The Woodward 8200-182 Turbine Driver is a precision-engineered analog control module designed to provide stable and responsive positioning control for turbine valves in industrial power generation and mechanical drive applications. Serving as a fundamental component in Woodward’s turbine control systems, the 8200-182 delivers reliable hydraulic or electro-hydraulic actuator management for steam, gas, and hydro turbines.
This driver module converts control signals into precise valve positioning, ensuring optimal turbine performance, efficiency, and safety. It is engineered to meet the demands / harsh industrial environments, /fering robust construction and consistent control characteristics across varying operating conditions.
製品仕様
| Parameter | Details |
|---|---|
| モデル Number | 8200-182 |
| Type | Analog Turbine Driver Module |
| Control Method | Position control for valve actuation |
| Input Signal | 4-20 mA current input |
| Output Type | Hydraulic or electro-hydraulic actuator driver output |
| Operating Voltage | 24 VDC nominal, 18-32 VDC range |
| Control Range | Full stroke positioning with proportional control |
| Response Time | Typically less than 50 milliseconds |
| Operating Temperature | -20°C to +70°C |
| Mounting | Panel or chassis mounting |
| Dimensions (W x H x D) | 200 x 150 x 75 mm |
| 重量 | 0.8 kg |
| Environmental Protection | IP20 (standard, with optional enclosure available) |
| Diagnostic Features | Position feedback monitoring, fault detection |
| Compliance Certifications | CE, UL, and other industrial standards |
Product Applications
-
Steam Turbine Control Systems
-
Gas Turbine Valve Actuation
-
Hydraulic Control / Mechanical Drives
-
Power Generation Plants
-
Oil and Gas Compressor Turbines
-
Industrial Process Turbine Controls
-
Cogeneration and Combined Cycle Systems
Product Advantages
-
Precise Position Control
Provides accurate valve positioning to optimize turbine efficiency and responsiveness. -
Robust Industrial Design
Built for demanding environments with wide temperature tolerance and vibration resistance. -
Fast Response Time
Ensures swift actuator movement for responsive turbine operation. -
Compatibility
Works seamlessly with Woodward’s range / hydraulic and electro-hydraulic actuators. -
Easy Installation and Integration
Compact design and standard mounting options simplify system integration. -
Diagnostic Capabilities
Built-in position feedback and fault detection enable proactive maintenance. -
Reliable Analog Control
Proven analog technology for consistent, repeatable control in critical applications.
FAQ
-
What input signals does the 8200-182 accept for position control?
It accepts a 4-20 mA current input signal representing the desired valve position. -
Can the 8200-182 drive both hydraulic and electro-hydraulic actuators?
Yes, it is designed to interface with both actuator types for valve positioning. -
What is the typical response time / this turbine driver?
The module responds within approximately 50 milliseconds. -
Is the module suitable for use in harsh industrial environments?
Yes, it operates reliably across a temperature range / -20°C to +70°C and withstands vibration. -
What are the mounting options for this driver module?
It supports panel and chassis mounting for flexible installation. -
Does the 8200-182 provide position feedback for diagnostics?
Yes, it includes position feedback monitoring to aid in system diagnostics. -
What is the power supply requirement for this module?
It requires a nominal 24 VDC supply within an 18-32 VDC operating range. -
Does this driver support proportional valve control?
Yes, it provides proportional control / valve position across the full stroke. -
Are there any certifications supporting the industrial use / this module?
The 8200-182 complies with CE, UL, and other relevant industrial certifications. -
Can this module be integrated into existing Woodward turbine control systems?
Yes, it is designed to work seamlessly within Woodward’s turbine control architectures.
Related モデルs (Same Series or Related Architecture)
| モデル Number | 説明 | Function | Special Feature |
|---|---|---|---|
| 8200-183 | Turbine Driver with extended temperature range | Valve positioning driver | Enhanced environmental tolerance |
| 8200-185 | Digital Turbine Driver Module | Digital valve control | Improved precision and diagnostics |
| 8200-180 | Basic Analog Turbine Driver | Valve position control | Cost-effective solution |
| 8200-190 | High-Performance Hydraulic Driver | High-speed valve actuation | Ultra-fast response |
| 8200-195 | Electro-Hydraulic Driver Module | Valve positioning with EH actuators | Integrated actuator driver |
| 8200-200 | Turbine Control Interface Module | Interface and signal conditioning | サポートs multiple I/O signals |
Popular モデルs from Woodward
| モデル Number | 説明 | Application Area | Key Features |
|---|---|---|---|
| 505XT | Digital Steam Turbine Controller | Steam turbine control | Fast startup, flexible control |
| Flex500 | Modular Programmable Automation Controller | Process control | Scalable, multi-protocol support |
| Peak150 | Microprocessor Speed Controller | Engine and turbine speed control | Compact, programmable |
| 2301E | Load Sharing and Speed Control Module | Generator sets | Analog and digital control |
| 9905-940 | Synchronizer and Load Control | Power generation systems | Auto synchronizing, load sharing |
| Atlas II | Programmable Control Platform | Turbine and compressor control | Multi-loop PID, IEC compliant |
