Product Overview
The Bently Nevada 21504-00-40-10-02 is a high-performance proximity probe designed as part / the trusted 7200 Series. It features an 8mm probe tip and comes with a 40-inch integral cable, making it ideal for installations requiring extended distance between the sensing point and the proximitor. This standard mount probe is engineered for continuous monitoring / rotating machinery, providing precise non-contact measurements / shaft vibration and position.
Built to comply with API 670 guidelines, this probe is widely used in the oil & gas, petrochemical, power generation, and heavy industrial sectors. It works in conjunction with a proximitor sensor and extension cable to form a complete eddy-current proximity measurement system. Its rugged design, superior stability, and ease / installation make it a long-term solution for machinery protection systems.
Technical Specifications
| Parameter | Details |
|---|---|
| 型号 | 21504-00-40-10-02 |
| Series | 7200 Series |
| Probe Tip Diameter | 8 mm (0.315 in) |
| Total Length | 1.0 meter |
| Mounting Type | Standard Threaded Mount |
| Thread Size | 3/8-24 UNF-2A |
| Connector Type | Miniature coaxial connector (male) |
| Measurement Range | 0.25 to 2.0 mm (10 to 80 mils) |
| Sensitivity | 200 mV/mil (7.87 mV/µm) |
| Linear Range | 0.5 mm (20 mils) from target surface |
| Operating Temperature | -35°C to +175°C (-31°F to +347°F) |
| Material – Probe Housing | AISI 303 Stainless Steel |
| Material – Probe Tip | PPS (Polyphenylene Sulfide) |
| Ingress Protection | IP65 (when installed properly) |
| 重量 | 0.22 kg |
| Frequency Response | 0 to 10 kHz (-3 dB) |
| Compliant Standards | API 670, CE, RoHS |
| System Accuracy | ±5% / full-scale output |
Applications
The Bently Nevada 21504-00-40-10-02 proximity probe is suitable for a broad range / industrial and critical applications:
-
Steam Turbines: Monitoring shaft vibration and axial displacement.
-
Gas Compressors: Shaft behavior analysis in high-speed rotating systems.
-
Centrifugal and Reciprocating Pumps: Detecting imbalance and misalignment.
-
Electric Motors and Generators: Rotor position tracking and vibration detection.
-
Gearboxes and Couplings: Early fault detection via shaft displacement signals.
-
Refineries and Chemical Plants: Integration into condition monitoring and safety systems.
Its 40-inch cable length makes it especially useful where access to the target surface is limited, or routing constraints are present.
Product Advantages
-
Extended Cable Length: 1.0 meter integrated cable supports flexible installation without compromising signal quality.
-
Robust Mechanical Design: Stainless steel body and high-temperature rated tip ensure durability in aggressive environments.
-
Industry Compliance: Conforms to API 670 standards, ensuring compatibility with critical rotating equipment monitoring specifications.
-
优秀 Signal Integrity: Delivers stable 200 mV/mil output across the full measurement range.
-
Non-联系我们 Operation: Provides accurate vibration and displacement data without physical wear on machinery.
-
Fast Response Time: Wide frequency response enables detection / rapid machinery behavior changes.
-
IP65 Rated Housing: Offers reliable protection against dust and moisture when properly installed.
-
Field Replaceable: Designed for ease / maintenance and field replacement with minimal downtime.
-
Global 支持: Backed by Bently Nevada’s comprehensive service network for technical assistance.
-
Long Operating Life: Built to withstand extreme industrial operating conditions for continuous usage.
常见问题 (FAQ)
-
Q: What distinguishes the 21504-00-40-10-02 from other 8mm probes?
A: The key distinction is its 1.0 meter total length, which allows for installations where longer reach is required. -
Q: What system does this probe belong to?
A: It is part / the Bently Nevada 7200 proximity transducer system. -
Q: Is this probe compatible with the 3300 XL proximitor?
A: No, it is designed specifically for use with 7200 series proximitor sensors. -
Q: How should this probe be mounted?
A: It should be thread-mounted using the standard 3/8-24 UNF threads. -
Q: What type / output signal does this probe generate?
A: The probe outputs a linear voltage signal / 200 mV/mil, typically processed through a proximitor. -
Q: Can the probe withstand oil and steam exposure?
A: Yes, the housing and probe tip materials are resistant to most industrial chemicals and high humidity. -
Q: What is the recommended gap voltage?
A: Typically, the system is adjusted to -10 VDC at a 1.0 mm (40 mils) gap. -
Q: Does the longer cable affect measurement accuracy?
A: No, the cable length is matched to the proximitor system to maintain calibrated accuracy. -
Q: Is this probe field-replaceable?
A: Yes, the probe is designed to be replaced in the field with minimal disassembly. -
Q: What kind / maintenance is required?
A: Periodic visual inspections and verification / calibration during scheduled maintenance intervals are recommended.
Related 型号s (Same Series or Function)
| 型号 Number | 描述 | Cable Length | Thread Type | Application |
|---|---|---|---|---|
| 21504-00-12-10-02 | 7200 8mm Standard Probe | 12 inches | 3/8-24 UNF | General vibration and position monitoring |
| 21504-00-18-10-02 | 7200 8mm Probe with Extended Reach | 18 inches | 3/8-24 UNF | Deeper installations |
| 21504-00-24-10-02 | 7200 8mm Probe with 24-inch Cable | 24 inches | 3/8-24 UNF | Shaft proximity monitoring |
| 21504-00-05-10-02 | 7200 8mm Compact Probe | 5 inches | 3/8-24 UNF | Compact spaces |
| 330101-00-40-10-02 | 3300 XL 8mm Probe with 40-inch Cable | 40 inches | 3/8-24 UNF | New generation systems |
| 21504-00-40-10-01 | 7200 8mm Probe, Alternate Connector Version | 40 inches | 3/8-24 UNF | System variation compatibility |
Popular Bently Nevada 型号s (Same 品牌)
| 型号 Number | 描述 | Function | Series |
|---|---|---|---|
| 3500/42M | Proximitor Monitor Module | Shaft vibration and position | 3500 Series |
| 3500/22M | Transient Data Interface Module | Communication and diagnostics | 3500 Series |
| 330104-00-10-10-02 | 3300 XL 8mm Probe | Vibration monitoring | 3300 XL Series |
| 330180-91-05 | 3300 XL NSv Probe | Small target/clearance applications | 3300 XL NSv |
| 330130-040-00 | 3300 XL Extension Cable | Signal transmission | 3300 XL |
| 3500/94M | VGA Display Module | System display and diagnostics | 3500 Series |
