The Bently Nevada 330103-00-02-05-02-05 3300 XL 8mm Proximity Probe is a precision sensor designed for accurate shaft vibration and displacement monitoring in critical rotating machinery. Part / the 3300 XL 8mm Proximity Probe series, it provides reliable, real-time data essential for machinery protection and predictive maintenance.
With a total cable length / 0.5 meters and a weight / 0.162 kg, this compact probe is ideal for installations with minimal distance between the probe tip and the associated Proximitor sensor module. The probe uses advanced eddy-current technology to detect the distance between the probe tip and the conductive shaft surface without physical contact, /fering high accuracy and fast response for critical industrial applications.
Its rugged stainless steel construction and PEEK-insulated cable ensure resilience in industrial environments, while coaxial shielding provides excellent resistance to electromagnetic interference. Fully compatible with Bently Nevada 3300 XL Proximitor modules, it meets the rigorous standards / API 670 for machinery protection systems.
Product Parameters
| Parameter | Specification |
|---|---|
| 型号 Number | 330103-00-02-05-02-05 |
| Series | 3300 XL 8mm Proximity Probe |
| Probe Tip Diameter | 8 mm |
| Linear Range | 2 mm (±1 mm from center) |
| Sensitivity | 7.87 V/mm (200 mV/mil) ±5% |
| Frequency Response | DC to 10 kHz |
| Power Supply | -24 V DC nominal via Proximitor module |
| Total Length | 0.5 meter |
| 重量 | 0.162 kg |
| Operating Temperature Range | -35°C to +177°C |
| Storage Temperature Range | -50°C to +200°C |
| Material | Stainless steel probe body, PEEK insulated cable |
| Mounting Thread | 3/8”-24 UNF or M10 x 1 depending on installation |
| System Compatibility | Compatible with Bently Nevada 3300 XL Proximitor Sensors |
Product Applications
The 330103-00-02-05-02-05 is suitable for a wide range / rotating machinery applications, including:
-
Turbines and Generators: Measures shaft vibration and radial displacement for predictive maintenance.
-
Centrifugal and Reciprocating Pumps: Monitors alignment, imbalance, and vibration.
-
Compressors: Tracks dynamic behavior / high-speed rotors for early fault detection.
-
Industrial Motors and Gearboxes: Provides real-time data to prevent machinery failure.
-
Critical Process Equipment: 支持s API 670 compliant machinery protection systems in oil, gas, and power plants.
Product Advantages
-
High Accuracy: Reliable measurement / shaft vibration and radial displacement with minimal error.
-
Short Cable Design: 0.5-meter length minimizes signal attenuation and simplifies compact installations.
-
Robust Construction: Stainless steel housing and PEEK-insulated cable withstand harsh industrial environments.
-
EMI Resistance: Coaxial shielding ensures signal integrity in electrically noisy conditions.
-
Seamless Integration: Compatible with 3300 XL Proximitor modules for continuous monitoring.
-
API 670 Compliance: Designed to meet industry standards for machinery protection.
-
High-Frequency Response: 支持s vibration detection up to 10 kHz for high-speed machinery.
FAQ
-
How does this probe maintain accuracy over its short 0.5-meter cable?
The probe uses impedance-matched coaxial cable with shielding to minimize signal loss and preserve output accuracy. -
What is the linear range / the 330103-00-02-05-02-05 probe?
The probe operates within a ±1 mm linear range, providing precise measurement / shaft displacement. -
Can it measure both vibration and static shaft position?
Yes, it simultaneously outputs signals for both dynamic vibration and static displacement. -
How does it handle electrical noise?
Shielded coaxial cable and PEEK insulation reduce electromagnetic interference and maintain signal clarity. -
What frequency range does this probe support?
It provides a DC to 10 kHz response suitable for high-speed rotating equipment. -
Is this probe compatible with all 3300 XL Proximitor modules?
Yes, it integrates seamlessly with 3300 XL Proximitor modules for system monitoring. -
How does temperature affect the probe signal?
Thermal compensation ensures stable output from -35°C to +177°C, maintaining accuracy. -
What is the correct mounting procedure?
The probe should be mounted perpendicular to the shaft using a 3/8”-24 UNF or M10 x 1 threaded fitting for optimal accuracy. -
Can it detect rapid changes in shaft vibration?
Yes, its 10 kHz frequency response allows monitoring / high-frequency vibration events. -
Does it comply with industrial standards?
Yes, the probe meets API 670 standards for machinery protection systems, ensuring safety and reliability.
