Product Introduction
The Yokogawa ANB10D-415 ESB Bus Node Unit is a critical component in the ESB (Embedded System Backbone) bus communication infrastructure, developed to provide high-speed, deterministic, and reliable data transfer across distributed control systems (DCS). As a bus node unit, it acts as the primary interface between ESB bus communication lines and connected modules, ensuring seamless synchronization and stable system operation.
Designed with Yokogawa’s engineering expertise, the ANB10D-415 is capable of handling real-time communication requirements in large-scale and mission-critical automation systems. It integrates multiple modules, manages data transmission integrity, and provides robust fault tolerance in environments where downtime is unacceptable.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | ANB10D-415 |
| Product Type | ESB Bus Node Unit |
| Communication Method | ESB Bus Protocol (High-speed, deterministic) |
| Interfaces | Supports multiple module connections |
| Bus Ports | Dual redundant ESB bus ports |
| Data Transfer Rate | High-speed real-time communication |
| Power Supply | 24 V DC |
| Power Consumption | < 15 W |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Humidity Tolerance | 5% to 95% RH (non-condensing) |
| Shock Resistance | 15 g, 11 ms |
| Vibration Resistance | 2 g, 10–150 Hz |
| EMC Compliance | IEC/EN Standards |
| Safety Certification | CE, RoHS, TÜV |
| Dimensions | 482.6 × 221.5 ×205 mm |
| Weight | 10 kg |
Applications
The ANB10D-415 ESB Bus Node Unit is designed for a wide range of industrial automation and control applications, particularly in complex and distributed networks where communication reliability is essential:
-
Distributed Control Systems (DCS): Acts as a central bus node unit, interconnecting multiple modules within Yokogawa’s CENTUM VP and related systems.
-
Oil & Gas Industry: Ensures robust and continuous communication in upstream, midstream, and downstream operations.
-
Power Generation Plants: Manages data flow between controllers, subsystems, and I/O modules in turbines and substations.
-
Petrochemical Plants: Provides secure, redundant communication paths in high EMI environments.
-
Pharmaceutical Manufacturing: Maintains compliance and precise process monitoring in validated environments.
-
Utilities and Water Treatment: Facilitates backbone communication for reliable control and monitoring.
Advantages
-
High-Speed Communication: Designed for deterministic data exchange with minimal latency.
-
Dual Redundancy: Dual ESB bus ports provide fault tolerance and ensure system availability.
-
Scalability: Supports multiple module connections for growing automation systems.
-
Hot-Swappable: Can be replaced without shutting down the system, minimizing downtime.
-
Robust Design: Resistant to shock, vibration, and harsh industrial environments.
-
Compliance with Global Standards: CE, RoHS, and TÜV certifications guarantee safety and reliability.
-
Centralized Integration: Acts as a communication hub within ESB bus networks.
-
Proven Reliability: Based on Yokogawa’s track record in long-term, mission-critical process automation.
FAQ
-
What is the main function of the ANB10D-415 in an ESB bus system?
It serves as a node unit that manages communication between ESB bus lines and connected modules. -
Does the ANB10D-415 support redundant operation?
Yes, it has dual redundant ESB bus ports for fault-tolerant communication. -
Which communication protocol is supported by this unit?
It supports Yokogawa’s ESB bus protocol for high-speed deterministic communication. -
Can the ANB10D-415 be integrated with CENTUM VP systems?
Yes, it is fully compatible with Yokogawa’s CENTUM VP and related DCS platforms. -
Is the ANB10D-415 hot-swappable?
Yes, it can be replaced during live operation without affecting system availability. -
How does the unit ensure communication reliability?
It regenerates signals, uses redundant ports, and complies with industrial EMC standards. -
What type of diagnostic features are included?
The unit provides status indicators and monitoring for communication integrity. -
What is the power supply requirement for the ANB10D-415?
It operates on a 24 V DC supply with a power consumption of less than 15 W. -
Does the ANB10D-415 have environmental resistance?
Yes, it is resistant to vibration, shock, and operates within 0°C to 55°C. -
Is the unit certified for global deployment?
Yes, it meets CE, RoHS, and TÜV certifications for safety and compliance.
