The Schneider Electric ATV61HC13N4 is a high-power variable speed drive from the Altivar 61 series, developed for demanding pumping and ventilation machines in industrial and infrastructure environments. With a rated motor power / 132 kW (200 hp), this drive is engineered to control large three-phase asynchronous motors operating on a 380–480 V AC power supply.
As part / the heavy-duty HC configuration, the ATV61HC13N4 is designed for continuous operation under high electrical and thermal stress. Its integrated heat sink construction ensures efficient heat dissipation, supporting stable performance in applications where airflow, cooling water circulation, or process continuity is critical.
The drive incorporates an integrated Class C2 EMC filter, reducing electromagnetic interference and simplifying compliance with industrial EMC requirements. Its electrical characteristics and control philosophy are optimized for variable torque loads, making it a reliable solution for large-scale pumping stations and ventilation systems.
製品仕様
| Parameter | Specification |
|---|---|
| Product Series | Altivar 61 |
| Product Type | Variable Speed Drive |
| Application Focus | Pumping and ventilation machines |
| Rated Motor Power | 132 kW |
| Maximum Horsepower Rating | 200 hp |
| Supply Voltage Range | 380–480 V AC |
| Supply Phases | 3-phase |
| Line Current (480 V) | 224 A |
| Line Current (380 V) | 239 A |
| Apparent Power | 157.3 kVA at 380 V |
| Maximum Prospective Line Isc | 35 kA |
| Maximum Transient Current | 310.8 A for 60 s |
| Nominal Switching Frequency | 2.5 kHz |
| EMC Filter | Integrated Class C2 EMC filter |
| Assembly Style | With integrated heat sink |
| Dimensions | 1022 × 106 × 360 mm |
| 重量 | 106 kg |
Applications
• Large Industrial Pumping Systems:
Applied in water supply, wastewater treatment, and industrial fluid transfer systems requiring high power and continuous operation.
• Ventilation and Air Handling ユニットs:
Used in large fans and air circulation systems in industrial plants, tunnels, and infrastructure facilities.
• HVAC Infrastructure:
Suitable for centralized HVAC systems with high airflow demand and variable load conditions.
• Energy and Utility Installations:
Installed in utility stations and auxiliary systems where reliability and operational stability are essential.
• Process Industry Equipment:
サポートs pumping and ventilation functions in chemical, petrochemical, and material processing plants.
Advantages
• High Power Density:
Designed to control large motors efficiently while maintaining compact integration within electrical rooms.
• Optimized for Variable Torque Loads:
Control algorithms specifically tuned for pump and fan applications improve system efficiency.
• Thermal Stability:
Integrated heat sink construction ensures reliable operation under continuous high-load conditions.
• Integrated EMC Compliance:
Built-in Class C2 EMC filter reduces installation complexity and external component requirements.
• Industrial-Grade Reliability:
Engineered for long service life in demanding industrial and infrastructure environments.
