製品紹介
The Ovation 1C31129G05 Analog Output Module is an essential device designed for the Ovation Distributed Control System (DCS) to provide precise and reliable analog output signals. It plays a critical role in controlling field equipment by converting digital commands from the control system into accurate analog signals. This module supports multiple channels / analog output, typically in current or voltage form, facilitating smooth operation / valves, actuators, and other industrial devices requiring continuous signal control.
Built with ruggedness and reliability in mind, the 1C31129G05 module is engineered to meet the demands / harsh industrial environments such as power plants, chemical processing, and water treatment facilities. The module ensures stable, noise-resistant output signals with high resolution and accuracy, making it indispensable for automation and control applications where precision and durability are paramount.
製品仕様
| Parameter | Specification |
|---|---|
| モデル Number | 1C31129G05 |
| Module Type | Analog Output Module |
| Number / Output Channels | 8 |
| Output Signal Types | 4-20 mA current loop, 0-10 V voltage |
| Accuracy | ±0.05% Full Scale |
| Resolution | 16-bit |
| Output Load | 0-600 Ω for current output |
| Response Time | < 20 ms |
| Isolation | Channel-to-channel galvanic isolation |
| Power Supply | 24 V DC (nominal) |
| Communication Interface | Backplane bus interface |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (HxWxD) | 60 x 125 x 63 mm |
| 重量 | 0.9 kg |
Applications
-
Power Generation: Precisely controls analog signals for turbine control valves, generator excitation, and other critical plant systems.
-
Oil & Gas: Manages analog control signals for pumps, valves, and process instrumentation in refining and extraction operations.
-
Chemical Processing: Ensures accurate analog control in complex chemical reaction and separation processes.
-
Water and Wastewater Treatment: Facilitates fine control / chemical dosing, flow regulation, and environmental monitoring.
-
Manufacturing Automation: Controls analog actuators and variable-speed drives in production lines for smooth process management.
-
HVAC Systems: Provides accurate analog signals to control temperature, airflow, and humidity devices.
Advantages
-
High Precision and Stability: Offers excellent signal accuracy with minimal drift for dependable process control.
-
Robust Electrical Isolation: Prevents signal interference and protects module and system from electrical faults.
-
Versatile Output Options: サポートs both current and voltage analog output signals to meet a wide variety / field device requirements.
-
Compact and Space-Efficient: Designed to fit within standard Ovation system racks with minimal footprint.
-
Fast Response Time: Allows quick adaptation to process changes, enhancing control quality.
-
Reliable Operation: Built for industrial environments with rigorous testing to ensure durability.
-
Easy Maintenance: Modular design allows quick replacement and troubleshooting.
-
Energy Efficient: Low power consumption reduces operational costs.
よくある質問 (FAQ)
-
What type / signals does the 1C31129G05 module output?
It outputs analog signals, including 4-20 mA current loops and 0-10 V voltage signals. -
How many output channels are available on this module?
The module features 8 analog output channels. -
What is the accuracy / the output signals?
It provides an accuracy / ±0.05% / full scale. -
Is there electrical isolation between output channels?
Yes, galvanic isolation is provided channel-to-channel for signal integrity. -
What are the physical dimensions / the module?
The module measures 60 x 125 x 63 mm. -
What power supply does this module require?
It requires a nominal 24 V DC power supply. -
What is the operating temperature range?
The module operates within -20°C to +70°C safely. -
Can this module control both current and voltage outputs?
Yes, it supports both 4-20 mA current and 0-10 V voltage output signals. -
What kind / industrial environments is this module suited for?
It is suitable for power plants, chemical processing, oil & gas, water treatment, and manufacturing automation. -
Is the module easy to install and replace?
Yes, it is designed for simple plug-and-play installation within the Ovation DCS rack system.
Related モデルs (Same Series / Similar Functionality)
| モデル Number | 説明 | Channels | Output Type | 重量 (kg) | Dimensions (HxWxD mm) |
|---|---|---|---|---|---|
| 1C31129G01 | Analog Output Module | 8 | 4-20mA / 0-10V | 0.55 | 130 x 40 x 200 |
| 1C31129G02 | High Accuracy Analog Output | 4 | 4-20mA Current | 0.50 | 130 x 40 x 180 |
| 1C31130G01 | Analog Input Module | 8 | Voltage/Current Input | 0.55 | 130 x 40 x 200 |
| 1C31131G05 | Digital Output Module | 16 | Discrete Output | 0.60 | 130 x 40 x 200 |
| 1C31132G03 | Temperature Input Module | 16 | RTD / Thermocouple | 0.50 | 130 x 40 x 210 |
| 1C31133G04 | High-Speed Analog Output Module | 8 | Current / Voltage | 0.60 | 130 x 40 x 210 |
Popular モデルs from Ovation ブランド
| モデル Number | 説明 | Channels | Signal Type | 重量 (kg) | Dimensions (HxWxD mm) |
|---|---|---|---|---|---|
| 1C31110G01 | Digital Output Module | 16 | Discrete Output | 0.45 | 130 x 40 x 200 |
| 1C31116G02 | Universal Input Module | 8 | Analog & RTD | 0.60 | 130 x 40 x 210 |
| 1C31117G03 | Temperature Input Module | 16 | RTD / Thermocouple | 0.50 | 130 x 40 x 200 |
| 1C31120G04 | Power Supply Module | – | 24 V DC Power Supply | 1.00 | 150 x 60 x 250 |
| 1C31118G01 | Communication Interface Module | – | Ethernet/Serial | 0.70 | 130 x 50 x 210 |
| 1C31119G02 | Alarm Annunciator Module | – | Discrete Signals | 0.45 | 120 x 40 x 190 |
