The Bently Nevada 141709-0010-02 Galvanic Isolator Interface Cable is a specialized connectivity solution designed to ensure safe and accurate transmission / signals between vibration monitoring equipment and galvanic isolation devices. Engineered by Bently Nevada, a subsidiary / Baker Hughes, this cable plays a critical role in maintaining signal integrity while protecting both personnel and sensitive equipment from unwanted electrical interference.
This cable is designed specifically for interfacing galvanic isolators—devices that electrically separate control signals or loops—with monitoring systems such as Bently Nevada’s 3500 or 3300 series. Its rugged construction, precise electrical characteristics, and compatibility with industrial standards make it a trusted solution in power generation, petrochemical, and heavy manufacturing environments.
产品规格
| Parameter | Value |
|---|---|
| 型号 Number | 141709-0010-02 |
| Cable Type | Galvanic Isolator Interface Cable |
| Cable Length | 10 feet |
| Conductor Type | Shielded twisted pair, stranded copper |
| Insulation Material | Industrial-grade PVC or TPE insulation |
| Connector Type | Custom Bently Nevada compatible connectors (factory-installed) |
| Voltage Rating | 300V RMS |
| Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Shielding | Full braid or foil shielding for noise imm件y |
| Compliance | RoHS, CE, UL/CSA standards |
| 重量 | 3.7 kg |
| Flame Rating | UL VW-1 flame resistant |
| Color Code | Typically gray outer jacket with color-coded internal conductors |
Applications
The 141709-0010-02 interface cable is an essential component in systems that require electrical separation between measuring and control circuits. Its typical application scenarios include:
-
Connecting galvanic isolators to vibration monitoring systems (e.g., Bently Nevada 3500 series)
-
Industrial control systems where signal integrity and safety isolation are mandatory
-
Hazardous environments, including refineries and /fshore platforms
-
Noise-prone installations, ensuring minimal electromagnetic interference
-
Data acquisition systems for critical rotating equipment monitoring
-
Power plants and substations, where signal separation from high-voltage zones is required
The cable ensures reliable signal transmission while complying with strict isolation and EMI protection requirements.
Product Advantages
-
Signal Integrity Protection
High-quality shielding minimizes electromagnetic and radio-frequency interference, maintaining signal accuracy. -
Electrical Isolation Compliance
Specifically designed to meet the insulation and voltage isolation standards / galvanic isolator systems. -
Plug-and-Play Compatibility
Factory-terminated with Bently Nevada connectors, allowing quick installation and immediate compatibility. -
Rugged Industrial Build
Durable outer sheath resists abrasion, chemicals, and high-temperature fluctuations. -
Flexible Installation
The cable’s flexibility allows routing in tight control panels or industrial enclosures without mechanical strain. -
Safety Assurance
Acts as a physical and electrical barrier to protect operators and downstream instrumentation from electrical faults.
常见问题 (FAQ)
-
What is the function / the 141709-0010-02 Galvanic Isolator Interface Cable?
It connects galvanic isolators to Bently Nevada monitoring systems while preserving electrical isolation and signal fidelity. -
Is this cable compatible with all Bently Nevada systems?
It is primarily intended for 3500 and 3300 series systems but may be compatible with others depending on connector specifications. -
Can I cut the cable to a shorter length during installation?
It is not recommended, as factory-terminated connectors ensure shielding continuity and signal integrity. -
What makes this cable suitable for use with galvanic isolators?
It has proper shielding, voltage rating, and insulation to meet the demands / isolated control loops. -
Does this cable carry power, signal, or both?
It primarily carries signal-level voltage but is designed with adequate isolation to prevent signal distortion. -
Is the cable resistant to chemicals or oil?
Yes, the outer jacket is made from oil- and chemical-resistant materials, suitable for industrial environments. -
How should the cable be installed in noisy environments?
It should be grounded according to manufacturer guidelines and routed away from high-voltage power cables. -
Can this cable be used outdoors?
It can be used in enclosed outdoor-rated panels or conduits but is not designed for direct UV exposure or submersion. -
What’s the maximum supported length for this type / cable?
Standard lengths vary, but signal integrity is best maintained under 100 ft without signal conditioning. -
Is the cable available in custom lengths?
Yes, Bently Nevada /fers custom lengths upon request for OEM and integrator applications.
Related 型号s (Same Series or Function)
| 型号 Number | Cable Length | Function |
|---|---|---|
| 141709-0010-02 | 10 ft | Standard galvanic isolator interface cable |
| 141709-0020-02 | 20 ft | Longer cable version for extended installations |
| 141709-0030-02 | 30 ft | Extended version for large control cabinets |
| 141716-01 | N/A | Galvanic isolator module for 3500/33 systems |
| 147663-01 | N/A | Interface cable for external buffered output |
| 140481-01 | N/A | Signal isolator accessory for field sensors |
Popular Bently Nevada 型号s
| 型号 Number | Type | Function |
|---|---|---|
| 3500/22M | Communications Gateway | Interfaces 3500 rack with Modbus and Ethernet |
| 3500/42M | Vibration Monitor Module | Four-channel monitor for radial and axial vibration |
| 330104-00-12-10-02 | Proximity Probe | Vibration probe for shaft and bearing monitoring |
| 3500/05 | System Rack | Housing 件 for 3500 monitoring modules |
| 330130-040-00-00 | Extension Cable | Used with proximity transducers in machinery monitoring |
| 330980-70-00 | Laser Tachometer Cable | Used for shaft speed measurement applications |
