibration and axial position measurements, depending on installation geometry. -
How does it differ from standard 3300 XL proximity probes?
The 3300 NSv version /fers a narrower signal range, optimized for smaller shaft diameters and confined installations.
