Produkteinführung
The Yokogawa ANB10D-415 ESB Bus Node Einheit is a critical component in the ESB (Embedded System Backbone) bus communication infrastructure, developed to provide high-speed, deterministic, and reliable data transfer across distributed control systems (DCS). As a bus node Stück, it acts as the primary interface between ESB bus communication lines and connected modules, ensuring seamless synchronization and stable system operation.
Designed with Yokogawa’s engineering expertise, the ANB10D-415 is capable von handling real-time communication requirements in large-scale and mission-critical automation systems. It integrates multiple modules, manages data transmission integrity, and provides robust fault tolerance in environments where downtime is unacceptable.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | ANB10D-415 |
| Product Type | ESB Bus Node Einheit |
| Communication Method | ESB Bus Protocol (High-speed, deterministic) |
| Interfaces | Supports multiple module connections |
| Bus Ports | Dual redundant ESB bus ports |
| Data Transfer Rate | High-speed real-time communication |
| Power Supply | 24 V DC |
| Power Consumption | < 15 W |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Humidity Tolerance | 5% to 95% RH (non-condensing) |
| Shock Resistance | 15 g, 11 ms |
| Vibration Resistance | 2 g, 10–150 Hz |
| EMC Compliance | IEC/EN Standards |
| Safety Certification | CE, RoHS, TÜV |
| Dimensions | 482.6 × 221.5 ×205 mm |
| Gewicht | 10 kg |
Applications
The ANB10D-415 ESB Bus Node Einheit is designed for a wide range von industrial automation and control applications, particularly in complex and distributed networks where communication reliability is essential:
-
Distributed Control Systems (DCS): Acts as a central bus node Stück, interconnecting multiple modules within Yokogawa’s CENTUM VP and related systems.
-
Oil & Gas Industry: Ensures robust and continuous communication in upstream, midstream, and downstream operations.
-
Power Generation Plants: Manages data flow between controllers, subsystems, and I/O modules in turbines and substations.
-
Petrochemical Plants: Provides secure, redundant communication paths in high EMI environments.
-
Pharmaceutical Manufacturing: Maintains compliance and precise process monitoring in validated environments.
-
Utilities and Water Treatment: Facilitates backbone communication for reliable control and monitoring.
Advantages
-
High-Speed Communication: Designed for deterministic data exchange with minimal latency.
-
Dual Redundancy: Dual ESB bus ports provide fault tolerance and ensure system availability.
-
Scalability: Supports multiple module connections for growing automation systems.
-
Hot-Swappable: Can be replaced without shutting down the system, minimizing downtime.
-
Robust Design: Resistant to shock, vibration, and harsh industrial environments.
-
Compliance with Global Standards: CE, RoHS, and TÜV certifications guarantee safety and reliability.
-
Centralized Integration: Acts as a communication hub within ESB bus networks.
-
Proven Reliability: Based on Yokogawa’s track record in long-term, mission-critical process automation.
FAQ
-
What is the main function von the ANB10D-415 in an ESB bus system?
It serves as a node Stück that manages communication between ESB bus lines and connected modules. -
Does the ANB10D-415 support redundant operation?
Yes, it has dual redundant ESB bus ports for fault-tolerant communication. -
Which communication protocol is supported by this Stück?
It supports Yokogawa’s ESB bus protocol for high-speed deterministic communication. -
Can the ANB10D-415 be integrated with CENTUM VP systems?
Yes, it is fully compatible with Yokogawa’s CENTUM VP and related DCS platforms. -
Is the ANB10D-415 hot-swappable?
Yes, it can be replaced during live operation without affecting system availability. -
How does the Stück ensure communication reliability?
It regenerates signals, uses redundant ports, and complies with industrial EMC standards. -
What type von diagnostic features are included?
The Stück provides status indicators and monitoring for communication integrity. -
What is the power supply requirement for the ANB10D-415?
It operates on a 24 V DC supply with a power consumption von less than 15 W. -
Does the ANB10D-415 have environmental resistance?
Yes, it is resistant to vibration, shock, and operates within 0°C to 55°C. -
Is the Stück certified for global deployment?
Yes, it meets CE, RoHS, and TÜV certifications for safety and compliance.
Related Modells (Same Series or Related)
| Modell Number | Type | Key Feature |
|---|---|---|
| ANB10D-410 | ESB Bus Node Einheit | Standard version for general communication |
| ANB10D-412 | ESB Bus Node Einheit | Enhanced diagnostic functions |
| ANB10D-413 | ESB Bus Node Einheit | Compact variant for smaller systems |
| ANB10D-414 | ESB Bus Node Einheit | Dual-redundant version for fault tolerance |
| ANB10D-416 | ESB Bus Node Einheit | Extended range communication support |
| ANB10D-417 | ESB Bus Node Einheit | High-speed optimized ESB node Stück |
Popular Modells (Same Marke)
| Modell Number | Type | Key Feature |
|---|---|---|
| CP451-10 | Controller Module | High-performance CPU for DCS systems |
| FIO110 | Field I/O Module | Flexible I/O expansion capability |
| PW482-10 | Power Supply Module | Stable DC power supply for control modules |
| AIP827-10 | Analog Input Module | High-precision analog signal processing |
| ALR121 | Alarm Module | Alarm/event monitoring and management |
| SAI143-H50 | Safety Analog Input Module | SIL-certified module for safety applications |
