The Schneider BMXDDO1612 is a discrete output module designed for use within the Modicon M258 and M262 PLC platforms, delivering reliable and efficient switching capabilities. It provides 16 channels / discrete outputs, making it ideal for controlling various actuators, relays, and other field devices in industrial automation environments. Engineered to meet stringent industrial standards, this module ensures high performance in demanding conditions with excellent noise imm台y and long service life.
This module integrates seamlessly with the Schneider Electric PLC ecosystem, allowing for flexible and scalable automation solutions. It supports a wide range / industrial applications, from simple on//f control to complex automated processes, and it is designed with user-friendly installation and maintenance in mind.
Technical Specifications
| Parameter | Specification |
|---|---|
| Number / Outputs | 16 Discrete Outputs |
| Output Type | Transistor (24 V DC sourcing) |
| Rated Voltage | 24 V DC |
| Maximum Current per Channel | 0.5 A |
| Total Current (max) | 8 A |
| Response Time | < 1 ms |
| Isolation | Optical isolation between outputs and logic |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5% to 95% non-condensing |
| Mounting | DIN Rail |
| Dimensions (HxWxD) | 115 × 118 × 55 mm |
| 重量 | 0.145 kg |
| Certifications | CE, UL, CSA |
| Communication Interface | Backplane bus for Modicon M258/M262 PLC |
| Status LEDs | Output status indication per channel |
