产品介绍
The Bently Nevada 330196-05-30-10-RU 3300 XL 8 mm ETR Reverse Mount Probe is a high-precision proximity probe engineered for continuous monitoring / shaft vibration and displacement in critical rotating machinery. Its reverse-mount configuration is ideal for confined installations where traditional forward-mount probes are not practical. Designed to meet the rigorous requirements / industrial environments, this probe delivers stable, repeatable measurements even in areas with high temperatures, vibration, or electrical interference. It integrates seamlessly with the Bently Nevada 3300 XL platform, providing a reliable solution for predictive maintenance and machinery protection.
产品规格
| Parameter | 描述 |
|---|---|
| 型号 Number | 330196-05-30-10-RU |
| Series | 3300 XL 8 mm ETR Reverse Mount Probes |
| Measurement Range | 2 mm (80 mils) non-contact displacement |
| Sensitivity | 7.87 mV/µm typical |
| Linearity | ±1 % over calibrated range |
| Operating Temperature | −40 °C to +125 °C |
| Humidity | 0–95 % non-condensing |
| Vibration Tolerance | Up to 20 g, 10–2000 Hz |
| Insulation Resistance | >100 MΩ at 500 V DC |
| Dielectric Strength | 2.5 kV AC for 1 minute |
| Probe Tip Diameter | 8 mm |
| Total Length | 1.0 meter |
| 重量 | 0.323 kg |
| Mounting Style | Reverse-mount threaded installation |
| Output Signal | Differential voltage, 3300 XL compatible |
| Housing Material | Stainless steel with corrosion-resistant finish |
Applications
-
Steam and Gas Turbines: Provides precise real-time monitoring / shaft vibration to detect imbalance or misalignment before failures occur.
-
Compressors and Pumps: Protects critical equipment by measuring shaft displacement and ensuring safe operating conditions.
-
Petrochemical Facilities: Functions reliably in humid, chemically aggressive environments common to refineries and chemical plants.
-
Power Generation 单位s: Integrates with 3300 XL monitoring systems for continuous predictive maintenance and machinery protection.
-
Industrial Rotating Equipment: Suitable for motors, fans, and generators requiring high-accuracy vibration measurements.
Advantages
-
Reverse-Mount Design: Facilitates installation where access is limited or where front mounting is not feasible.
-
High Measurement Accuracy: Maintains precise sensitivity and linearity for dependable machine condition monitoring.
-
优秀 Environmental Durability: Operates consistently under extreme temperatures, vibration, and electrical noise.
-
Robust Construction: Stainless-steel housing and corrosion-resistant finish provide long-term reliability.
-
System Compatibility: Fully compatible with Bently Nevada 3300 XL monitoring hardware, simplifying upgrades and replacements.
常见问题 (FAQ)
-
Can this probe be installed in both horizontal and vertical orientations?
Yes, the reverse-mount threaded design allows installation in either orientation without affecting measurement accuracy. -
What is the typical measurement range and sensitivity / this probe?
It supports a non-contact displacement range / 2 mm (80 mils) with a typical sensitivity / 7.87 mV/µm for precise vibration monitoring. -
Is this probe directly compatible with Bently Nevada 3300 XL systems?
Yes, it is engineered for seamless integration with all 3300 XL monitoring modules for vibration and shaft-position applications. -
How is proper alignment maintained during reverse mounting?
The probe uses a threaded rear-mount design with locking hardware to ensure accurate gap alignment and secure installation. -
What is the allowable operating temperature range?
The probe reliably operates between −40 °C and +125 °C, suitable for a wide range / industrial environments. -
Can it withstand high vibration conditions without losing accuracy?
Yes, the probe is rated to handle up to 20 g / vibration from 10–2000 Hz while maintaining stable performance. -
Does the probe provide a differential output signal?
Yes, it delivers a differential voltage output to minimize electrical noise and improve signal integrity. -
What is the insulation resistance specification?
The insulation resistance exceeds 100 MΩ at 500 V DC, ensuring electrical stability and reliable operation. -
How is electromagnetic interference managed?
Its internal shielding and robust construction protect against electromagnetic and radio-frequency interference for accurate data transmission. -
Is the probe suitable for continuous use in corrosive or humid environments?
Yes, the stainless-steel body and corrosion-resistant finish provide reliable operation in harsh or humid conditions.
Related 型号s in the Same Series
| 型号 Number | 描述 |
|---|---|
| 330196-05-30-05-RU | 3300 XL 8 mm ETR Reverse Mount Probe, 0.5 m length |
| 330196-05-30-20-RU | 3300 XL 8 mm ETR Reverse Mount Probe, 2.0 m length |
| 330196-05-30-30-RU | 3300 XL 8 mm ETR Reverse Mount Probe, 3.0 m length |
| 330196-05-30-50-RU | 3300 XL 8 mm ETR Reverse Mount Probe, 5.0 m length |
| 330196-05-30-90-RU | 3300 XL 8 mm ETR Reverse Mount Probe, 9.0 m length |
| 330196-05-30-12-RU | 3300 XL 8 mm ETR Reverse Mount Probe, 1.2 m length |
