The ABB PP825A (3BSE042240R3) is a high-performance industrial touch screen panel, part / ABB’s Panel 800 operator panel series. This robust Human-Machine Interface (HMI) is designed for demanding industrial environments, enabling intuitive, real-time process visualization and control. Engineered with a powerful processor, bright TFT display, and comprehensive communication interfaces, the PP825A simplifies automation management across a wide range / industries.
The 件 is fully compatible with ABB’s Control Builder and 800xA systems, enabling seamless integration into ABB’s automation ecosystem. Its rugged construction, ease / configuration, and responsive capacitive touch interface make it an ideal solution for both new installations and modernization projects.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Name | ABB PP825A Touch Screen Panel |
| Order Code | 3BSE042240R3 |
| Series | Panel 800 |
| Display Type | TFT LCD, 16.7 million colors |
| Screen Size | 15.4 inches |
| Resolution | 1024 × 768 (XGA) |
| Touch Technology | Resistive analog touch screen |
| Processor | ARM-based processor |
| Memory | 64 MB RAM, 64 MB Flash |
| Operating System | Windows CE-based embedded OS |
| Interfaces | 2 × Ethernet (RJ45), 2 × USB Host, 1 × RS232, 1 × RS485, 1 × CAN |
| 支持ed Protocols | Modbus TCP, OPC, ABB-specific protocols, Ethernet/IP |
| Input Voltage | 24 VDC |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 10–90% RH, non-condensing |
| Cooling | Fanless, convection cooled |
| Certifications | CE, UL, cULus, RoHS compliant |
| Mounting Type | Panel mounting |
| Front Panel Protection | IP65 (front), IP20 (rear) |
| Dimensions (W × H × D) | 202 x 152 x 6 mm |
| 重量 | 0.9 kg |
Applications
The ABB PP825A is tailored for industrial HMI applications where operator interaction, real-time process feedback, and remote diagnostics are critical. Common use cases include:
-
Factory Automation – Line control, status visualization, recipe management
-
Power and Utilities – Monitoring substations, SCADA front-end interfaces
-
Water and Wastewater Treatment – Pump and flow control dashboards
-
Oil and Gas – Process status, pressure/temperature visualization, fault logs
-
Chemical and Pharmaceutical – Batch processing panels, safety alerts
-
Food and Beverage – Touch panel control for mixing, packaging, and labeling systems
The device supports flexible deployment across manufacturing lines, control rooms, operator stations, and cabinet panels.
Product Advantages
-
High-Resolution Display
The 1024×768 XGA display delivers crisp, clear visuals for detailed SCADA or HMI graphics. -
Multiple Communication Ports
With RS232, RS485, USB, CAN, and dual Ethernet ports, it accommodates a wide range / protocols and devices. -
Rugged Industrial Design
Built for 24/7 operation in industrial environments, it withstands vibrations, temperature swings, and dust exposure. -
Fanless Cooling System
The convection-cooled design reduces mechanical failure risks and extends device longevity. -
Fast Installation and Setup
Panel cutout-friendly dimensions and plug-and-play interfacing streamline integration and deployment. -
Seamless ABB System Integration
Native compatibility with ABB AC 800M and Control Builder systems enhances system coherence and engineering efficiency. -
Touch-Friendly Interface
The resistive touchscreen is highly responsive and suitable for use with gloves in industrial settings. -
Energy Efficient
Operates on 24 VDC with low power consumption, suitable for energy-conscious designs. -
Secure Operation
Includes password protection and configurable user roles for system security. -
Longevity and 支持
Backed by ABB’s industrial-grade product lifecycle and global service infrastructure.
常见问题 (FAQ)
-
Q: What is the display resolution / the PP825A?
A: The PP825A /fers 1024×768 XGA resolution on a 15.4-inch display. -
Q: Does it support Modbus TCP communication?
A: Yes, Modbus TCP is fully supported along with other common industrial protocols. -
Q: Can it be used with gloves?
A: Yes, the resistive touch screen allows use with gloved hands, ideal for industrial use. -
Q: Is the front panel water-resistant?
A: The front panel is rated IP65, protecting against water splashes and dust ingress. -
Q: Can the 件 be mounted outdoors?
A: It’s designed for indoor use, but can be used in enclosures rated for outdoor conditions. -
Q: What s/tware is used for configuration?
A: ABB Panel Builder 800 or compatible HMI engineering tools. -
Q: Is the PP825A compatible with ABB’s AC 800M controllers?
A: Yes, it is fully compatible with AC 800M and integrates well within the System 800xA platform. -
Q: How is the 件 powered?
A: It operates on a 24 VDC power supply. -
Q: Does it support USB devices?
A: Yes, it has two USB host ports for peripherals like keyboards or USB drives. -
Q: Is firmware upgradable?
A: Yes, firmware updates can be applied via USB or network connection.
Related 型号s (Same Series or Functional Range)
| 型号 | Screen Size | Resolution | Touch Type | Key Features |
|---|---|---|---|---|
| PP820A | 10.4 inches | 800 × 600 | Resistive | Compact design, basic control panels |
| PP826A | 12.1 inches | 800 × 600 | Resistive | Enhanced I/O, fanless cooling |
| PP835A | 15 inches | 1024 × 768 | Capacitive | High-end panel for visual-rich HMIs |
| PP841A | 19 inches | 1280 × 1024 | Resistive | Large display, ideal for overview panels |
| PP874A | 15 inches | 1024 × 768 | Multi-touch | Multi-protocol support, wide format |
| CP620 | 12.1 inches | 1024 × 768 | Capacitive | HMI + control hybrid 件 |
Popular ABB Automation 型号s
| 型号 | 分类 | Highlights |
|---|---|---|
| PM866 | Controller Module | Redundancy support, AC 800M platform |
| CI854AK01 | Communication Module | PROFIBUS-DP interface for AC800M |
| AI810 | Analog Input Module | 8-channel 4–20 mA input, robust design |
| AC500 PM595 | PLC CPU | High-speed multicore CPU, large memory |
| DO820 | Digital Output Module | 16-channel 24 VDC sinking output |
| AC500-eCo PM554 | Compact PLC | Entry-level PLC with Ethernet and expansion options |
