製品紹介
The Yokogawa ADM11-S3 お問い合わせ Input Module is a high-performance digital input module designed for use with the CENTUM CS 3000 and CENTUM VP distributed control systems (DCS). Engineered for reliability and long-term operation in industrial environments, the ADM11-S3 allows for precise monitoring / contact signal statuses from field devices, ensuring accurate process automation and safety control. It plays a critical role in capturing digital signals from push buttons, limit switches, relays, and other contact-type sensors.
Built on Yokogawa’s longstanding reputation for robust industrial automation components, the ADM11-S3 /fers 16 channels / contact input and is specifically tailored to meet the demanding standards / process control in industries such as power generation, petrochemicals, oil and gas, and water treatment.
製品仕様
| Parameter | Specification |
|---|---|
| モデル Number | ADM11-S3 |
| Product Type | お問い合わせ Input Module |
| Input Channels | 16 channels (non-isolated from each other, isolated from system) |
| Input Signal Type | Dry contact or wetted contact signal input |
| ON 州 Voltage | 15 V DC or higher |
| OFF 州 Voltage | 5 V DC or lower |
| Input Impedance | Approx. 4.7 kΩ |
| Scan Interval | 100 ms or faster |
| Power Supply | Supplied from the system (no external power required for input detection) |
| Isolation | Optical isolation between field and system |
| お問い合わせ Type | Voltage-free dry contact |
| Diagnostic Function | Built-in self-diagnostics and status indicators |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Storage Temperature | -20 to 70°C (-4 to 158°F) |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Installation Method | Mounted on a baseplate within a control cabinet |
| Dimensions (W × H × D) | 125 x 130 x 248 mm |
| 重量 | 0.14 kg |
| Certifications | CE, CSA, UL, RoHS compliant |
Product Applications
The ADM11-S3 module is widely used in process industries that require dependable digital signal acquisition. Key application scenarios include:
-
Power Plants: Monitoring / switch statuses, interlock contacts, and alarm systems.
-
Oil and Gas Facilities: お問い合わせ signal acquisition from field instruments and safety systems.
-
Petrochemical Refineries: Logic interlocks and control signal monitoring in hazardous zones.
-
Water Treatment Plants: Monitoring / float switches, pump contactors, and valve positions.
-
Manufacturing Automation: Integrating machine safety switches and manual override signals into the DCS.
Product Advantages
-
High Reliability: Designed for industrial environments with robust construction and optical isolation.
-
Real-Time Monitoring: Fast scan cycle ensures timely and accurate input data delivery to the control system.
-
Built-in Diagnostics: LEDs and self-check functions enhance troubleshooting and reduce downtime.
-
Space-Efficient: Compact size allows for high-density input signal monitoring within small enclosures.
-
Easy Integration: Seamless compatibility with Yokogawa CENTUM systems ensures effortless configuration.
-
Low Maintenance: Stable operation with minimal drift or degradation over time.
-
Standards Compliant: Meets international safety and environmental standards (CE, RoHS, UL).
よくある質問 (FAQ)
-
What type / signals can the ADM11-S3 accept?
The ADM11-S3 is designed to accept dry or wetted contact input signals, typically from switches, relays, or other voltage-free contact devices. -
Is the module isolated from the system?
Yes, it features optical isolation between the field inputs and the internal system to ensure safety and prevent signal interference. -
How many input channels are available on the ADM11-S3?
It provides 16 input channels for digital contact signal acquisition. -
What is the required ON and OFF voltage for the input signal?
The ON state requires ≥15V DC, while the OFF state must be ≤5V DC. -
Can the module be used in high humidity environments?
Yes, it supports 5% to 95% relative humidity (non-condensing), suitable for most industrial conditions. -
What is the main difference between ADM11-S3 and ADM11-S2?
The ADM11-S3 typically features improved diagnostics and component revisions for higher reliability compared to older models like ADM11-S2. -
What kind / diagnostic features are included?
The module includes LED indicators and internal self-check routines to detect and notify about internal faults. -
Does it require external power for inputs?
No, the power for detecting input signals is provided internally by the system. -
Can I hot-swap this module during operation?
No, it is not designed for hot-swapping. The system should be powered down before replacing the module. -
Is this module compatible with CENTUM VP?
Yes, it is fully compatible with Yokogawa’s CENTUM VP and CS 3000 systems.
Related モデルs from the Same Series
| モデル | 説明 | Input Type | Channels | Dimensions (mm) | 重量 |
|---|---|---|---|---|---|
| ADM11-S2 | 前の version / ADM11-S3 | お問い合わせ Input | 16 | 27.2×130×176 | 0.2 kg |
| ADM12-S3 | High-speed digital input module | お問い合わせ Input | 16 | 27.2×130×176 | 0.2 kg |
| ADM51 | Dual-redundant input module | お問い合わせ Input | 16 | 27.2×130×176 | 0.2 kg |
| ADV151 | Mixed input/output module | Analog/Digital | 8/8 | 27.2×130×176 | 0.25 kg |
| AAI141-S1 | Analog input module | Analog Input | 16 | 27.2×130×176 | 0.2 kg |
| ADV111 | Digital output module | お問い合わせ Output | 16 | 27.2×130×176 | 0.2 kg |
Popular Yokogawa モデルs
| モデル | 説明 | Function | System Compatibility | 重量 |
|---|---|---|---|---|
| AAI143-H50 | High-speed analog input module | Analog Input | CENTUM VP/CS 3000 | 0.2 kg |
| AAI543-H00 | HART analog input module | Analog Input (HART) | CENTUM VP/CS 3000 | 0.2 kg |
| AAI835-H00 | Isolated universal input module | Universal Input | CENTUM VP | 0.3 kg |
| AAR181-S00 | Pulse input module | Pulse Signal | CENTUM VP/ProSafe-RS | 0.2 kg |
| ADV551 | Digital output module (relay) | Relay Output | CENTUM VP/CS 3000 | 0.25 kg |
| ACG10S | Control network gateway module | Network Gateway | CENTUM VP | 0.3 kg |
