The GE IC697MDL652 Discrete Input Module is an interrupt-capable input module designed for the GE Fanuc Series 90-70 PLC system. This specialized module provides 14 discrete interrupt input points, each operating at 24V DC, and supports both positive and negative logic. It is divided into four isolated groups / four points each, allowing enhanced electrical isolation, robust noise imm台y, and reliable operation in industrial environments.
The module is engineered for applications where fast and prioritized signal detection is critical. The interrupt functionality enables the CPU to respond immediately to high-priority events, such as emergency stop signals, critical sensor feedback, or machine protection inputs. Each / the 14 interrupt-capable points can be configured independently to trigger specific interrupt routines in the PLC program, making this module ideal for high-reliability control and automation applications.
The IC697MDL652 integrates seamlessly into existing Series 90-70 racks, supporting multiple interrupt modules in a single system for scalable control architectures. Its design ensures easy installation, real-time diagnostics, and long-term reliability under continuous industrial use.
Technical Specifications
| Parameter | 説明 |
|---|---|
| メーカー | GE Fanuc (General Electric) |
| Product モデル | IC697MDL652 |
| Product Type | Discrete Interrupt Input Module |
| System Series | GE Fanuc Series 90-70 |
| Input Voltage | 24V DC nominal |
| Logic Type | Positive/Negative logic selectable |
| Number / Input Points | 14 interrupt-capable input points |
| Input Grouping | 4 isolated groups / 4 points each |
| Input Current (Typical) | 7 mA per point at 24V DC |
| Input Impedance | 3.4 kΩ nominal |
| Isolation Voltage | 1500V RMS between groups and logic ground |
| Interrupt Capability | 14 dedicated interrupt channels |
| Response Time | <5 ms typical |
| Indicators | LED per input for status indication |
| Backplane Current | 120 mA at 5V DC |
| Power Dissipation | 3.2 W typical |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Humidity Range | 5%–95% non-condensing |
| Mounting Type | Rack-mounted (Series 90-70 I/O base) |
| Cooling Method | Natural convection |
| Diagnostics | Individual LED indicators, open-circuit and short-circuit detection |
| Dimensions (W × H × D) | 200 × 40 × 150 mm |
| 重量 | 0.77 kg |
| Certifications | CE, UL, CSA approved |
Product Applications
The IC697MDL652 Interrupt Module is ideal for industrial applications requiring fast, prioritized signal detection and robust electrical isolation. Typical applications include:
-
Emergency Stop Systems: Immediate CPU response for safety shutdown events.
-
High-Priority Sensor Monitoring: Captures signals from critical machine protection sensors or limit switches.
-
Process Automation: Monitors alarms, interlocks, and high-priority process triggers in chemical or oil and gas plants.
-
Power Generation: Detects breaker trips, generator faults, and auxiliary control signals.
-
Material Handling Systems: Monitors high-priority events such as conveyor jams or safety interlocks.
-
Factory Automation: Detects machine fault conditions or operator emergency interventions in real time.
This module allows PLCs to react in milliseconds to critical events, improving system safety, reliability, and operational efficiency.
Product Advantages
The IC697MDL652 Interrupt Module /fers multiple operational and technical benefits:
-
Interrupt Capability: 14 dedicated interrupt points provide immediate CPU attention for critical events.
-
Positive/Negative Logic: Flexible input compatibility with diverse industrial devices.
-
High Isolation: Four isolated groups prevent cross-talk and protect system integrity.
-
Fast Response: Typical response time under 5 milliseconds ensures rapid event handling.
-
High Channel Density: 14 interrupt-capable inputs in a single module save rack space.
-
LED Status Indicators: Individual LEDs allow instant verification and troubleshooting / input status.
-
Reliable Noise Imm台y: Robust against industrial electromagnetic interference.
-
Modular Design: Fits standard Series 90-70 racks for scalable system expansion.
-
Industrial Durability: Built for continuous operation under demanding industrial conditions.
-
Global Compliance: CE, UL, and CSA approvals ensure safety and interoperability worldwide.
FAQ
-
How many interrupt points does the IC697MDL652 provide, and what do they do?
The module has 14 interrupt-capable points. Each point can trigger a high-priority interrupt in the PLC, allowing immediate CPU response to critical events like emergency stops or safety signals. -
What logic types are supported by the module?
Both positive and negative logic are supported. Each input can be configured depending on whether the field device is sourcing or sinking. -
What is the nominal input voltage?
The module operates at 24V DC and is compatible with standard industrial sensors and proximity switches. -
How are the inputs isolated, and why is this important?
Inputs are divided into four isolated groups / four points each. Isolation prevents electrical noise from affecting other inputs and protects the PLC from faults. -
What is the response time for interrupts?
The typical response time is less than 5 milliseconds, ensuring fast CPU reaction to high-priority signals. -
Can it work with proximity switches or similar sensors?
Yes, it is fully compatible with 24V DC proximity switches and other discrete field devices. -
How is input status indicated?
Each input has an LED that lights when the point is active, helping with monitoring and troubleshooting. -
Is the module compatible with other Series 90-70 modules?
Yes, it works seamlessly with Series 90-70 CPUs, output, and communication modules. -
Does the module provide diagnostic features?
Yes, it has LED indicators and open/short-circuit detection for each input group. -
Can multiple modules be used in one rack?
Yes, multiple modules can be installed, and each manages its own 14 interrupt points independently.
Related or Similar モデルs
| モデル | 説明 |
|---|---|
| IC697MDL650 | 32-Point 24V DC Input Module, positive logic type |
| IC697MDL651 | 32-Point 3–7V DC Input Module, negative logic |
| IC697MDL640 | 16-Point 125V DC Input Module, positive/negative logic |
| IC697MDL653 | 32-Point 24V DC Input Module, negative logic |
| IC697MDL341 | 12-Point 120/240V AC Output Module, high inrush capacity |
| IC697MDL250 | 32-Point 24V DC Output Module for Series 90-70 PLC systems |
Popular GE モデルs
| モデル | 説明 |
|---|---|
| IC697CPX928 | High-performance CPU module for Series 90-70 PLCs |
| IC200ALG264 | 15-Channel Analog Input Module for GE VersaMax systems |
| IC693MDL645 | 16-Point 24V DC Input Module for Series 90-30 PLCs |
| IC695CPU310 | RX3i Compact CPU with integrated Ethernet and redundancy |
| IC693PWR330 | Power Supply Module for Series 90-30 PLCs |
| IC200MDL650 | 32-Point 120V AC Input Module for VersaMax PLC systems |
