Product Overview
The HIMA HIMatrix F60 CPU 01 is the central processor module / the HIMatrix F60 safety-related controller system. Designed for demanding industrial automation applications, it ensures reliable execution / safety-critical functions up to SIL 3 (IEC 61508) and SIL 4 for railway (EN 50126). It features integrated Ethernet and fieldbus interfaces, hardware and s/tware self-monitoring, and certified safety compliance for use in safety-critical environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Operating voltage | 24 VDC ±15% |
| Ethernet interfaces | 4 × RJ-45, 10/100 Mbps |
| Fieldbus interfaces | 2 × 9-pin D-sub (with submodules) |
| Operating temperature | 0 to +60 °C |
| Storage temperature | -40 to +85 °C |
| User memory (latest OS) | Max. 1023 kB program, 1023 kB data |
| Response time | ≥ 20 ms |
| Certifications | SIL 3, PL e, Cat. 4, ATEX Zone 2, SIL 4 (railway) |
| Dimensions | 150 × 140 × 80 mm |
| 重量 | 0.28 kg |
Applications
The F60 CPU 01 is suitable for:
-
Safety-critical process automation in chemical, oil & gas, and power industries
-
Railway signaling and interlocking systems
-
Emergency shutdown (ESD) systems
-
Fire & gas detection and suppression control
-
Machine safety control in manufacturing
Advantages
Why choose the HIMatrix F60 CPU 01:
-
Certified to the highest international safety standards
-
Compact and modular design
-
Integrated self-diagnostics and fault monitoring
-
Flexible communication via Ethernet and fieldbus
-
Easy configuration with SILworX or ELOP II Factory tools
-
Reliable operation in harsh environments
FAQ
Q1: What is the maximum safety level supported?
A1: SIL 3 (IEC 61508), SIL 4 (EN 50126 for railway), and PL e (EN ISO 13849-1).
Q2: Which programming tools are compatible?
A2: SILworX (CPU OS V7 and higher) and ELOP II Factory (CPU OS up to V6.x).
Q3: What is the default IP address / the CPU?
A3: 192.168.0.99.
Q4: How many Ethernet ports are available?
A4: Four RJ-45 Ethernet ports with integrated switch.
Q5: Can the module operate in Zone 2 hazardous areas?
A5: Yes, with appropriate installation in an IP54 enclosure as per ATEX requirements.
Q6: How is the CPU mounted?
A6: It is installed in slot 2 / the HIMatrix F60 subrack.
Q7: What is the response time / the CPU?
A7: ≥ 20 ms.
Q8: Does the module support hot swapping?
A8: No, modules must be inserted or removed only when powered /f.
Q9: What is the operating temperature range?
A9: 0 to +60 °C.
Q10: How does the CPU indicate system faults?
A10: System faults are indicated by the red ERR LED on the front panel, and diagnostic details can also be accessed via the programming tool.
Recommended Related モデルs
| モデル | 説明 | Dimensions (mm) | 重量 (kg) |
|---|---|---|---|
| F60 PS 01 | Power supply module | 150×140×80 | 0.30 |
| F60 DI 16 | 16-channel digital input module | 150×140×80 | 0.28 |
| F60 DO 16 | 16-channel digital output module | 150×140×80 | 0.28 |
| F60 AI 8 | 8-channel analog input module | 150×140×80 | 0.28 |
| F60 AO 4 | 4-channel analog output module | 150×140×80 | 0.28 |
| F60 COM 01 | Communication module | 150×140×80 | 0.28 |
Popular HIMA モデルs
| モデル | 説明 | Dimensions (mm) | 重量 (kg) |
|---|---|---|---|
| HIMax X-CPU 01 | High-performance CPU for HIMax | 150×140×80 | 0.35 |
| HIMatrix F35 CPU 01 | Compact CPU for F35 system | 150×140×80 | 0.26 |
| HIMatrix F30 CPU 01 | CPU module for F30 series | 150×140×80 | 0.26 |
| HIMax X-SIL 01 | SIL-certified safety module | 150×140×80 | 0.32 |
| HIMatrix F20 CPU 01 | Compact CPU for F20 series | 150×140×80 | 0.25 |
| HIMax X-BUS 01 | Bus coupler module for HIMax | 150×140×80 | 0.30 |
