Product Overview
The Bently Nevada 330104-00-22-10-01-05 proximity probe is an integral part / the trusted 3300 XL series, designed to deliver reliable, high-accuracy non-contact measurement / shaft displacement and vibration in rotating machinery. Built with robust materials and advanced eddy current sensing technology, this probe is optimized for industrial environments requiring continuous condition monitoring and protection / critical assets.
Its precision measurement capability supports predictive maintenance by detecting early signs / machine wear or failure, minimizing downtime and repair costs. The probe features a threaded mounting design and an integral coaxial cable engineered for seamless compatibility with Bently Nevada 3300 XL extension cables and Proximitor sensors.
Key Features
-
Non-contact eddy current sensing for high-precision displacement measurement
-
Integral coaxial cable for durable and interference-resistant signal transmission
-
Threaded probe body (3/8-24 UNF) for secure installation
-
Hermetically sealed probe tip designed to resist contaminants and moisture
-
Wide operating temperature range to suit harsh industrial environments
-
Compatible with 3300 XL Proximitor sensors and extension cables
-
High shock and vibration tolerance for reliable performance
-
EMI/RFI resistant for stable and accurate signal output
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | 330104-00-22-10-01-05 |
| Series | 3300 XL 8 mm |
| Sensing Principle | Eddy current (non-contact) |
| Target Material | Conductive metals (e.g., 4140 steel) |
| Linear Range | 2 mm (80 mils) |
| System Accuracy | ±0.07 mm (±2.8 mils) within linear range |
| Output Voltage | -200 mV/mil (nominal) |
| Power Supply | Via 3300 XL Proximitor Sensor |
| Connector Type | Male Microdot coaxial |
| Cable Length | 1.0 meters |
| Thread Size | 3/8-24 UNF-2A |
| Mounting Method | Threaded probe body |
| Environmental Sealing | Hermetically sealed probe tip |
| Operating Temperature Range | -35°C to +177°C (-31°F to +351°F) |
| Shock Survivability | 5000 g peak |
| Vibration Survivability | 20 g, 10–2000 Hz sinusoidal |
| EMC Compliance | IEC 61000-6-2, IEC 61000-6-4 |
| Ingress Protection | IP67 |
| Dimensions | Total Length : 1.0 meter |
| 重量 | 0.323 kg |
Industry Applications
-
Power Generation: Monitoring turbines and generators to detect early mechanical issues
-
Oil & Gas: Critical equipment such as compressors and pumps
-
Petrochemical: Refinery rotating machinery condition monitoring
-
Steel & Mining: Mills, crushers, and large motors requiring precise shaft position data
-
Marine & Offshore: Machinery protection for propulsion and auxiliary systems
-
Pulp & Paper: Rollers and rotary machines vibration monitoring
-
Heavy Industry: Broad applications in machinery protection and condition monitoring
Product Advantages
-
Precision and Reliability: Provides accurate vibration and shaft displacement measurements critical to predictive maintenance.
-
Robust Construction: Hermetic sealing and rugged design ensure longevity in harsh environments.
-
Standard Compatibility: Fully compatible with 3300 XL system components for ease / integration.
-
Resistance to EMI and Vibration: Ensures signal integrity in electrically noisy and mechanically demanding settings.
-
Minimal Maintenance: Factory calibrated with durable components requiring little upkeep.
-
Compact Size: Fits into tight spaces without compromising measurement performance.
-
Long-Term Stability: Designed to maintain calibration and functionality over extended periods.
-
Cost-Efficient Monitoring: Helps prevent unexpected machinery failures and costly downtime.
-
Wide Temperature Range: Suitable for a variety / industrial settings, including high-temperature zones.
-
Proven Industry Standard: Globally trusted by industrial operators for asset protection.
常见问题 (FAQ)
-
What does the 330104-00-22-10-01-05 probe measure?
It measures non-contact shaft displacement and vibration via eddy current sensing. -
Is the cable integral or detachable?
This probe features a 2.2-meter integral coaxial cable. -
What is the operating temperature range?
The probe operates safely from -35°C to +177°C (-31°F to +351°F). -
Can this probe be used with other brands?
It is specifically designed for compatibility with Bently Nevada 3300 XL systems. -
What mounting options are available?
The probe mounts securely via a 3/8-24 UNF threaded body. -
How accurate is the probe’s measurement?
The system accuracy is ±0.07 mm within the linear range / 2 mm. -
Is the probe suitable for hazardous environments?
Certification depends on the entire system; the probe is rugged but check system approvals. -
Does it require periodic recalibration?
Typically, factory calibration suffices unless the operating environment changes significantly. -
What materials can the probe detect?
It is designed for conductive metal targets, typically steel. -
What is the probe’s approximate weight?
关于我们 0.323 kg including the cable.
Related Modules
| 型号 Number | 描述 |
|---|---|
| 330104-00-05-10-02-00 | 8 mm Proximity Probe, 5 m integral cable |
| 330104-00-12-10-02-05 | 8 mm Proximity Probe, 12 m integral cable |
| 330104-00-18-10-02-05 | 8 mm Proximity Probe, 18 m integral cable |
| 330104-01-05-50-02-00 | Armored 8 mm Proximity Probe, 5 m cable |
| 330104-01-08-50-01-CN | 8 mm Proximity Probe, armored, 8 m cable, CN version |
| 330101-00-14-10-02-05 | Alternative 8 mm Proximity Probe with smaller thread |
Popular 型号s
| 型号 Number | 描述 |
|---|---|
| 3500/22M | Transient Data Interface Module for 3500 Series |
| 330130-080-00-00 | 3300 XL Extension Cable (8 m) |
| 330180-91-05 | 3300 XL Extension Cable with connectors |
| 330500-02-00 | Velocity Transducer for vibration measurement |
| 3500/42M | Proximitor/Seismic Monitor Module |
| 3300 XL 25 mm | Large gap proximity probe system for axial thrust position |
