The Schneider TSXDSZ08T2K is a high-performance digital output module designed for use within the Modicon Premium programmable logic controller (PLC) platform. As a part / Schneider Electric’s advanced automation solutions, this model delivers reliable control over discrete outputs in industrial environments. The TSXDSZ08T2K features transistor outputs and is tailored for fast-switching applications where performance and reliability are essential.
With a compact form factor and DIN rail mounting support, the module integrates seamlessly into control cabinets and automated systems. The 8-channel design /fers precise digital signal control, making it suitable for controlling solenoids, indicators, relays, and small actuators in a wide variety / automation processes.
Product Features and Advantages
-
High-Speed Switching: Transistor outputs support rapid switching for time-sensitive control.
-
Compact and Modular: Fits within the Modicon Premium PLC rack, conserving panel space.
-
LED Status Indicators: Each output channel includes LED indication for simplified diagnostics.
-
Reliable Build Quality: Engineered by Schneider Electric to meet industrial-grade standards for reliability and longevity.
-
Overload and Short-Circuit Protection: Protects the module and connected devices from electrical faults.
-
Screw Terminal Block: Easy wiring and secure connection ensure robust installation.
-
High Density: 8 outputs in one module reduce I/O expansion requirements.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル Number | TSXDSZ08T2K |
| Product Type | Digital Output Module |
| Output Type | Transistor (Sink Type) |
| Number / Channels | 8 |
| Output Voltage | 24 V DC |
| Output Current per Channel | 0.5 A |
| Response Time | < 1 ms |
| Output Protection | Short-circuit and overload protection |
| Isolation | Optical isolation between channels and bus |
| LED Indicators | 1 per output channel |
| Connector Type | Removable terminal block |
| Mounting | DIN Rail |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -25°C to 70°C |
| Dimensions | 55 × 180 × 260 mm |
| 重量 | 0.18kg |
| Standards Compliance | CE, UL, CSA, RoHS |
| Compatible PLCs | Modicon Premium Series |
Applications
The TSXDSZ08T2K is commonly used in:
-
Manufacturing Automation: Controls actuators, conveyors, and robotic arms.
-
Material Handling Systems: Provides output signals for sorting, labeling, and packaging machinery.
-
Energy Management: Controls load-shedding relays and lighting systems.
-
Process Control: Operates valves, pumps, and alarms in chemical and water treatment facilities.
-
Building Automation: Integrates with HVAC systems and building safety controls.
-
Transportation and Logistics: サポートs automation in warehouse management and vehicle diagnostics.
よくある質問 (FAQs)
-
What type / output does the TSXDSZ08T2K provide?
It provides 24V DC transistor (sink-type) digital outputs. -
How many outputs are available on the module?
The module features 8 independent digital output channels. -
Is this module compatible with the Modicon M340 series?
No, the TSXDSZ08T2K is specifically designed for the Modicon Premium series. -
Can I use this module for high-speed pulse output?
It is suitable for fast switching but not designed for high-frequency pulse output like PWM. -
Does the module have overload protection?
Yes, it includes integrated short-circuit and overload protection per channel. -
What is the typical power consumption / this module?
Power consumption varies by load but remains minimal due to efficient transistor output design. -
Are replacement terminal blocks available separately?
Yes, Schneider Electric provides spare parts including terminal blocks. -
What indicators are available for troubleshooting?
Each output channel has a dedicated LED indicator to show active state. -
Is any additional s/tware required for configuration?
It is configured using ユニットy Pro or EcoStruxure Control Expert, Schneider’s PLC programming s/tware. -
Can the TSXDSZ08T2K be hot-swapped?
No, it must be powered down before installation or removal to prevent damage or unsafe operation.
Related モデルs (Same or Similar Series)
| モデル Number | 説明 | Output Type | Channels | Voltage | Dimensions (mm) |
|---|---|---|---|---|---|
| TSXDSY08R5 | Digital Output Module, relay | Relay | 8 | 24 VDC/230 VAC | 125 x 32 x 115 |
| TSXDSZ32T2K | Digital Output Module, transistor | Transistor (Sink) | 32 | 24 VDC | 125 x 45 x 115 |
| TSXDEY16D2 | Digital Input Module | Sink Input | 16 | 24 VDC | 125 x 32 x 115 |
| TSXDSY16R5 | Digital Output Module, relay | Relay | 16 | 24 VDC/230 VAC | 125 x 45 x 115 |
| TSXAEY414 | Analog Input Module | Voltage/Current | 4 | V/mA | 125 x 32 x 115 |
| TSXASY410 | Analog Output Module | Voltage/Current | 2 | V/mA | 125 x 32 x 115 |
Popular Schneider モデルs (Cross-Series)
| モデル Number | 説明 | Series | Type | Application |
|---|---|---|---|---|
| BMXDDO1602 | 16-Channel Digital Output Module | Modicon M340 | Transistor | General I/O control |
| TM5SAI2DF | Analog Input Module | Modicon TM5 | Analog Input | Compact remote I/O |
| BMXAMO0410 | Analog Output Module | Modicon M340 | Analog Output | Process control and regulation |
| TSXP572634M | Premium CPU Module | Modicon Premium | CPU | Core PLC control |
| TM221CE16R | Logic Controller with Ethernet | Modicon M221 | PLC | Compact machine control |
| TM241CEC24T | Logic Controller with CANopen | Modicon M241 | PLC | Machine automation |
