Product Overview
The Schneider TM3DM24RG is a discrete input/output (I/O) module designed for modular automation systems, /fering reliable digital signal control in industrial environments. Part / Schneider Electric’s TM3 series, this module combines discrete digital inputs and relay outputs, making it ideal for applications that require both sensing and switching capabilities.
This module supports 24 V DC digital inputs and relay outputs, delivering electrical isolation and enhanced switching power. Its robust construction and compact design enable easy integration into TM3 modular I/O systems, suitable for machine control, factory automation, and process applications.
Technical Specifications
| Specification | 説明 |
|---|---|
| モデル Number | TM3DM24RG |
| Module Type | Discrete Input and Relay Output Module |
| Number / Inputs | 12 digital inputs |
| Number / Outputs | 8 relay outputs |
| Input Voltage | 24 V DC nominal |
| Output Voltage | 250 V AC / 30 V DC (relay output ratings) |
| Output Type | Electromechanical relay |
| Input Type | Sinking or sourcing (depending on wiring) |
| Output Current Rating | 5 A per relay contact |
| Response Time | Typically < 10 ms |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 90 x 84.6 x 42.9mm |
| 重量 | Package weight 0.27 kg |
| Mounting Type | DIN rail mounting |
| Protection Rating | IP20 |
| Communication Interface | Backplane bus connection |
| Certifications | CE, UL, cUL, RoHS compliant |
Industry Applications
-
Machine and Factory Automation
-
Process Control Systems
-
Building Automation
-
Packaging and Material Handling
-
HVAC Control
-
Water and Wastewater Treatment
-
Food and Beverage Manufacturing
-
Automotive Industry
Key Advantages
-
Combined Input and Relay Output: サポートs both discrete sensing and high-current switching in a single module.
-
High Load Capacity: Relay outputs rated up to 5 A per contact, suitable for controlling heavy loads.
-
Electrical Isolation: Relay outputs provide galvanic isolation between control signals and loads.
-
Robust and Reliable: Designed to operate reliably across wide temperature and humidity ranges.
-
Compact and Modular: Fits within TM3 modular I/O systems, allowing easy expansion and maintenance.
-
Fast Response: Typical response times below 10 ms for effective control.
-
DIN Rail Mounting: Simplifies installation and wiring in control cabinets.
-
Certified and Compliant: Meets international safety and environmental standards.
よくある質問 (FAQ)
-
How many inputs and outputs does the TM3DM24RG module have?
It has 12 digital inputs and 8 relay outputs. -
What voltage levels do the inputs and outputs operate at?
Inputs operate at 24 V DC nominal; relay outputs switch up to 250 V AC or 30 V DC. -
What is the maximum current rating for each relay output?
Each relay contact is rated for 5 A. -
What is the typical response time / the module?
Response time is typically under 10 milliseconds. -
What mounting options are available?
The module mounts on a standard DIN rail. -
Is the module suitable for harsh environments?
It is rated for operation between -25°C and +60°C with 5% to 95% humidity. -
Does the module provide electrical isolation?
Yes, relay outputs provide galvanic isolation. -
Can the module be used with other Schneider TM3 modules?
Yes, it is fully compatible with the TM3 modular I/O system. -
What certifications does the TM3DM24RG hold?
It is CE, UL, cUL certified and RoHS compliant. -
Is the module suitable for controlling inductive loads?
Yes, relay outputs are suitable for resistive and inductive loads within specified ratings.
